10 totalWhat are the electrical requirements for installing this chest freezer?
The freezer requires a grounded three-prong receptacle with a 115V / 60Hz electrical supply rated at 5 amps. The power supply circuit must be installed in accordance with the current edition of the National Electrical Code (NFPA 70) and local codes and ordinances. A minimum circuit of 15 amps is required. (Page 2)
How much clearance space does the freezer need around it during installation?
For adequate air circulation, allow a minimum of 3 inches of clearance on all sides and 1 inch at the bottom. This ensures proper airflow and optimal performance. (Page 3)
What is the total storage capacity of this chest freezer?
The freezer has a total capacity of 5 cubic feet. It also includes one removable wire storage basket for organizing smaller frozen items. (Page 2)
What are the dimensions of this chest freezer?
The freezer measures 33-5/8 inches in height (including the lid), 28-7/8 inches in width, and 20-11/16 inches in depth (including the handle). When the lid is opened to 90 degrees, the maximum height is 52 inches. (Page 2)
What is the maximum surrounding air temperature the freezer can operate in?
The surrounding air temperature should not exceed 110°F to ensure optimum performance. Temperatures of 32°F and below will NOT affect the freezer's operation. (Page 3)
How do I know if my chest freezer is powered on and working?
The freezer includes a Power-On Indicator Light that lets you know at a glance that your freezer is working. This light is a standard feature of the unit. (Page 1)
Full Manual
3 pages
Signature Features
Defrost Water Drain Use the drain to conveniently remove water during defrosting. Power-on Indicator Light Know at a glance that your freezer is working. Adjustable Temperature Control Select the correct temperature for your needs. Removable Storage Basket Stay organized with our removable basket that can hold small frozen items when you need it, or be removed if you have large items that need to be stored.Fffc05M2Uw
frigidaire.com / frigidaire.caProduct Dimensions
Height (Incl. Lid) 33-5/8" Width 28-7/8" Depth 20-11/16"Freezer
Manual Defrost
5 Cu. Ft. Chest
Available Colors
W
White
Specifications subject to change. Accessories information available on the web at frigidaire.com / frigidaire.ca Note: For planning purposes only. Always consult local and national electric, gas and plumbing codes. Refer to Product Installation Guide for detailed installation instructions on the web at frigidaire.com / frigidaire.ca. USA • 10200 David Taylor Drive • Charlotte, NC 28262 • 1-800-FRIGIDAIRE • frigidaire.com CANADA • 5855 Terry Fox Way • Mississauga, ON L5V 3E4 • 1-800-265-8352 • frigidaire.ca
Fffc05M2Uw 07/18
© 2018 Electrolux Home Products, Inc.A
B
C
Features
Defrost Manual Adjustable Temperature Control Yes Store-More™ Removable Baskets 1 Wire Defrost Water Drain Yes Lid Handle Yes Power-On Light YesCertifications
CSA Rating HouseholdSpecifications
Total Capacity (Cu. Ft.) 5 Annual Energy (kWH) 218 Annual Energy Cost (.1065 / kWH) $26 Power Cord Connection Location Left Bottom Rear Voltage Rating 115V / 60Hz Connected Load (kW rating) @ 120 Volts1 .6 Amps @ 120 Volts 5 Minimum Circuit Required (Amps) 15 Shipping Weight (Approx.) 71 Lbs. 1 An electrical supply with grounded three-prong receptacle is required. The power supply circuit must be installed in accordance with current edition of National Electrical Code (NFPA 70) and local codes & ordinances.Product Dimensions
A - Height (Incl. Lid) 33-5/8" B - Width 28-7/8" C - Depth (Incl. Handle) 20-11/16" Height with Lid Open 90° 52"Fffc05M2Uw
Freezer
5 Cu. Ft. Chest
