HP EliteBook 630 G10 13.3 Inch Notebook PC

Datasheet HP EliteBook 630 13.3 inch G10 Notebook PC Empowering the hybrid workforce Simplify hybrid work with the cost-effective, highly secure, and easy to manage HP EliteBook

With the latest Intel® processor , this PC easily adapts for use at home, in the office, or

when traveling. Ready for demanding workloads Drive performance with the latest Intel® processor in the HP EliteBook 630. This globally available and easily serviceable PC features long battery life and two USB Type-A (USB 3.2 Gen 1) and one Thunderbolt™ 4 with USB4 Type-C® port. Protected by HP Wolf Security HP Wolf Security for Business creates a hardware-enforced, always-on, resilient defense. From the BIOS to the browser, above, in, and below the OS, these constantly evolving solutions help protect your PC from modern threats. Make connections that matter Take presenting in a hybrid work environment to the next level with audio and video features that enhance your collaboration experience. Enjoy the crystal-clear audio performance delivered by HP Dynamic Voice Leveling and HP AI Noise Reduction. Sustainability in action Outer box packaging 100% sustainably sourced This PC contains at least 30-percent post-consumer recycled plastic in the bezel, at least 50-percent post-consumer recycled plastic in the keycaps , and the outer box packaging is 100-percent sustainably sourced. 2 2 3 17 6 6 *Product image may differ from actual product 6 7

Datasheet HP recommends Windows 11 Pro for business HP EliteBook 630 13.3 inch G10 Notebook PC Technical specifications Available Operating Systems Windows 11 Pro Windows 11 Pro Education Windows 11 Home – HP recommends Windows 11 Pro for business Windows 11 Home Single Language – HP recommends Windows 11 Pro for business Windows 11 Pro (Windows 11 Enterprise or Windows 10 Enterprise available with a Volume Licensing Agreement) Windows 11 Pro (preinstalled with Windows 10 Pro Downgrade) FreeDOS Processor family 13th Generation Intel® Core™ i7 processor 13th Generation Intel® Core™ i5 processor 13th Generation Intel® Core™ i3 processor Available Processors Intel® Core™ i7-1355U (1.2 GHz E-core base frequency, 1.7 GHz P-core base frequency, up to 3.7 GHz E-core Max Turbo frequency, up to 5.0 GHz P- core Max Turbo frequency, 12 MB L3 cache, 2 P-cores and 8 E-core, 12 threads) Intel® Core™ i5-1335U (0.9 GHz E-core base frequency, 1.3 GHz P-core base frequency, up to 3.4 GHz E-core Max Turbo frequency, up to 4.6 GHz P- core Max Turbo frequency, 12 MB L3 cache, 2 P-cores and 8 E-core, 12 threads) Intel® Core™ i7-1365U (1.3 GHz E-core base frequency, 1.8 GHz P-core base frequency, up to 3.9 GHz E-core Max Turbo frequency, up to 5.2 GHz P- core Max Turbo frequency, 12 MB L3 cache, 2 P-cores and 8 E-core, 12 threads) Intel® Core™ i5-1345U (1.2 GHz E-core base frequency, 1.6 GHz P-core base frequency, up to 3.5 GHz E-core Max Turbo frequency, up to 4.7 GHz P- core Max Turbo frequency, 12 MB L3 cache, 2 P-cores and 8 E-core, 12 threads) Intel® Core™ i3-1315U with Intel® UHD Graphics (0.9 GHz E-core base frequency, 1.2 GHz P-core base frequency, up to 3.3 GHz E-core Max Turbo frequency, up to 4.5 GHz P-core Max Turbo frequency, 10 MB L3 cache, 2 P-cores and 4 E-core, 8 threads) Maximum memory 64 GB DDR4-3200 MHz RAM Both slots are accessible/upgradeable by IT or self-maintainers only. Supports dual channel memory. Memory slots

2 Sodimm

Internal storage 1 TB up to 2 TB PCIe® NVMe™ M.2 SSD TLC up to 1 TB PCIe® NVMe™ M.2 SED SSD TLC up to 512 GB PCIe® Gen4x4 NVMe™ M.2 SED SSD TLC up to 512 GB PCIe® Gen4x4 NVMe™ M.2 SSD TLC 256 GB up to 512 GB PCIe® NVMe™ M.2 SSD up to 256 GB PCIe® NVMe™ M.2 SED SSD Display size (diagonal, metric) 33.8 cm (13.3") Display 33.8 cm (13.3") diagonal, FHD (1920 x 1080), IPS, anti-glare, 400 nits, low power, 72% NTSC; 33.8 cm (13.3") diagonal, FHD (1920 x 1080), IPS, narrow bezel, anti-glare, 250 nits, 45% NTSC; 33.8 cm (13.3") diagonal, HD (1366 x 768), narrow bezel, anti-glare, 250 nits, 45% NTSC; 33.8 cm (13.3") diagonal, FHD (1920 x 1080), touch, IPS, 250 nits, 45% NTSC; 33.8 cm (13.3") diagonal, FHD (1920 x 1080), IPS, narrow bezel, anti-glare, 1000 nits, 100% sRGB, HP Sure View integrated privacy screen with HP Eye Ease Available Graphics Integrated: Intel® UHD Graphics; Intel® Iris® Xᵉ Graphics (Support HD decode, DX12, HDMI 2.1.) Audio Dual stereo speakers, dual array microphones Wireless technologies (Compatible with Miracast-certified devices.) Ports and connectors 1 Thunderbolt™ 4 with USB Type-C® 40Gbps signaling rate (USB Power Delivery, DisplayPort™ 1.4); 2 USB Type-A 5Gbps signaling rate (1 power); 1 AC power; 1 HDMI 2.1; 1 stereo headphone/microphone combo jack; 1 RJ-45 ; (HDMI cable sold separately.); Optional Ports: 1 Smartcard reader (optional) Input devices HP Premium Keyboard – spill resistant, optional backlit keyboard ; Clickpad with multi-touch gesture support Communications Intel® I219-LM GbE LOM, vPro®; Intel® I219-LM GbE LOM, non-vPro® ; Intel® Wi-Fi 6E AX211 (2x2) and Bluetooth® 5.3 wireless card, vPro®; Intel® Wi-Fi 6E AX211 (2x2) and Bluetooth® 5.3 wireless card, non-vPro® ; Near Field Communication (NFC) module Camera 720p HD camera with temporal noise reduction; IR Camera (select models) Software HP Connection Optimizer; HP Hotkey Support; HP Power Manager; myHP; HP Privacy Settings; HP Notifications; HP PC Hardware Diagnostics Windows; HP Services Scan; HP Smart Support (download) Buy Office (Sold separately) Security management Absolute persistence module; HP Secure Erase; HP Sure Click; HP Sure Sense; BIOS Update via Network; HP Sure Admin; HP BIOSphere Gen6; HP Client Security Manager Gen7; TPM 2.0 embedded security chip (Common Criteria EAL4+ and FIPS 140-2 Level 2 Certified); HP Sure Start Gen7; HP Wake on WLAN; HP Tamper Lock; HP Sure Run Gen5; HP Sure Recover Gen5; Secured-Core PC Enable Security Software Licenses HP Wolf Pro Security Edition Fingerprint reader Fingerprint sensor (select models) 1 1 1 1 1 1,2 6 3,4,5 7 8 8 8 8 8 8 13,15,16,17 12,13 42 18 14 11 9,10 13,18 20,21,38,57; 19 25,26,27,28,29,30,31,32,33,34 56

Datasheet HP recommends Windows 11 Pro for business HP EliteBook 630 13.3 inch G10 Notebook

Pc

Technical specifications Management features HP Client Management Script Library (download); HP Driver Packs (download); HP Client Catalog (download); HP Manageability Integration Kit Gen4 (download); HP Image Assistant Gen5 (download); HP Patch Assistant (download); HP Cloud Recovery; HP Connect for Microsoft Endpoint Manager Available Graphics Integrated: Intel® UHD Graphics; Intel® Iris® Xᵉ Graphics (Support HD decode, DX12, HDMI 2.1.) Audio Dual stereo speakers, dual array microphones Wireless technologies (Compatible with Miracast-certified devices.) Ports and connectors 1 Thunderbolt™ 4 with USB Type-C® 40Gbps signaling rate (USB Power Delivery, DisplayPort™ 1.4); 2 USB Type-A 5Gbps signaling rate (1 power); 1 AC power; 1 HDMI 2.1; 1 stereo headphone/microphone combo jack; 1 RJ-45 ; (HDMI cable sold separately.); Optional Ports: 1 Smartcard reader (optional) Input devices HP Premium Keyboard – spill resistant, optional backlit keyboard ; Clickpad with multi-touch gesture support Communications Intel® I219-LM GbE LOM, vPro®; Intel® I219-LM GbE LOM, non-vPro® ; Intel® Wi-Fi 6E AX211 (2x2) and Bluetooth® 5.3 wireless card, vPro®; Intel® Wi-Fi 6E AX211 (2x2) and Bluetooth® 5.3 wireless card, non-vPro® ; Near Field Communication (NFC) module Camera 720p HD camera with temporal noise reduction; IR Camera (select models) Software HP Connection Optimizer; HP Hotkey Support; HP Power Manager; myHP; HP Privacy Settings; HP Notifications; HP PC Hardware Diagnostics Windows; HP Services Scan; HP Smart Support (download) Buy Office (Sold separately) Security management Absolute persistence module; HP Secure Erase; HP Sure Click; HP Sure Sense; BIOS Update via Network; HP Sure Admin; HP BIOSphere Gen6; HP Client Security Manager Gen7; TPM 2.0 embedded security chip (Common Criteria EAL4+ and FIPS 140-2 Level 2 Certified); HP Sure Start Gen7; HP Wake on WLAN; HP Tamper Lock; HP Sure Run Gen5; HP Sure Recover Gen5; Secured-Core PC Enable Security Software Licenses HP Wolf Pro Security Edition Fingerprint reader Fingerprint sensor (select models) Management features HP Client Management Script Library (download); HP Driver Packs (download); HP Client Catalog (download); HP Manageability Integration Kit Gen4 (download); HP Image Assistant Gen5 (download); HP Patch Assistant (download); HP Cloud Recovery; HP Connect for Microsoft Endpoint Manager Power HP Smart 65 W External AC power adapter; HP Smart 65 W EM External AC power adapter; HP Smart 45 W External AC power adapter; HP Smart 45 W 2-prong External AC power adapter; HP Smart 65 W USB Type-C® adapter; HP Smart 45 W USB Type-C® adapter Battery type HP Long Life 3-cell, 42.75 Wh polymer Dimensions 30.69 x 20.84 x 1.59 cm 6.9 x 48.3 x 30.5 cm (Package) Weight Starting at 1.22 kg (Weight will vary by configuration. Does not include power adapter.) Ecolabels CECP; IT ECO Declaration; EPEAT® Gold registered in the U.S.; SEPA; Taiwan Green Mark; Japan PC Green Label; TCO Certified Energy star certified (series fixed) ENERGY STAR® certified Certification and compliance CCC; CECP; GS Mark Sustainable impact specifications Low Halogen; Bulk packaging available; Molded paper pulp cushion inside box is 100% sustainably sourced and recyclable; Outside box and corrugated cushions are 100% sustainably sourced and recyclable; 5% post-consumer recycled plastic; Ocean-bound plastic in speaker enclosure(s) Warranty 1-year and 3-year limited warranties and 90 day software limited warranty options depending on country. Batteries have a default one year limited warranty. Refer to http://www.hp.com/support/batterywarranty/ for additional battery information. On-site service and extended coverage is also available. HP Care Pack Services are optional extended service contracts that go beyond the standard limited warranties. To choose the right level of service for your HP product, use the HP Care Pack Services Lookup Tool at: http://www.hp.com/go/cpc . 22,23,24 12,13 42 18 14 11 9,10 13,18 20,21,38,57; 19 25,26,27,28,29,30,31,32,33,34 56 22,23,24 37 36 39 40,41,43,44,45

Datasheet HP recommends Windows 11 Pro for business HP EliteBook 630 13.3 inch G10 Notebook

Pc

Footnotes Key Selling Points Footnotes Multicore is designed to improve performance of certain software products. Not all customers or software applications will necessarily benefit from use of this technology. Performance and clock frequency will vary depending on application workload and your hardware and software configurations. Intel’s numbering, branding and/or naming is not a measurement of higher performance. HP Wolf Security for Business requires Windows 10 Pro and higher, includes various HP security features and is available on HP Pro, Elite, Workstation, and RPOS products. See product details for included security features and OS requirements. Requires the myHP application and Windows OS. HP Power Manager requires Windows 10 and higher and is available from the Microsoft store. 100% outer box packaging made from sustainably sourced certified and recycled fibers. Fiber cushions made from 100% recycled wood fiber and organic material. Any plastic cushions are made from >90% recycled plastic. Sold separately or as an optional feature. Sold separately or as an optional feature. For storage drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 30GB (for Windows) of disk is reserved for system recovery software. HP Sure View Reflect integrated privacy screen is an optional feature that must be configured at purchase and is designed to function in landscape orientation. HP Manageability Integration Kit can be downloaded from http://www8.hp.com/us/en/ads/clientmanagement/overview.html . HP Sure Start Gen7 is available on select HP PCs and requires Windows 10 Pro and higher. HP Sure Run Gen5 is available on select HP PCs and requires Windows 10 Pro and higher. HP Sure Recover Gen5 is available on select HP PCs and requires Windows 10 Pro and higher and an open network connection. You must back up important files, data, photos, videos, etc. before using HP Sure Recover to avoid loss of data. Network based recovery using Wi-Fi is only available on PCs with Intel Wi-Fi Module. HP Sure Click requires Windows 10 and higher. See https://bit.ly/2PrLT6A_SureClick for complete details. HP conferencing features require Windows and the latest myHP app, available over the air or for download via sofpaq on the HP Support website. Planned availability in spring 2023. Technical Specifications Footnotes This computer is preinstalled with Windows [insert Product version/edition name] Home Single Language. Multicore is designed to improve performance of certain software products. Not all customers or software applications will necessarily benefit from use of this technology. Performance and clock frequency will vary depending on application workload and your hardware and software configurations. Intel’s numbering, branding and/or naming is not a measurement of higher performance. Processor speed denotes maximum performance mode; processors will run at lower speeds in battery optimization mode. Intel® Turbo Boost performance varies depending on hardware, software and overall system configuration. See www.intel.com/technology/turboboost for more information. In accordance with Microsoft’s support policy, HP does not support the Windows 8 or Windows 7 operating system on products configured with Intel and AMD 7th generation and forward processors or provide any Windows 8 or Windows 7 drivers on http://www.support.hp.com . Due to the non-industry standard nature of some third-party memory modules, we recommend HP branded memory to ensure compatibility. If you mix memory speeds, the system will perform at the lower memory speed. For storage drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 30 GB (for Windows 10 and 11) is reserved for system recovery software. Wi-Fi 6E requires a Wi-Fi 6E router, and Windows 11, to function in the 6GHz band. Availability of public wireless access points limited. Wi-Fi 6E is backwards compatible with prior 802.11 specs. And available in countries where Wi-Fi 6E is supported. Miracast is a wireless technology your PC can use to project your screen to TVs, projectors, and streaming. The term "10/100/1000" or "Gigabit" Ethernet indicates compatibility with IEEE standard 802.3ab for Gigabit Ethernet, and does not connote actual operating speed of 1 Gb/s. For high-speed transmission, connection to a Gigabit Ethernet server and network infrastructure is required. Intel® Iris® Xᵉ Graphics capabilities require system to be configured with Intel® Core™ i5 or i7 processors and dual channel memory. Intel® Iris® Xᵉ Graphics with Intel® Core™ i5 or 7 processors and single channel memory will only function as UHD graphics. HD content required to view HD images. Backlit keyboard is an optional feature. Resolutions are dependent upon monitor capability, and resolution and color depth settings. HP Sure View Reflect integrated privacy screen is an optional feature that must be configured at purchase and is designed to function in landscape orientation. Actual brightness will be lower with touchscreen or Sure View. Sold separately or as an optional feature. Microsoft Office sold separately and requires Internet access for activation. HP Support Assistant requires Windows and Internet access. HP Services Scan is provided with Windows Update on select products and will check entitlement on each hardware device to determine if an HP TechPulse-enabled service has been purchased, and will download applicable software automatically. HP TechPulse is a telemetry and analytics platform that provides critical data around devices and applications. For full system requirements or to disable this feature, please visit http://www.hpdaas.com/requirements . Not applicable in China. HP Connect for Microsoft Endpoint Manager is available from the Azure Market Place for HP Pro, Elite, Z and Point-of-Sale PCs managed with Microsoft Endpoint Manager. Subscription to Microsoft Endpoint Manager required and sold separately. Network connection required. HP Manageability Integration Kit can be downloaded from http://www8.hp.com/us/en/ads/clientmanagement/overview.html . HP Patch Assistant available on select HP PCs with the HP Manageability Kit that are managed through Microsoft System Center Configuration Manager. HP Manageability Integration Kit can be downloaded from http://www8.hp.com/us/en/ads/clientmanagement/overview.html . HP Sure Click requires Windows 10 Pro or higher or Enterprise. See https://bit.ly/2PrLT6A_SureClick for complete details. HP Sure Sense is available on select HP PCs with Windows 10 Pro, Windows 10 Enterprise, Windows 11 Pro, or Windows 11 Enterprise OS25. HP Sure Run Gen5 is available on select HP PCs and requires Windows 10 and higher. HP Sure Run Gen5 is available on select HP PCs and requires Windows 10 and higher. HP Sure Recover is available on HP Elite PCs with 8th generation Intel® or AMD processors and requires an open, wired network connection. You must back up important files, data, photos, videos, etc. before use to avoid loss of data. Does not support platforms with Intel® Optane™. HP Sure Start Gen7 is available on select HP PCs and requires Windows 10 and higher. HP Client Security Manager Gen7 requires Windows and is available on the select HP Elite and Pro PCs. HP BIOSphere Gen6 features may vary depending on the platform and configuration. HP Secure Erase for the methods outlined in the National Institute of Standards and Technology Special Publication 800-88 "Clear" sanitation method. HP Secure Erase does not support platforms with Intel® Optane™. Absolute firmware module is shipped turned off and can only be activated with the purchase a license subscription and full activation of the software agent. License subscriptions can be purchased for terms ranging multiple years. Service is limited, check with Absolute for availability outside the U.S. Certain conditions apply. For full details visit: https://www.absolute.com/about/legal/agreements/absolute/ Secured-Core PC Enable requires an Intel® vPro® , AMD Ryzen™ Pro processor or Qualcomm® processor with SD850 or higher and requires 8 GB or more system memory. Secured-core PC is enabled from the factory. HP Fingerprint sensor is an optional feature that must be configured at purchase. Actual battery Watt-hours (Wh) will vary from design capacity. Battery capacity will naturally decrease with shelf life, time, usage, environment, temperature, system configuration, loaded apps, features, power management settings and other factors. Availability may vary by country. HP Power Manager requires Windows 10 and higher and can be downloaded from the Microsoft Store. Based on US EPEAT® registration according to IEEE 1680.1-2018 EPEAT®. Status varies by country. Visit www.epeat.net for more information. External power supplies, power cords, cables and peripherals are not Low Halogen. Service parts obtained after purchase may not be Low Halogen. Molded pulp cushions made from 100% recycled wood fiber and organic materials. SuperSpeed USB 20Gbps is not available with Thunderbolt™ 4. Recycled plastic content percentage is based on the definition set in the IEEE 1680.1-2018 standard. 100% outer box packaging and corrugated cushions made from sustainably sourced certified and recycled fibers. Percentage of ocean-bound plastic contained in each component varies by product. HP Wolf Pro Security Edition (including HP Sure Click Pro and HP Sure Sense Pro) is available preloaded on select SKUs and, depending on the HP product purchased, includes a paid 1-year or 3-year license. The HP Wolf Pro Security Edition software is licensed under the license terms of the HP Wolf Security Software - End-User license Agreement (EULA) that can be found at: https://support.hp.com/us-en/document/ish_3875769-3873014-16 as that EULA is modified by the following: “7. Term. Unless otherwise terminated earlier pursuant to the terms contained in this EULA, the license for the HP Wolf Pro Security Edition (HP Sure Sense Pro and HP Sure Click Pro) is effective upon activation and will continue for either a twelve (12) month or thirty-six (36) month license term (“Initial Term”). At the end of the Initial Term you may either (a) purchase a renewal license for the HP Wolf Pro Security Edition from HP.com, HP Sales or an HP Channel Partner, or (b) continue using the standard versions of HP Sure Click and HP Sure Sense at no additional cost with no future software updates or HP Support.” © Copyright 2023 HP Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein. Intel, Core, Iris and Intel vPro are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries. Bluetooth is a trademark owned by its proprietor and used by HP Inc. under license. DisplayPort™ and the DisplayPort™ logo are trademarks owned by the Video Electronics Standards Association (VESA®) in the United States and other countries. USB Type-C® and USB-C® are registered trademarks of USB Implementers Forum. ENERGY STAR is a registered trademark of the U.S. Environmental Protection Agency. All other trademarks are the property of their respective owners. August 2023
