Common questions
Common Questions
20 totalWhat are the power output levels available on this microwave and what are they used for?
The microwave has five power levels: Low (17%) for softening ice cream, Med. Low/Defrost (33%) for soup, stew, or defrosting, Med. (55%) for stew and fish, Med. High (77%) for rice, fish, chicken, and ground meat, and High (100%) for reheating, milk, boiling water, vegetables, and beverages. You select the desired level using the POWER knob before setting the timer. (Page 13)
What combination cooking modes are available and what foods are they best suited for?
There are three combination modes plus a pure grill option: Combi.1 (80% Grill & 20% Micro) for sausage, lamb, kabobs, seafood, and steak; Combi.2 (70% Grill & 30% Micro) for chicken pieces, chicken breasts, and pork chops; Combi.3 (60% Grill & 40% Micro) for whole chicken; and 100% Grill for baking bread and slicing food. Children should only use the oven in combination mode under adult supervision due to the high temperatures generated. (Page 14)
What should I do if my microwave oven won't start?
Check that the power cord is plugged in tightly — if not, unplug it and plug it back in after 10 seconds. Other possible causes include a blown fuse or tripped circuit breaker (which should be repaired by professional personnel), a faulty outlet (test with another appliance), or a door that is not closed properly. (Page 15)
Is it safe to run the microwave with no food inside?
No, it is forbidden to run the unit without any food inside as it is very dangerous. Additionally, operating the microwave oven without food can result in overheating and damage to the magnetron. Always ensure the timer is set to O (zero) when removing food from the oven. (Page 14-15)
How do I clean the inside of my microwave oven?
Unplug the appliance before cleaning, then wipe the cavity with a slightly damp cloth after each use. For easier cleaning of cavity walls, place half a lemon in a bowl with 300ml of water and heat on 100% microwave power for 10 minutes, then wipe clean with a soft, dry cloth. Never use harsh abrasive cleaners or sharp metal scrapers, especially on the door glass, as they can scratch the surface and may cause the glass to shatter. (Page 8)
What are the installation clearance requirements for this microwave?
The minimum installation height is 85cm, and the rear surface must be placed against a wall. A minimum clearance of 30cm is required above the oven, and a minimum clearance of 20cm is required between the oven and any adjacent walls. Do not install the oven over a range cooktop or other heat-producing appliance, as this could damage the oven and void the warranty. (Page 12)
Show 14 more questions
What are the key specifications of the Mw2-Mg20Pe(Bk) microwave?
What materials and utensils should I avoid using in the microwave?
Is it normal for my microwave to interfere with TV or radio reception?
What safety precautions should I follow when heating liquids and eggs in the microwave?
What should I do if the oven won't start?
Can I use metal containers in the microwave?
How do I properly install the turntable?
What's the safest way to clean the microwave oven?
Can I heat liquids in sealed containers?
What are the minimum clearance requirements for installation?
Why is the oven light dim during cooking?
How do I test if a utensil is safe for microwave use?
What happens if the oven oven door or seals are damaged?
Is it safe to operate the oven without food inside?
Full Manual
16 pages
Instruction Manual
Microwave OvenMw2-Mg20Pe(Bk)
Read these instructions carefully before using your microwave oven, and keep it carefully.If you follow the instructions, your oven will provide you with many years of good service.Save These Instructions Carefully
Contents.
PRECAUTIONS .....................................................................................................3 IMPORTANT SAFETY INSTRUCTIONS ..........................................................4To Reduce The Risk Of Injury To Persons Grounding
INSTALLATION .....................................................................................................7 CLEANING ............................................................................................................8Materials You Can Use In Microwave Oven ..................................9
Materials To Be Avoided In Microwave Oven
...........................
10 SET UP & INSTALLATION ............................................................................11 OPERATION ........................................................................................................13 TROUBLE SHOOTING ......................................................................................15........
3
Precautions
Precautions To Avoid Possible Exposure To Excessive
Microwave Energy
(a) Do not attempt to operate this oven with the door open since this can result in harmful exposure to microwave energy. It is important not to break or tamper with the safety interlocks. (b)Do not place any object between the oven front face and the door or allow cleaner residue to accumulate on sealing surface. (c) WARNING: If the door or door seals are damaged, the oven must not be operated until it has been repaired by a competent person.Addendum
If the apparatus is not maintained in a good state of cleanliness, its surface could be degraded and affect the life span of the apparatus and lead to a dangerous situation.Specifications
Model:Mw2-Mg20Pe(Bk)
Rated Voltage: 230V~ 50Hz Input Power (Microwave):1050W
Output Power (Microwave):700W
Capacity:20L
Turntable Diameter: Φ 255mm Outside Dimensions (Wx D x H): 440x356x259mm Net Weight: Approx. 11.1 kg Grill Power:1000W
4
Important Safety Instructions
To reduce the risk of fire, electric shock, injury to persons or exposure to excessive microwave oven energy when using your appliance, follow basic precautions, including the following:Exposureto Excessive Microwave Energy".
5
6
Read Carefully And Keep For Future Reference
7 To Reduce the Risk of Injury to Persons Grounding Installation
Danger
Electric Shock HazardTouching some of the internal components can cause serious personal injury or death. Do not disassemble this appliance.Warning
Electric Shock HazardImproper use of the grounding can result in electric shock. Do not plug into an outlet until appliance is properly installed and grounded. This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire for the electric current. This appliance is equipped with a cord having a grounding wire with a grounding plug. The plug must be plugged into an outlet that is properly installed and grounded. Consult a qualified electrician or serviceman if the grounding instructions are not completely understood or if doubt exists as to whether the appliance is properly grounded. If it is necessary to use an extension cord, use only a 3-wire extension cord.
8
Cleaning
Be sure to unplug the appliance from the power supply.Utensils
Caution
Personal Injury Hazard It is hazardous for anyone other than a competent person to carry out any service or repair operation that involves the removal of a cover which gives protection against exposure to microwave energy. See the instructions on "Materials you can use in microwave oven or to be avoided in microwave oven." There may be certain non- metallic utensils that are not safe to use for microwaving. If in doubt, you can test the utensil in question following the procedure below. Utensil Test:Note: Keep The Cavity And Wave Guide Area Clean
9 Materials you can use in microwave oven Utensils Remarks Browning dish Follow manufacturer's instructions. The bottom of browning dish must be at least 3/16 inch (5mm) above the turntable. Incorrect usage may cause the turntable to break. Dinnerware Microwave-safe only. Follow manufacturer's instructions. Do not use cracked or chipped dishes. Glass jars Always remove lid. Use only to heat food until just warm. Most glass jars are not heat resistant and may break. Glassware Heat-resistant oven glassware only. Make sure there is no metallic trim. Do not use cracked or chipped dishes. Oven cooking bags Follow manufacturer's instructions. Do not close with metal tie. Make slits to allow steam to escape. Paper plates and cups Use for short-term cooking/warming only. Do not leave oven unattended while cooking. Paper towels Use to cover food for reheating and absorbing fat. Use with supervision for a short-term cooking only. Parchment paper Use as a cover to prevent splattering or a wrap for steaming. Plastic Microwave-safe only. Follow the manufacturer's instructions. Should be labeled "Microwave Safe". Some plastic containers soften, as the food inside gets hot. "Boiling bags" and tightly closed plastic bags should be slit, pierced or vented as directed by package. Plastic wrap Microwave-safe only. Use to cover food during cooking to retain moisture. Do not allow plastic wrap to touch food. Wax paper Use as a cover to prevent splattering and retain moisture.
10 Utensils Remarks Aluminum tray May cause arcing. Transfer food into microwave-safe dish. Food carton with metal handle May cause arcing. Transfer food into microwave-safe dish. Metal or metal- trimmed utensils Metal shields the food from microwave energy. Metal trim may cause arcing. Metal twist ties May cause arcing and could cause a fire in the oven. Paper bags May cause a fire in the oven. Plastic foam Plastic foam may melt or contaminate the liquid inside when exposed to high temperature. Wood Wood will dry out when used in the microwave oven and may split or crack. Materials to be avoided in microwave oven
11
Set Up & Installation
Setting Up Your Oven
Names of Oven Parts and Accessories. Remove the oven and all materials from the carton and oven cavity. Your oven comes with the following accessories: Glass tray1 Turntable ring assembly 1 Turntable Shaft 1 Grill Rack 1 Instruction Manual 1 A) Control panel B) Turntable shaft C) Turntable ring assembly D) Glass tray E) Observation window F) Door assembly G) Safety interlock system a. Never place the glass tray upside down. Follow the instruction to place the glass tray on the turntable ring with correct direction. The glass tray should rotate smoothly. b. Both glass tray and turntable ring assembly must always be used during cooking. c. All food and containers of food are always placed on the glass tray for cooking. d. If glass tray or turntable ring assembly cracks or breaks, contact your nearest authorized service center. Turntable Installation Hub (underside) Turntable shaft Glass tray Turntable ring assembly Grill Rack (Can not be used in microwave function and must be placed on the glass tray)H
H) Waveguide cover
12 Remove all packing material and accessories. Examine the oven for any damage such as dents or broken door. Do not install if oven is damaged.Cabinet: Remove any protective film found on the microwave oven cabinet surface. Do not remove the light brown waveguide cover that is attached to the oven cavity to protect the magnetron. Installation
Countertop Installation
13
Operation
POWER knob TIMER knob Function/Power Output Application Low 17% Micro. Soften Ice Cream Med. Low (Defrost) 33% Micro. Soup Stew, Soften Butter or Defrost Med. 55% Micro. Stew, Fish Med. High 77% Micro. Rice, Fish, Chicken, Ground Meat High 100% Micro. Reheat, Milk, Boil Water, Vegetables, Beverage To set cooking power by turning POWER knob to desired level.
14 Function/Power Output Application Combi.1 80% Grill & 20% Micro. Sausage, Lamb, Kabobs, Seafood, Steak Combi.2 70% Grill & 30% Micro. Chicken Pieces, Chicken Breasts, Pork Chops Combi.3 60% Grill & 40% Micro. Whole Chicken 100% Grill Bake Bread, Slice Food Notice: When removing food from the oven, please ensure that the oven power is switched off by turning the timer switch to O (zero). Failure to do so, and operating the microwave oven without food in it, can result in overheating and damage to the magnetron.
15
Trouble Shooting
Normal Microwave oven interfering TV reception Radio and TV reception may be interfered when microwave oven operating.It is similar to the interference of small electrical appliance, like mixer, vacuum cleaner, and electric fan.It is normal. Dim oven light In low power microwave cooking, oven light may become dim. It is normal. Steam accumulating on door, hot air out of vents In cooking, steam may come out of food. Most will get out from vents. But some may accumulate on cool place like oven door. It is normal. Oven started accidentally with no food in. It is forbidden to run the until without any food inside. It is very dangerous. Normal Possible Cause Remedy Oven can not be started. (1) Power cord not plugged in tightly. Unplug. Then plug again after 10 seconds. (2) Fuse blowing or circuit breaker works. Replace fuse or reset circuit breaker (repaired by professional personnel of our company) (3) Trouble with outlet. Test outlet with other electrical appliances. Oven does not heat. (4) Door not closed well. Close door well.Pn:16170000A91892
