Everstart Maxx 1200A Jump Starter

How do I charge the EverStart Maxx Jump Starter?

Plug the Micro USB end of the charging cable into the input port on the jump starter, then connect the USB end to a charger's USB port and plug it into a live AC or DC power outlet. The jump starter will fully charge in approximately 4 hours with a 2A charger. When fully charged, all four blue LEDs will turn solid for a short time and then shut off.

What are the specifications of the EverStart Maxx 1200A Jump Starter?

The EverStart Maxx Jump Starter (Model PPS1CWE) has a peak battery output of 1000 Amps, a built-in compressor with up to 120 PSI pressure, two USB ports providing 3.1A total (5V each), and a built-in LED area light. It also features a wireless charging pad for compatible devices.

How do I jump start a vehicle with the EverStart Maxx?

Ensure the jump starter is fully charged, then connect the red (positive) clamp to the positive terminal of the vehicle's battery and the black (negative) clamp to a grounded metal surface away from the battery. Press the Jump Starter Power Button to turn on the unit, attempt to start the vehicle, and once it starts, remove the clamps in reverse order.

How do I use the built-in compressor to inflate tires?

Ensure the jump starter is fully charged, screw the Sure Fit® nozzle onto the valve stem of the tire, and press the Compressor Power Button to turn on the compressor. Use the Increase (+) and Decrease (–) Pressure Control Buttons to set your desired pressure—the compressor will automatically stop when the set pressure is reached. Press the Compressor Power Button again to turn off the unit and remove the nozzle.

What should I do if the unit does not power on?

Ensure the jump starter is fully charged, check that the power button is in the "on" position, and verify that the battery clamps are properly connected. If the unit still does not power on, the battery may need to be recharged or there may be a connection issue.

How can I troubleshoot USB ports that are not charging devices?

Ensure the USB ports are turned on by pressing the USB Power Button, check that your device is properly connected to the USB port, and verify that your device is compatible with the USB output. If charging still does not work, disconnect the device and allow the unit to cool down before trying again.
