Name: Frigidaire Nugget Ice Maker EFIC189
Brand: Frigidaire

Question 1

What are the electrical requirements for the Nugget Ice Maker?

Accepted Answer

The appliance must be plugged into a 15 AMP, 110-115 VOLT, 60 Hz grounded outlet. The appliance is equipped with a 3-wire cord having a grounding plug that must be plugged into an outlet that is properly installed and grounded.

Question 2

How long does it take to get the first batch of ice?

Accepted Answer

The first batch of ice is typically ready in about 10–15 minutes after starting the ice-making process.

Question 3

What should I do before plugging in the ice maker for the first time?

Accepted Answer

Allow the refrigerant fluid to settle for at least an hour before plugging in the unit. You should also remove all exterior and interior packaging, clean the interior with lukewarm water and a soft cloth, and place the ice maker on a level countertop away from direct sunlight and heat sources.

Question 4

How do I fill the water reservoir?

Accepted Answer

Pull out the top drawer section of the ice maker, open the water tank lid, and fill the tank with clean, potable water up to the maximum fill line. Then close the water tank lid and slide the water tank back into the ice maker.

Question 5

What should I do if the 'Add Water' indicator lights up?

Accepted Answer

Stop the ice maker and fill the reservoir with water, then press the 'Ice/Clean' button again to restart the unit. If the problem persists, check that the internal water tank baffle is installed correctly, or consult a qualified technician if it may be a water pump failure.

Question 6

What does it mean when the 'Ice Full' indicator lights up?

Accepted Answer

The 'Ice Full' indicator means the ice basket is full or there are no ice cubes inside. Remove the ice cubes from the basket or check for obstructions and clean the interior walls of the ice storage, then press the 'Ice' button for 5 seconds to resume ice-making for 80 minutes.

Question 7

How do I perform the cleaning procedure?

Accepted Answer

Press the 'Clean' button on the control panel to initiate the cleaning process, which takes about 20 minutes and will be indicated by an illuminated Clean icon. After cleaning, place the ice maker on the edge of a countertop with the back facing the edge, place a large container below it, remove the water drain plug to allow water to drain, and reinsert the water drain plug once draining stops.

Question 8

What does it mean when the Power and Ice icons are flashing?

Accepted Answer

Flashing Power and Ice icons indicate that either the ambient or water temperature is too high, or there may be refrigerant liquid leakage. Try operating the ice maker in an environment below 90°F and use colder water in the reservoir, or press the 'Ice' button to power off and restart the unit. If the issue persists, consult a qualified technician.

Question 9

How much ice can this machine produce per day?

Accepted Answer

The Frigidaire Nugget Ice Maker is capable of producing up to 44 lbs. of ice per day.

Question 10

Do I need a direct water line hookup for this ice maker?

Accepted Answer

No, the ice maker has a built-in water reservoir that you simply fill with clean, potable water, so it does not require a direct water line hookup to produce ice.

Question 11

What electrical outlet do I need for this ice maker?

Accepted Answer

The Frigidaire Nugget Ice Maker requires a 15 AMP, 110-115 VOLT, 60 Hz grounded outlet. The appliance is equipped with a 3-wire cord having a grounding plug that must be plugged into a properly installed and grounded outlet.

Question 12

How much ice can this machine produce in a day?

Accepted Answer

The Frigidaire Nugget Ice Maker is capable of producing up to 44 lbs. of ice per day, with the first batch ready in approximately 10-15 minutes after starting the ice-making process.

Question 13

What should I do if the 'Add Water' indicator keeps lighting up?

Accepted Answer

First, stop the ice maker and fill the water reservoir with water, then press the 'Ice/Clean' button to restart. If the problem persists, check that the internal water tank baffle is installed correctly, or consult a qualified technician if you suspect water pump failure.

Question 14

What should I do before cleaning or performing maintenance on the ice maker?

Accepted Answer

Before performing any maintenance or cleaning, you must unplug the appliance or disconnect it from the power supply to minimize the risk of electric shock.

Question 15

How long do I need to wait before plugging in my new Frigidaire Nugget Ice Maker?

Accepted Answer

You should allow the refrigerant fluid to settle for at least one hour before plugging in the unit. This is an important step during the initial setup to ensure proper operation of the appliance.

Question 16

Can I use an extension cord with this ice maker?

Accepted Answer

Extension cords should be avoided as they may overheat and pose a fire risk. If absolutely necessary, use only 3-wire extension cords with a 3-blade grounding plug, ensuring the extension cord's rating is equal to or greater than the appliance's rating.

Question 17

Do I need a water line connection for this ice maker?

Accepted Answer

No, the ice maker has a built-in water reservoir that you simply fill with clean, potable water. The unit will produce ice without the need for a direct water hookup or permanent water line connection.

Question 18

How often should I change the water in the reservoir?

Accepted Answer

You should change the water in the water reservoir every 24 hours to maintain hygiene and ensure optimal ice quality.

Question 19

Why are the Power and Ice icons flashing on my ice maker?

Accepted Answer

Flashing Power and Ice icons typically indicate that the ambient or water temperature is too high, or there may be refrigerant liquid leakage. Try operating the ice maker in an environment below 90°F and use colder water in the reservoir. If the problem persists, power off and restart the unit, or consult a qualified technician.

Question 20

How do I clean the ice maker for the first time?

Accepted Answer

Before first use, press the 'Clean' button on the control panel to initiate the cleaning process, which takes about 20 minutes. After cleaning, place the ice maker on the edge of a countertop, position a large container below it, remove the water drain plug to allow water to drain, and then reinsert the plug once drainage stops.

Question 21

What should I do before using my ice maker for the first time?

Accepted Answer

Before first use, remove all exterior and interior packaging, clean the interior with lukewarm water and a soft cloth, and allow the refrigerant fluid to settle for at least an hour before plugging in. It is also recommended to run the cleaning procedure before first use. (Page 1 — Operating Procedures & Maintenance)

Question 22

What does the 'Add Water' indicator mean and how do I fix it?

Accepted Answer

The 'Add Water' indicator lights up when there is a lack of water in the reservoir, the internal water tank baffle is not installed correctly, or there is a water pump failure. To fix it, stop the ice maker, fill the reservoir with water, and press the 'Ice/Clean' button again to restart the unit. If the issue persists, consult a qualified technician. (Page 1 — Troubleshooting Guide)

Question 23

What are the dimensions of this ice maker and where should I place it?

Accepted Answer

The ice maker dimensions are 16.5 inches in height, 14.6 inches in depth, and 10 inches in width. You should place it on a level countertop away from direct sunlight and heat sources. (Page 1 — Operating Procedures & Maintenance)

Question 24

What electrical outlet do I need to plug the Frigidaire Nugget Ice Maker into?

Accepted Answer

The appliance must be plugged into a 15 AMP, 110-115 VOLT, 60 Hz grounded outlet. The appliance is equipped with a 3-wire cord having a grounding plug, and the plug must be plugged into an outlet that is properly installed and grounded. (Page 1 — Operating Procedures & Maintenance)

Question 25

Do I need a water hookup for this ice maker?

Accepted Answer

No, the ice maker has a built-in water reservoir. Simply fill it with clean, potable water, and the unit will produce ice without the need for a direct water line. (Page 1 — FAQ)

Question 26

What should I do if the 'Ice Full' indicator is lit but there is no ice inside?

Accepted Answer

If no ice is present when the 'Ice Full' indicator is lit, check for obstructions or clean the interior walls of the ice storage. You can then press the 'Ice' button for 5 seconds to resume ice-making for 80 minutes. (Page 1 — Troubleshooting Guide)
