LG AI Inverter Direct Drive WM3988HWA Washing Machine

Washer/Dryer Combo

Wm3988Hwa

Full Size All-In-One SteamWasher™and Dryer Combo Performance

Largest Capacity Front Load Combo (4.2 cu.ft. IEC)

with NeveRust™Stainless Steel Drum

Direct Drive Motor for the ultimate in durability

and reliability

TilTub™is designed with a 10° tilt for easy reach

of clothing in the rear of the drum

1320 RPM powerful spin for efficient water

extraction

SteamWash™System for Better Washing Performance

and Higher Water and Energy Efficiency

Allergiene™Cycle

SteamFresh™Cycle for Reducing Wrinkles

and Refreshing Clothes

TrueSteam™Generator

Ventless Condensing Drying System

Intelligent Fabric Care

SenseClean™& Sensor Dry System for intelligent

fabric care, water and energy efficiency

9 Washing Programs

5 Wash/Dry Programs

5 Wash/Rinse Temperature Levels

RollerJets™& Forced Water Circulation

Sanitary Cycle / Stain Cycle

Delay Wash by 19 hours for washing convenience

Style and Design

Upfront Electronic Control Panel with Dial-A-Cycle™

Large Chrome Rimmed Door with Clear Glass

Porcelain Top

Optional Drawer Pedestal

Environmentally Friendly

LoDecibel™Quiet Operation

Highly Energy and Water Efficient

Among full-size front load washers. For details, visit: www.energystar.gov White

W M 3 9 8 8 H W A

L G u s a . c o m

L A U N D R Y

LG front load washers exceed Energy Star® classifications by a minimum of 39%. NSF certifies the SANITARY course which is intended for reducing 99.9% of bacteria and other harmful microscopic organisms on laundry.

Printed in February 2008 SS-5007

Wm3988Hwa

Type

Front Loader  Design Look Front Control Intelligent Electronic Controls with Dial-A-Cycle™  Drying System Ventless Condensing

Capacity

Total Capacity* 4.2 cu.ft. (IEC) Dry Linen Capacity >10.1kg

Energy

Energy Star

Programs

9 Wash Programs SteamFresh™, Sanitary (158°F), Bulky/Large, Perm Press, Cotton/Normal, Delicates, Hand Wash/Wool, Speed Wash, Allergiene™ 5 Wash/Dry Programs Sanitary, Perm Press, Cotton/Normal, Allergiene™, Speed Wash 5 Wash/Rinse Temperature Levels Extra Hot/Cold, Hot/Cold, Warm/Warm, Warm/Cold, Cold/Cold 5 Spin Speeds Extra High (1320 RPM Max), High (1150/1000 RPM), Medium (1000/950/600 RPM), Low (950/600/400 RPM), No Spin 4 Dry Times 120 min, 90 min, 60 min, 30 min No. of Water Levels Automatically adjusts to size of load No. of Soil Levels 5 Options Prewash, Rinse & Spin, Extra Rinse, Stain Cycle, Water Plus, Drum Light, Tub Clean, SpinSense™, Delay Wash up to 19 Hours, Steam, Language Selection

Fabric Care Features

SteamWash™System  SenseClean™  Sensor Dry  RollerJets™& Forced Water Circulation

Convenience Features

4 Tray Dispenser Prewash, Main Wash (with liquid detergent cup), Bleach, Softener End of Cycle Beeper  Child Lock  Self Diagnosis  Tub Light White LED Auto-Balancing  Auto Suds Removal  Forced Drain System  Remaining Time Display/Status Indicator  Water Heater  TrueSteam™Generator  Leveling Legs 4 Adjustable LoDecibel™Quiet Operation

Motor And Agitator

Motor Type / Motor Speed / Axis Direct Drive / Variable / Horizontal

Materials And Finishes

NeveRust™Stainless Steel Drum  Easy Loading TilTub™  Cabinet Top Porcelain Transparent Glass Window Door  Door Rim Chrome Cabinet Painted Steel Control Panel Plastic Colors White

Power Source

Ratings/Electrical Requirements UL Listed/120V, 60Hz, 12 Amps Type Electric

Dimensions

Product (WxHxD) 27" x 38 11/16" x 29 3/4" (51"D with door open) Weight (lbs): Net / Gross 201 / 227

Options

Pedestal WDP3W (Drawer with Handle)

Warranty

1 year parts and labor 2 years on the control board 7 years on the motor Lifetime on the drum

Upc Code

Wm3988Hwa

048231 009560

Wdp3W

048231 008556 Design and specifications are subject to change without notice. ©2008 LG Electronics U.S.A., Inc., Englewood Cliffs, NJ All Rights Reserved. LG Design and Life's Good are trademarks of LG Electronics Inc. ASTHMA AND ALLERGY FRIENDLY and ASTHMA AND ALLERGY FRIENDLY LOGO are Certification Marks and Trademarks of ALLERGY STANDARDS LIMITED. The ASTHMA AND ALLERGY FOUNDATION OF AMERICA is a Registered Trademark of AAFA. All other trademarks are property of their respective owners.

Per IEC 60456 washes the equivalent of 4.2 cu.ft.

conventional agitator washer.

Washer/Dryer Combo

Lg Electronics Inc.

1000 Sylvan Ave., Englewood Cliffs, NJ 07632 800.243.0000 LGusa.com Full Size All-in-One Washer and Dryer SteamFresh™ LG's innovative SteamFresh™cycle makes it possible for you to refresh and reduce wrinkles in up to 5 garments at one time. Running late for work with no time to iron? Load a cotton blend shirt into the SteamWasher™and select the SteamFresh™cycle. You'll be ready to go in just 20 minutes. Allergiene™ Allergiene™cycle is proven to reduce certain allergens such as house dust mites and domestic animal dander. Intelligent Electronic Controls with Blue LCD Display Intuitive controls allow you to 'set it and go'. The large LCD display provides instructions and diagnostics while keeping you updated on the cycle status and time remaining. Direct Drive Power is delivered right to the drum from the motor without belts, resulting in a highly durable, powerful and quiet washing machine. SenseClean™System The water level and wash time are set automatically based on the weight and size of each load for optimal washing care. RollerJets™& Forced Water Circulation Clothes glide over the RollerJets™while sprinklers encourage the removal of soil, reducing pilling, fraying, and snags for longer lasting clothing. Sanitary Cycle Get tough stains and bacteria out of dirty clothes with this special cycle that boosts water to 158°F. LoDecibel™Quiet System Anti-vibration motor and one-piece cabinet structure reduce unnecessary noises.
