What dryer programs are available on the WKHC252H_A dryer?

The dryer offers 6 programs: Normal, Bedding, Delicates, Heavy Duty, Small Load, and Downloaded. Drying levels include Very, More, Normal, Less, and Damp, with manual dry times available from 30 to 70 minutes in 10-minute increments. (Page 1)

2

Does the WKHC252H_A qualify for ENERGY STAR certification?

Yes, both the washer and dryer are ENERGY STAR® certified, and the washer is also designated as ENERGY STAR® Most Efficient. The washer holds a CEE Tier 2 rating and the dryer has a Combined Energy Factor (CEF) of 9.0. (Page 1)

3

What is the warranty coverage for the WKHC252H_A?

Parts and labor are covered for 1 year for both the washer and dryer. The Direct Drive Motor on the washer carries a 10-year limited warranty, the drum is covered for 3 years on both units, and the Inverter Compressor and Motor on the dryer carries a 10-year limited warranty. (Page 1)

4

Does the WKHC252H_A support Wi-Fi and smart home features?

Yes, both the washer and dryer support Wi-Fi connectivity and ThinQ® Smart Technology, including Remote Start/Cycle Monitor, Energy Monitoring, and Smart Diagnosis (v3.0). The unit also supports ThinQ UP™ and ThinQ Care™ for additional smart features. (Page 1)

5

What are the dimensions and weight of the WKHC252H_A WashTower?

The product dimensions are 27" x 74 3/8" x 32 3/4" (W x H x D), with a depth of 57 1/2" when the door is open. The product weighs 353.0 lbs and the carton weighs 380.0 lbs. (Page 1)

6

What lint and condenser maintenance features does the WKHC252H_A dryer have?

The dryer features a 3-Stage Lint Filter and an Auto Cleaning Condenser™ to help maintain dryer performance. There is also a Condenser Care option available in the dryer's options menu. (Page 1)

Show 48 more questions

What fabric care features are included in the washer?

What are the capacity specifications for the WKHC252H_A washer and dryer?

What electrical requirements does the WKHC252H_A need for installation?

What wash programs are available on this washing machine?

What dryer programs are available on this model?

What warranty coverage does the WKHC252H_A have?

What are the spin speed options for the washer?

What are the physical dimensions and weight of the WKHC252H_A?

What smart technology features does the WKHC252H_A include?

What is the washer and dryer capacity of the WKHC252H_A WashTower?

What type of dryer technology does the WKHC252H_A use?

What are the electrical requirements for the WKHC252H_A?

What wash programs are available on the WKHC252H_A washer?

What dry programs are available on the WKHC252H_A dryer?

What is the warranty coverage for the WKHC252H_A WashTower?

Does the WKHC252H_A support smart home or Wi-Fi connectivity?

What wash temperatures and spin speeds are available on the washer?

Does the WKHC252H_A have a lint filter, and how is the condenser maintained?

Is the WKHC252H_A ENERGY STAR certified, and what colors is it available in?

What is the water capacity of the washer in the LG WKHC252H_A?

What are the electrical requirements for installing this washing machine?

What dryer capacity does the WKHC252H_A have?

How long is the warranty on the Direct Drive Motor?

What temperature options are available for washing?

What spin speed options does the washer have?

What are the dimensions of the WKHC252H_A?

What wash programs are available on the washer?

Is this unit ENERGY STAR certified?

What is the weight of the WKHC252H_A?

What is the warranty coverage on the motors?

What electrical requirements does this washer-dryer unit need?

Does this unit have smart home connectivity?

Can I lock the controls to prevent accidental operation?

What are the dimensions of the LG WKHC252H_A washing machine and how much space do I need?

What wash temperature options are available on this washer?

How much does the unit weigh and what's included in the box?

How often should I clean the condenser on the dryer?

What drum capacity does this washing machine have?

What special wash cycles are available for sensitive fabrics?

What wash temperature options are available?

What colors are available for this washing machine?

How long is the warranty coverage for the motor and drum?

What wash programs are available on this machine?

What is the capacity of the washer and dryer?

What are the available drying levels?

What are the electrical requirements for this washer/dryer combo?

What smart features does this washing machine have?

Does this machine have an auto-cleaning feature for maintenance?

Full Manual

1 pages
Page 1

Lg Laundry

Home Appliances

© 2023 LG Electronics USA, Inc. All rights reserved. "LG Life’s Good" is a registered trademark of LG Corp. All other product and brand names are trademarks or registered trademarks of their respective owners. Design, features and specifications are subject to change without notice. Non-metric weights and measurements are approximate. Some features may require Internet access. Content and services may vary by product and are subject to change without notice. 1/9/24

Key Features

Product Features

Summary

Washer Dryer Type Single Unit Front Load Washer and Dryer Vent Type
  • Ventless
  • Dryer Type
  • Heat Pump
  • Capacity (cu. ft.) Washer 5.0 cu. ft. / Dryer 7.8 cu. ft. Color Black Steel (B), White (W)

    Appearance

    Washer Dryer Touch Buttons Yes Full Touch Electronic Control Panel with LED Display Yes Center Control® Yes

    Energy

    Washer Dryer ENERGY STAR® Most Efficient Yes ENERGY STAR® Certified Yes Yes CEE Tier Tier2
  • Imef

  • 2.92
  • Iwf

  • 2.9
  • Cef

  • 9.0
  • Programs

    Washer Dryer No. of Programs 6 6 Wash Programs Normal, Bedding, Delicates, Heavy Duty, Quick Wash, Downloaded Normal, Bedding Delicates, Heavy Duty, Small Load, Downloaded

    Options

    Washer Dryer No. of Options 9 8 Options TurboWash®, Steam, Extra Rinse, Pre-wash, Tub Clean*, Drum Light*, Control Lock* Signal*, Wi-Fi* / Remote Start* Wrinkle Care, More Time, Less Time Condenser Care, Drum Light*, Control Lock*, Signal*, Wi-Fi* / Remote Start*

    Details

    Washer Dryer No. of Wash/Rinse Temps 5
  • Wash/Rinse Temps
  • Hot, Very Warm, Warm, Cool, Cold
  • No. of Spin Speeds
  • 5
  • Spin Speeds
  • High, Medium/ High, Medium, Low, No Spin
  • Max RPM
  • 1300
  • Water Levels
  • Load Sensing
  • No. of Soil Levels
  • 5
  • Drying Levels
  • Very, More, Normal,
  • Less, Damp Dry Mode
  • Energy Saver,
  • Normal, Speed Manual Dry Times
  • 30 - 70 mins.
  • (10 min. increments)

    Fabric Care Features

    Washer Dryer

    Ai Dd®

    Yes
  • TurboWash® 360 Technology
  • Yes
  • Steam Technology
  • Yes
  • Allergiene® Cycle
  • Yes
  • Sanitary Cycle
  • Yes
  • AI Sensor Dry
  • Yes
  • AI Sensor Dry 2.0 (with IR Sensor)
  • Yes
  • 6 Motion Dry
  • Yes
  • Sensor Dry
  • Yes
  • Precise Temperature Control with Variable Compressor
  • Yes
  • Convenience Features

    Washer Dryer TrueBalance® Anti-Vibration System Yes
  • 4 Tray Dispenser
  • Prewash, Main Wash (with liquid detergent cup), Bleach, Fabric Softener
  • End of Cycle Signal
  • Yes
  • LoadSense
  • Yes
  • Control Lock
  • Yes
  • Auto Suds Removal
  • Yes
  • Leveling Legs
  • 4 Adjustable Legs
  • Drum Light
  • Yes
  • Remaining Time Display/Status
  • Indicator(s) Yes
  • End of Cycle Signal
  • Yes
  • Drum Light
  • Yes
  • Wrinkle Care Option
  • Yes
  • Control Lock
  • Yes
  • Venting Option
  • 4 Adjustable Legs
  • Yes
  • Remaining Time Display/Status Indicator(s)
  • Yes
  • Lint Filter
  • Yes
  • Auto Cleaning Condensor
  • Yes
  • ThinQ® TECHNOLOGY Washer Dryer Smart Diagnosis (v3.0) Yes Yes Wi-Fi Yes Yes ThinQ Up Yes Yes Remote Start/Cycle Monitor Yes Yes Energy Monitoring Yes Yes Tub Clean Coach Yes
  • Motor And Agitator

  • Washer Dryer Motor Type Inverter Direct Drive Motor Axis Horizontal

    Materials And Finishes

    Washer Dryer NeveRust® Stainless Steel Drum Yes Yes Aluminized Alloy Steel Drum
  • No
  • Control Panel Plastic Top Plate Steel Cabinet Painted Steel Door / Rim Large Circle Chrome Rim Door Cover Tinted Round Tempered Glass All Available Colors Black Steel (B), White (W)

    Certification

    Washer Dryer

    Aafa

    Yes No

    Power Source

    Washer Dryer Ratings CSA Listed
  • Electrical Requirements
  • 120V, 10 Amps 240V, 830W or

    208V, 820W

    15 Amp Circuit Type Electric Heat Pump BTU Rating
  • Heat Pump : N/A
  • Options/Accessories

    Washer Dryer LP Conversion Kit
  • N/A

  • Dimensions

    Product (WxHxD) 27” x 74 3/8” × 32 3/4” Depth with Door Open 57 1/2” Carton (WxHxD) 29 1/4” x 77 1/2” x 33 1/4” Weight (Product/Carton) 353.0 Ibs / 380.0 Ibs

    Limited Warranty

    Washer Dryer Parts and Labor 1 Year 1 Year Direct Drive Motor 10 Years
  • Drum
  • 3 Years 3 Years Inverter Compressor & Motor
  • 10 Years
  • Upc Codes

    WKHC252HBA (Black Steel) 195174072370 WKHC252HWA (White) 195174072318 black steel

    Available Colors

    white

    Wkhc252H_A

    Single Unit LG WashTower™ with Center Control™ 5.0 cu. ft. Front Load Washer and 7.8 cu. ft. Electric Ventless Heat Pump Dryer Mega Capacity 5.0 cu. ft. Washer and 7.8 cu. ft. Dryer Single Unit WashTower™ Design Dual Inverter HeatPump™ Technology & Inverter Direct Drive Motor System Built-In Intelligence: AI Fabric Sensor / Infrared Sensor / Smart Pairing™ Advanced Washing: TurboWash® 360° and Allergiene® Wash Cycle Auto Cleaning Condenser™ & 3-Stage Lint Filter ThinQ® Smart Technology & ThinQ UP™ & ThinQ Care™ Tempered Glass Doors Direct Drive Motor (Washer and Dryer) & Inverter Compressor Motor (Dryer) 10-Year Limited Warranty on Direct Drive Motor (Washer and Dryer) & Inverter Compressor Motor (Dryer) Most Efficient ENERGY STAR® Washer and ENERGY STAR® Certified Dryer
