Craftsman Lawn Mower Model 917

What are the specifications for the Craftsman Model 917 lawn mower?

The Craftsman 917.387210 is a 4.0 horsepower, 22-inch side discharge rotary lawn mower with a 9.05 cubic inch engine displacement. It has a fuel capacity of 1.25 quarts of unleaded regular gasoline and an oil capacity of 20 ounces. The mower features adjustable cutting height and an operator presence control bar for enhanced safety.

How do I assemble and unfold the handle on my Craftsman Model 917?

Start by removing the handle padding holding the operator presence control bar to the upper handle. Raise the handles until the lower handle section locks into the mowing position. Then raise the upper handle section into place on the lower handle and tighten the handle knob. Finally, discard the protective handle pads placed between the upper and lower sections.

What type of oil and spark plug does the Craftsman 917 require?

The Craftsman 917 requires SAE 30 oil for temperatures above 32°F, or SAE 5W-30 for temperatures below 32°F. For the spark plug, use a Champion J19LM with a .030″ gap. The oil capacity is 20 ounces.

How do I start the engine on my Craftsman Model 917 lawn mower?

Ensure the operator presence control bar is engaged before starting. Pull the starter rope handle slowly until resistance is felt, then pull rapidly to start the engine. Always keep the operator presence control bar engaged while mowing.

What maintenance should I perform before each use of the Craftsman 917?

Before each use, check the engine oil level to ensure it is at the proper level. Inspect the mower for any loose fasteners and tighten them if necessary. These pre-operation checks help ensure safe and efficient mowing.

How do I troubleshoot if my Craftsman Model 917 engine fails to start?

If the engine fails to start, first ensure the operator presence control bar is engaged, as the engine requires this for operation. Check that the fuel level is adequate and the fuel is of good quality. Finally, inspect the spark plug for wear or damage and replace if necessary.
