1

What type of electrical connection does the Kenmore 110.60942990 dryer require?

The dryer requires a three-wire or four-wire, single phase, 120/240-volt, 60-Hz., AC-only electrical supply on a separate 30-ampere circuit, fused on both sides of the line. A time-delay fuse or circuit breaker is recommended. Do not use an extension cord with this dryer. (Page 14)

2

What should I do if my dryer runs but produces no heat?

A blown fuse or tripped circuit breaker on one side of the line can cause the dryer to appear to operate without producing heat. Replace the fuse or reset the circuit breaker to resolve this issue. (Page 43)

3

What type of exhaust vent material is required for this dryer?

The dryer must use a 4-inch heavy metal vent or flexible metal vent — do not use a plastic vent or a metal foil vent, as these create a fire hazard. Using a plastic vent may also void the dryer's warranty. All installations must be exhausted outdoors. (Pages 4, 25)

4

What is the minimum room temperature required for the dryer to operate properly?

Proper operation of dryer cycles requires temperatures above 45°F. At lower temperatures, the dryer may not shut off at the end of automatic cycles and drying times will be extended. This applies to standard, closet, and mobile home installations. (Page 10)

5

What is the Wrinkle Guard feature and how does it work?

Wrinkle Guard helps keep permanent press items wrinkle-free if you don't unload the dryer promptly at the end of an automatic cycle. If the door is not opened, it will tumble clothes without heat periodically — for about 30 minutes on Wrinkle Guard I, 40 minutes on Wrinkle Guard II, and approximately 2.5 hours on Wrinkle Guard III. (Page 35)

6

What items should never be placed in the dryer?

Do not dry articles previously cleaned in, soaked in, or spotted with gasoline, dry-cleaning solvents, or other flammable substances, as the vapors could ignite or explode. Items contaminated with cooking oils or containing foam rubber, rubber-like materials should not be dried with heat, as these pose a fire hazard. (Pages 6, 31)

Show 22 more questions

Full Manual

47 pages
Page 1

This Owner's Manual is provided and hosted by Appliance Factory Parts. Kenmore 110.60942990 Owner's Manual Shop genuine replacement parts for Kenmore 110.60942990 Find Your Kenmore Dryer Parts - Select From 92 Models -------- Manual continues below --------

Page 2

Owner's Manual and Installation Instructions ® 27-Inch Wide

Electric

Dryers

m rm. m rt

Important:

Read and follow all safety and operating instructions before first use of this product. Your dryer may look different from the dryer shown. Sears, Roebuck and Co., Hoffman Estates,

Il 60179

U.S.A.

www.sears.com

3405602A

Printed

In Us.A

8/99

Page 3

Before

Using Your New Dryer

Kenmore

Electric

Dryer Warranty

Dryer Safety

Installation

Instructions

Operating

Your Dryer

Laundry Tips

Caring

Foryour

Dryer

Troubleshooting

Sears

Maintenance

Agreement

2 3 4 6 30 37 39 43 45 Please read this manual. It will help you install and operate your new Kenmore dryer in the safest and most economical way. If you need more information about the care and operation of Kenmore appliances call your nearest Sears store. You will need the complete model and serial numbers when requesting information. Your dryer's model and serial numbers are located on the Model and Serial Number Plate. Use the space below to record the model number and serial number of your new Kenmore dryer. Model No. Serial No. Date of Purchase Keep this book and your Sears Salescheck (receipt) in a safe place for future reference.

Page 4

Full One Year Warranty on Mechanical and Electrical Parts For one year from the date of purchase, if this dryer is installed and operated according to the instructions in this manu- al, Sears will repair or replace any of its mechanical or electrical parts if they are defective in material or workmanship.

Note:

Exhausting your dryer with a plastic vent may void this warranty. Pages 24-28 of this manual describe the complete exhaust requirements for this dryer. Warranty Restriction If the dryer is subjected to other than private family use, all warranty coverage is effective for only 90 days. Warranty Service Warranty service is available by contacting your nearest Sears Service Center in the United States. This warranty applies only while this dryer is in use in the United States. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. Sears, Roebuck and Co., Dept.

817Wa,

Hoffman Estates,

Il

  • For Sears Warranty
  • information or to contact a Sears Service Center, call 1-800-4-MY-HOME sM (1-800-469-4663)

    Page 5

    Your safety and the safety of others is very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the safety alert symbol. This symbol alerts you to hazards that can kill or hurt you and others. All safety messages will be preceded by the safety alert symbol and the word

    "Danger"

    or "WARNING." These words mean: You wil__lbe killed or seriously injured if you don't follow instructions. You can be killed or seriously injured if you don't follow instructions. All safety messages will identify the hazard, tell you how to reduce the chance of injury, and tell you what can happen if the instructions are not followed.

    Page 6

    Important

    Safety

    Instructions

    Warning

    : To reduce the risk of fire, electric shock, or injury to persons when using the dryer, follow basic precautions, including the following:
  • Read
  • all instructions before using the dryer.
  • Do not place
  • items exposed to cook- ing oils in your dryer. Items contami- nated with cooking oils may contribute to a chemical reaction that could cause a load to catch fire.
  • Do not dry
  • articles that have been pre- viously cleaned in, washed in, soaked in, or spotted with gasoline, dry- cleaning solvents, other flammable, or explosive substances as they give off vapors that could ignite or explode.
  • Do not allow
  • children to play on or in the dryer. Close supervision of children is necessary when the dryer is used near children.
  • Before
  • the dryer is removed from service or discarded, remove the door to the drying compartment.
  • Do not reach
  • into the dryer if the drum is moving.
  • Do not
  • install or store the dryer where it will be exposed to the weather.
  • Do not tamper
  • with controls.
  • Do
  • not repair or replace any part of the dryer or attempt any servicing unless specifically recommended in this Owner's Manual or in published user-repair instructions that you understand and have the skills to carry out.
  • Do not
  • use fabric softeners or products to eliminate static unless recommended by the manufacturer of the fabric softener or product.
  • Do
  • not use heat to dry articles containing foam rubber or similarly textured rubber-like materials.
  • Clean
  • lint screen before or after each load.
  • Keep
  • area around the exhaust opening and adjacent surrounding areas free from the accumulation of lint, dust, and dirt.
  • The
  • interior of the dryer and exhaust vent should be cleaned periodically by qualified service personnel.
  • See the
  • "Installation

    Instructions"

    section for grounding requirements.

    Save

    These

    Instructions

    Page 7

    Installation

    Overview

    For a complete list of tools and parts needed, see pages 6-8.

    A. Select

    Location

    Foryour

    Dryer

    (pgs. 9-11) Standard Installation (p. 9) Recessed Area/Closet Installation Instructions (p. 10)

    B. Install

    Leveling

    LEGS (p. 12) Tools Needed: wrench Two corner Flashlight (optional posts (from depending on dryer carton) installation) Parts Needed: (supplied with dryer) 4 ieveIing iegs

    Page 8

    C.Make

    Electrical

    Connection

    (pgs. 13-23) If using a power cord: Tools Needed: X-inch nut #2 Phillips head driver (shown) screwdriver or socket wrench Flashlight (optional depending on installation) Parts Needed: _rain relief New 3- or 4-wire, 30-amp., U.L.-listed power supply cord kit (includes strain relief) If making a direct wire connection: Tools Needed: Parts Needed: X-inch nut #2 Phillips head driver (shown) screwdriver or socket wrench Wire stripper Flashlight (optional depending on installation) lO-gauge, 3- or 4-wire, flexible armored or nonmetallic sheathed copper cable (with grounding wire). @ X-inch, U.L.-listed strain relief

    Page 9

    D, Connect

    Exhaust

    (pgs. 24-28) Tools Needed: Parts Needed: Tin snips Duct tape Flashlight (optional depending on installation) Flat-bladed screwdriver 4-inch heavy or flexible metal vent 4-inch outlet exhaust hood 4-inch metal elbow(s) (optional depending on installation) Cbd

    O

    (4) 4-inch diameter clamps

    Page 10

    A. Select

    Location

    For

    Your Dryer

    .i'{,Jal_{,J_Ja"Iq iIq i'14 Selecting the proper location for your dryer makes installation easy and gives you the best drying perfor- mance.

    Standard

    Installation

    Check location where dryer will be in- stalled. Proper installation is your respon- sibility. Make sure you have everything necessary for correct installation (see il- lustration below). The dryer must not be installed where it can be exposed to water and/or weather.
  • Proper
  • operation of dryer cycles requires temperatures above

    45°F

    (at lower temperatures, the dryer may not shut off at the end of automatic cycles and drying times will be extended). Explosion Hazard Keep flammable materials and vapors, such as gasoline, away from dryer. Place dryer at least 18 inches (46 cm) above the floor for a garage installation. Failure to do so can result in death, explosion, or fire. Check code requirements. Some codes limit or do not permit installation of clothes dryers in garages, closets, mobile homes, or sleeping quarters. Contact your local building inspector.

    Z

    Support: Floor must be Level floor: Maximum allow- able slope under sturdy enough to support entire dryer - 1 inch. a total weight of 175 pounds (includes dryer and load weight).

    Page 11

    Dryer Dimensions

    Most installations will require at least 5-inch clearance behind the dryer for the dryer vent. Location must be large enough to fully open dryer door.

    Recessed

    Area/Closet

    Installation

    Instructions

    Check governing codes and ordinances. This dryer may be installed in a recessed area or closet. The dryer must not be installed where it can be exposed to water and/or weather.
  • Proper
  • operation of dryer cycles requires temperatures above

    45°F

    (at lower temperatures, the dryer may not shut off at the end of automatic cycles and drying times will be extended).
  • Check
  • code requirements. Some codes limit or do not permit installation of clothes dryers in garages, closets, mobile homes, or sleeping quarters. Contact your local building inspector.

    Warning:

    To reduce the risk of fire, this appliance

    Must

    Be

    Exhausted

    Outdoors.

    Note:

    No fuel-burning appliances may be installed in the same closet as a dryer.

    I

    °1° t FrontView (DoorNotShown)

    Minimum

    Installation

    Spacing

    1"

    I

    SideView (DoorShown) **48sq. in_. minimum ventilation area 3" 3" FrontView (DoorWithVent)
  • Additional clearances for wall, doorand floor moldings may be required. 0" clearance
  • is acceptable but notrecommended. ** Opening is minimum for closet door. Louvered doorwith equivalent air openings is acceptable. *** Additional space is needed when external exhaust elbow is used. Can be 0" clearance when house exhausting is lined updirectly with dryer exhaust.
  • in the above
  • illustration, the installation spacing is in inches and is the minimum allowable.
  • Additional
  • spacing should be considered for ease of installation and servicing.
  • If closet
  • door is installed, the minimum air openings in top and bottom are

    I0

    required. Louvered doors with equivalent air openings in top and bottom are acceptable.
  • All installations
  • must be exhausted outside. Use at least the minimum dimensions indicated.

    Page 12

    Mobile

    Home

    Exhaust

    Requirements

    The dryer must not be installed where it can be exposed to water and/or weather. Proper operation of dryer cycles requires temperatures above

    45°F

    (at lower temperatures, the dryer may not shut off at the end of automatic cycles and drying times will be extended). This dryer is suitable for mobile home installations. The installation must conform to the Manufactured Home Construction and Safety Standard, Title

    24 Cfr,

    Part 3280 (formerly the Federal Standard for Mobile Homes Construction and Safety, Title

    24, Hud

    Part 280). Dryer exhaust vent must not be connected or secured with screws or other devices which extend into the interior of the vent. The exhaust vent must be securely fastened to a noncombustible portion of the mobile home structure and must not terminate beneath the mobile home.

    I1

    Page 13

    B. Install Leveling

    Legs

    Leveling your dryer correctly will reduce operating noise and provide improved drying performance.

    Step

  • Start
  • to screw the legs into the holes by hand. Use a wrench to finish turning the legs until diamond marking is no longer visible. This is when we recommend you start checking the dryer for levelness. Further adjustment may be necessary. Excessive Weight Hazard Use two or more people to move and install dryer. Failure to do so can result in back or other injury.

    Step

  • Take two
  • of the cardboard corners from the carton. Place them on the floor in back of the dryer.

    Step

  • Firmly
  • grasp the body of the dryer (not the top or console panel). Gently lay dryer on the cardboard corners.

    Step

  • Stand
  • the dryer up and move it close to its final location. Leave enough room to connect the exhaust vent.

    Step

  • Check
  • levelness of dryer by placing a level on top of the dryer, first side-to-side; then front-to-back.

    Step

  • With
  • one of the legs in hand, check the ridges for a diamond marking.

    Step

  • If dryer
  • is not level, prop the dry- er up using two stacked cardboard cor- ner posts. Use a wrench to adjust the legs up or down.

    I2

    Note:

    It may be necessary to level the dryer again after it is moved into its final position.

    Page 14

    C.Make

    Electrical

    Connection

    It is your responsibility:
  • To contact
  • a qualified electrical installer.
  • To assure
  • that the electrical installation is adequate and in conformance with the National Electrical Code,

    Ansi/Nfpa

    70 - latest edition and all local codes and ordinances. Copies of the code standards listed above may be obtained from: National Fire Protection Association Batterymarch Park Quincy, Massachusetts 02269

    Electrical

    Requirements

    OrteJiirj'e_m

    "I_

    i[_ _,,, The proper electrical connection ensures a safe installation that meets local code requirements. A three-wire or four-wire, single phase, 120/240-volt, 60-Hz., AC-only, electrical supply (or three-wire or four-wire, 120/208-volt if specified on serial/rating plate) is required on a separate 30-ampere circuit, fused on both sides of the line. A time-delay fuse or circuit breaker is recommended. This dryer is manufactured with the 3-wire, frame-grounding conductor connected to the

    Neutral

    (white or center) of the wiring harness of the terminal block. Do not have a fuse in the neutral or grounding circuit. A fuse in the neutral or grounding circuit could result in an electrical shock. Use a 4-conductor cord when the dryer is installed in a mobile home or an area where local codes do not permit grounding through the neutral.

    Electrical

    Connection

    Options

    IfYeur Home Has: 3-wire electrical receptacle (NEMA Type 10-30R) And YouWill Be Go To Connecting To: Page A U.L.-listed, 120/240-volt minimum, 30-amp., dryer power supply cord.* 3-wire direct

    14-I.

    4-wire electrical receptacle (NEMA Type 14-30R) A fused disconnect or 16 -

    Ii.

    circuit breaker box.* A U.L.-listed, 120/240-volt minimum, 30-amp., dryer power supply cord.

    19- Iii.

    4-wire direct A fused disconnect or 22 -

    Iv.

    circuit breaker box. *if local codes do not permit the connection of a frame-grounding conductor to the neutral wire, see the instructions on page 18.

    I3

    Page 15

    I. Three-Wire

    Electrical

    Connection

    To Receptacle

    Use a 3-wire power supply cord: Fire Hazard Use a new UL approved 30 ampere power supply cord. Use a UL approved strain relief. Disconnect power before making electrical connections. Connect neutral wire (white or center wire) to center terminal (silver). Ground wire (green or bare wire) must be connected to green ground connector. Connect remaining 2 supply wires to remaining 2 terminals (gold). Securely tighten all electrical connections. Failure to do so can result in death, fire, or electrical shock. This blade connected to this conductor Neutral _ i.............. Local codes may permit the use of a U.L.-listed, 120/240-volt minimum, 30-ampere, dryer power supply cord kit (pigtail). Power supply cord should be type

    Srd

    or SRDT and be at least four feet long. The wires that connect to the dryer must end with ring terminals or spade terminals with upturned ends. Do not use an extension cord with this dryer. Do not connect plug end of power supply cord into a live receptacle before connecting power supply cord to dryer terminal block. The power supply cord must have three, No.-10 copper wires to match a three-wire receptacle of NEMA Type

    10-30R.

    Spade terminals with upturned ends (OR ring terminals) / Connect wire with ends iacing you Ring terminals (OR spade terminals) _-inch, U.L.-listed Neutral wire strain relief (white) Three-Wire Power Supply Cord

    I4

    Three-wire receptacle (NEMA TypelO-3OR)

    Page 16

    Grounding

    Instructions

    This appliance must be grounded. In the event of malfunction or breakdown, grounding will reduce the risk of electric shock by providing a _ath of least resistance for electric current. The power supply cord must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances.

    Warning:

    Improper connection of the equipment-grounding conductor can result in a risk of electric shock. Check with a qualified electrician or serviceman if your are in doubt as to whether the appliance is properly grounded. Do not modify the plug on the power supply cord. if it will not fit the outlet, have a proper outlet installed by a qualified electrician.

    Save These Instructions

    Step

  • Disconnect
  • power.

    Step

  • Remove
  • hold-down screw and terminal block cover. Hold-down screw

    Step

  • Attach
  • a _-inch, U.L.-listed, strain relief to the hole below terminal block opening. Strain relief should have a tight fit with dryer cabinet and be in a hor- izontal position. Put the power supply cord through the strain relief.

    Step

  • Loosen
  • or remove terminal block screws. Connect the neutral wire (white or center) of power supply cord under the center screw of the terminal block.

    Step

  • Connect
  • the other two wires to outer terminal block screws. Securely tighten all electrical connections. External ground connector Center silver-colored terminal block screw Neutral wire (white) Neutral grounding wire (green/yellow) _/4-Jnch, U.L.-listed strain relief 3-Wire Connection with Frame-Grounding Conductor Terminal block cover

    Step

  • Tighten
  • the strain relief screws.

    Step

  • Insert
  • tab of terminal block cover into slot of the dryer rear panel. Secure cover with hold-down screw. If local codes do not permit the connection of a frame-grounding conductor to the neutral wire, see the instructions on page 18. Otherwise, proceed with Installation on page 24.

    I5

    Page 17

    I1. Three-Wire

    Electrical

    Connection

    (Direct

    Wire)

    Prepare cable as directed: Fire Hazard Use 10 gauge solid copper wire. Use a UL approved strain relief. Disconnect power before making electrical connections. Connect neutral wire (white or center wire) to center terminal (silver). Ground wire (green or bare wire) must be connected to green ground connector. Connect remaining 2 supply wires to remaining 2 terminals (gold). Securely tighten all electrical connections. Failure to follow these instructions can result in death, fire, or electrical shock. The dryer can be connected directly to fused disconnect or circuit breaker box with three-wire, flexible armored or non- metaflic sheathed copper cable (with grounding wire). All current-carrying wires must be insulated. A conduit connector must be installed at junction box. Allow four feet of slack in the line so dryer can be moved if servicing is ever necessary.

    Grounding

    Instructions

    This appliance must be connected to a grounded metal, permanent wiring system; or an equipment-grounding conductor must be run with the circuit conductors and connected to the equipment-grounding terminal or lead on the appliance.

    Save

    These

    Instructions

    Step

  • Disconnect
  • power.

    Step

    la. Strip 3_ inches of outer covering from end of cable. If using 3-wire cable with grounding wire, cut the bare wire even with outer covering. • /_)......_m_m=

    I_

    31/2''_l

    Step

    lb. Cut 1 inch of insulation from the end of each insulated wire. Shape the end of each wire into a "U" shaped hook.

    I6

    Page 18

    STEP2.Remove hold-down screwand terminalblockcover. Hold-down screw \

    Step

    4a. Place the hook-shaped end of the wire over the terminal block screw. The open side of the hook should face to the right. Squeeze hook end of wire together to form a loop. Terminal block cover

    Step

  • Attach
  • a _-inch, U.L.-Iisted strain relief to the hole below terminal block opening. Strain relief should have a tight fit with dryer cabinet and be in a horizon- tal position. Put the direct wire cable through the strain relief.

    Step

  • Loosen
  • or remove terminal block screws. Connect the neutral wire (white or center) of direct wire cable under the cen- ter screw of the terminal block. External ground connector

    Step

  • Connect
  • the other two wires to outer terminal block screws using the same method(s) described in STEP 4a. Securely tighten all electrical connections.

    Step

  • Tighten
  • the strain relief screws.

    Step

  • insert
  • tab of terminal block cover into slot of the dryer rear panel. Secure cover with hold-down screw. If local codes do not permit the connection of a frame-grounding conductor to the neutral wire, see the instructions on page
  • Otherwise,
  • proceed with Installation on page
  • Center
  • silver-colored terminal block screw Neutral wire (white) Neutral grounding / wire (green/yellow) K-inch, U.L.-listed strain relief 3-Wire Connection with Direct Wire and Frame-Grounding Conductor

    I7

    Page 19

    Alternate

    Connection:

    If local codes do not permit the connection of a frame-grounding conductor to the neutral wire:

    Step

  • Disconnect
  • power.

    Step

  • Make
  • sure the power supply cord or direct wire cable is in place (see

    Steps

    1-3 on page 15 for power cord connections or STEPS 1-3 on pages 16-17 for direct wire connection).

    Step

  • Remove
  • the neutral grounding wire (green/yellow wire) from external grounding connector screw. Loosen or re- move terminal block screws. Connect neutral grounding wire and the neutral wire (white or center) of power supply cord or direct wire cable under the center screw of the terminal block.

    Step

  • Connect
  • the other two wires to outer terminal block screws. Securely tighten all electrical connections.

    Step

  • Tighten
  • the strain relief screws.

    Step

  • Insert
  • tab of terminal block cover into slot of the dryer rear panel. Secure cover with hold-down screw.

    Step

  • Connect
  • separate copper grounding wire from external ground con- nector to an adequate ground. If codes permit and a separate grounding wire is used, it is recommended that a qualified electrician determine that the grounding path is adequate. Proceed with Installation on page
  • External
  • ground conne_or \ \ Neutral grounding wire (green/yellow) Neutral wire (white) Grounding path determined by a qualified electrician =_= Alternate 3-Wire Connection with External-Grounding Conductor

    I8

    Page 20

    Iii. Make Four-Wire

    Electrical

    Connection

    To Receptacle

    Use a 4-wire power supply cord: Fire Hazard Use a new UL approved 30 ampere power supply cord. Use a UL approved strain relief. Disconnect power before making electrical connections. Connect neutral wire (white or center wire) to center terminal (silver). Ground wire (green or bare wire) must be connected to green ground connector. Connect remaining 2 supply wires to remaining 2 terminals (gold). Securely tighten all electrical connections. Failure to do so can result in death, fire, or electrical shock. Neutral Local codes may permit the use of a U.L.-listed, 120/240-volt minimum, 30-ampere, dryer power supply cord kit (pigtail). Power supply cord should be type

    Srd

    or SRDT and be at least four feet long. The wires that connect to the dryer must end with ring terminals or spade terminals with upturned ends. For mobile homes or other four-wire installations, the power supply cord must have four, No.-10 copper wires and match a four-wire receptacle of NEMA Type 14- 30R. The fourth wire (grounding conduc- tor) must be identified with a green cover or bare copper wire and the neutral conductor by a white cover. Do not use an extension cord with this dryer. Do not connect plug end of power supply cord into a live receptacle before connecting power supply cord to dryer terminal block. \, Grounding prong Neutral _/4-inch, U.L.-listed wire (white) strain relief wire (green) Ring terminals Four-Wire Power Supply Cord (Mobile home or other four-wire installations) Four-wire receptacle (NEMA Type 14-30R)

    I9

    Page 21

    Grounding

    Instructions

    This appliance must be grounded. In the event of malfunction or breakdown, grounding will reduce the risk of electric shock by providing a 3ath of least resistance for electric current. The power supply cord must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances.

    Warning:

    Improper connection of the equipment-grounding conductor can result in a risk of electric shock. Check with a qualified electrician or serviceman if your are in doubt as to whether the appliance is properly grounded. Do not modify the plug on the power supply cord. If it will not fit the outlet, have a proper outlet installed by a qualified electrician.

    Save These Instructions

    Step

  • Disconnect
  • power.

    Step

    2, Remove hold-down screw and terminal block cover. Hold-down screw

    Step

  • Attach
  • a _-inch, U.L-listed strain relief to the hole below terminal block opening. Strain relief should have a tight fit with dryer cabinet and be in a horizontal position. Put the power supply cord through the strain relief.

    Step

  • Remove
  • the center terminal block screw. Remove the neutral grounding wire (green/yellow wire) from external ground- ing screw. External ground connector Center silver-colored terminal block screw

    J

    Green/yellow wire of harness Terminal block cover

    2O

    Page 22

    STEP5.Connectneutralgrounding wire andtheneutralwire(whiteorcenter) ofpowersupplycordunderthecenter screwofterminalblock. STEP6.Connect theothertwoinsulated wirestoouterterminalblockscrews. STEP7.Connect thegrounding wire (green)ofthepowersupplycordtothe externalgrounding conductor screw. Securely tightenallelectrical connections. STEP8.Inserttabofterminalblockcover intoslotofthedryerrearpanel.Secure coverwithhold-down screw. Proceed with Installation on page

  • External
  • ground connector Neutral wire Center silver-colored (white) terminal block screw///// / / Green wire of power supply cord or bare copper wire _-inch, U,L -listed strain relief Neutral grounding wire (green/yellow) 4-Wire Connection with Frame-Grounding Conductor 21

    Page 23

    Iv. Four-Wire

    Electrical

    Connection

    (Direct

    Wire)

    Prepare cable as directed: Fire Hazard Use 10 gauge solid copper wire. Use a UL approved strain relief. Disconnect power before making electrical connections. Connect neutral wire (white or center wire) to center terminal (silver). Ground wire (green or bare wire) must be connected to green ground connector. Connect remaining 2 supply wires to remaining 2 terminals (gold). Securely tighten all electrical connections. Failure to do so can result in death, fire, or electrical shock. The dryer can be connected directly to fused disconnect or circuit breaker box with four-wire flexible armored or non- metallic sheathed copper cable (with grounding wire). All current-carrying wires must be insulated. The grounding wire may be bare. A conduit connector must be installed at junction box. Allow four feet of slack in the line so dryer can be moved if servicing is ever necessary.

    Grounding

    Instructions

    This appliance must be connected to a grounded metal, permanent wiring system; or an equipment-grounding conductor must be run with the circuit conductors and connected to the equipment-grounding terminal or lead on the appliance.

    Save

    These

    Instructions

    Step

  • Disconnect
  • power.

    Step

    la. Strip 5 inches of outer covering from end of cable. Leave bare grounding wire at 5 inches.

    Step

    lb. Cut 1_ inches from the three remaining insulated wires. Strip insulation back 1 inch. Shape the end of each wire into a "U" shaped hook. STEP 2. Remove hold-down screw and terminal block cover. Hold-down screw 22 Terminal block cover

    Page 24

    Step

  • Attach
  • a _-inch, U.L.-listed strain relief to the hole below terminal block opening. Strain relief should have a tight fit with dryer cabinet and be in a horizon- tal position. Put the direct wire cable through the strain relief.

    Step

  • Place
  • the hook-shaped end of the wire over the terminal block screw. The open side of the hook should face to the right. Squeeze hook end of wire to- gether to form a loop.

    Step

  • Remove
  • the center terminal block screw. Remove the neutral ground- ing wire (green/yellow wire) from external grounding screw. External ground Center silver-colored connector terminal block screw Green/yellow wire of harness

    Step

  • Connect
  • neutral grounding wire and the neutral wire (white or center) of direct wire cable under the center screw of terminal block.

    Step

  • Connect
  • the other two wires to outer terminal block screws. Use the same method described in STEP
  • Step

  • Connect
  • the direct wire cable (bare) grounding wire to the external- grounding conductor screw. Securely tighten all electrical connections.

    Step

  • Tighten
  • the strain relief screws.

    Step

  • insert
  • tab of terminal block cover into slot of the dryer rear panel. Secure cover with hold-down screw. External ground connector \ \ Neutral wire Center silver-colored terminal block screw/(white) / // Green wire / of power supply cord or bare copper wire ¾-inch, U.L.-listed strain relief Neutral grounding wire (green/yellow) 4-Wire Connection with Direct Wire and Frame-Grounding Conductor 23

    Page 25

    D. Connect

    Exhaust

    I _e_l_[e1_ "[_ i[_ _"' A properly exhausted dryer will give you the shortest drying time, lower your utility bills, and extend the life of the dryer.
  • If using
  • an existing exhaust system, disconnect vent from the dryer and clean one section at a time until you reach the exhaust hood. To clean out lint, you can use the hose attachment on your vacuum, or use a pole or wire with a feather duster or rag attached. Fire Hazard Use a heavy metal vent. Do not use a plastic vent. Do not use a metal foil vent. Failure to follow these instructions can result in death or fire.

    Warning:

    To reduce the risk of fire, this dryer

    Must

    Be

    Exhausted

    Outdoors.

  • Do not exhaust
  • dryer into a chimney, a wall, a ceiling, or a concealed space of a building.
  • The
  • diameter or the heavy metal vent must be 4 inches.
  • Do not use
  • an exhaust hood with a magnetic latch.
  • Dryer
  • exhaust vent must not be connected or secured with screws or other devices which extend into the interior of the vent.
  • Make
  • sure exhaust hood is not plugged with lint. Follow the instructions in this section to reinstall your vent system. 24

    Page 26

    Route

    The Vent

    Typical installations exhaust from the rear of the dryer. Avoid pushing the dryer tightly against a wall. This can crush or kink the vent. Use the straightest path you can, where possible. Avoid 90 ° turns. Rear exhaust installations for standard offset connections
  • (see pgs. 26-27).
  • Rear exhaust installations for offset connections with close clearances
  • (see p. 28)
  • This dryer may be converted to exhaust out the right or left side or through the bottom. To convert the dryer, one of the following kits must be used. Exhaust Kit No. 279818 (white) Exhaust Kit No. 279819 (almond) Exhaust Kit No. 279915 (graphite) Fire Hazard Cover unused exhaust holes with one of the following kits: 279818 (white) 279819 (almond) 279915 (graphite) Contact your local dealer. Failure to follow these instructions can result in death, fire, electrical shock or serious injury. Follow the instructions in the kit to avoid operational and personal hazards. These kits are available at your local Sears store or Sears Service Center. Typical installations for left or right side exhausting Typical installations for bottom exhausting 25

    Page 27

    26

    Determine

    Ventlength

    MaximumExhaustLengths:
  • Rear
  • Exhaust. The maximum length of the rear exhaust system depends on the type of vent, the number of elbows, and the type of exhaust hood. Refer to the chart below.
  • Side
  • or Bottom Exhaust. Side or bottom exhaust adds a 90 ° turn inside the dryer. To determine maximum exhaust length, add one 90 ° turn to the chart.

    Exhaust

    Hood Type

    Number of 90 ° Turns 0 1 2 3 4 Number of 90 ° Turns 0 1 2 3 4 (Use4-inch if possible) Maximum length of 4-inch diameter heavy metal vent. 64 ft 58 ff 54 ft 48 ff 44 ft 38 ff 35 ft 29 ff 27 ft 21 ff Maximum length of 4-inch diameter flexible metal vent. 36 ft 28 ft 31 ft 23 ft 27ft 19ft 25ft 17ft 23ft 15ft

    Note:

    If a combination of heavy metal vent and flexible metal vent is used, use instructions for flexible metal vent.

    Standard

    Offset

    Connection8

    Using 4-inch heavy metal vent:

    Note:

    Do not secure exhaust vent joints with screws. Screws can catch lint and slow the drying process, instead, use clamps to secure exhaust vent joints.

    Step

  • Install
  • a 4-inch metal elbow on the hood and on the dryer exhaust outlet.

    Step

  • Measure
  • the length of 4-inch heavy metal vent needed to connect the two elbows. Elbow j Wall [ Exhaust °°" Duct

    I

    clamps .......... See .......... j,TE.2 Elbow Duct tape & clamps The vent usually comes in 2-foot lengths. Use tin snips to cut the vent 3 inches longer than your measurement in order to make a connection.

    Step

  • Place
  • a clamp on each end of vent elbow and connect elbow to your dryer's exhaust outlet. Tape the joint with duct tape. Tighten clamp. Tape Clamp

    Page 28

    STEP 4. Connect vent to elbow. Tape the joint with duct tape. Tighten clamp.

    Step

  • Install
  • one end of elbow on vent, the other end to the exhaust hood. Tape joints and tighten clamps. Finish Installation. See "REVIEW

    Installation".

    Step

  • Place
  • a clamp on each end of vent elbow. Install one end of elbow on vent, the other end to the exhaust hood. Tape joints and tighten clamps. Using 4-inch flexible metal vent:

    Note:

    Do not secure exhaust vent joints with screws. Screws can catch lint and slow the drying process, instead, use clamps to secure exhaust vent joints.

    Step

  • Install
  • a 4-inch metal elbow on the exhaust hood and, if necessary, on the dryer's exhaust outlet.

    Step

  • Measure
  • the length of 4-inch flexible metal vent needed from the dryer to the hood. Elbow Flexible metal vent _ Dryer Wall Exhaust Duct tape & clamp tape& clamps Duct tape& clamp Elbow (optional)

    Step

  • Add
  • 10 inches to the measure- ment for each bend in the vent.

    Step

  • Add
  • 3 more inches to the measurement for connection over the dryer's exhaust outlet and hood. Tape Clamp

    Step

  • Stretch
  • the vent only as needed by pulling out from the center in each direction. Do not stretch vent sections over 6 feet. if distance is more than 6 feet, use 2 or more sections of metal vent with flexible metal vent attached at ends.

    Step

  • Connect
  • the vent directly to the dryer outlet or to a separate elbow. Tape the joints with duct tape. Secure with clamps.

    Step

  • To connect
  • the vent to the section of the exhaust hood that is inside your wall, it may be necessary to make two _ inch cuts in the end of the flexible vent to allow it to expand. Finish Installation. See

    "Review

    Installation".

    27

    Page 29

    Offset Connections

    With Close Clearances

    When your exhaust vent is in a close clearance behind the dryer, or if you are installing your dryer in a recessed area or closet, you will find it helpful to install the exhaust vent over-the-top* of the dryer.

    A

    kit is available from your local Sears store or Sears Service Center.
  • Parts may be covered by one or more
  • U.S. Patents.

    Loop

    System

    Note:

    Vent systems come in many varieties. Select the type that best fits your installation. Three of the most common types of installations are illustrated here.

    I

    ," \ Vent system installed over-the-top with standard elbows

    I

    <.
  • -
  • 1-'--_

    [ -- -"""" T .....

    " .... :z=_

    Periscope

    System

    , "'. ......

    T

    Vent system installed over-the-top with one offset and one standard elbow 28 Vent system with one periscope (2-inch clearance)

    Page 30

    Review Installation

    _WJro_'.,=._reJ._J= ;,I_ a[,_ i"[d Take a few minutes to complete this checklist. It will help assure you that you have a proper installation and increase your satisfaction with your Kenmore dryer. [] Check that all parts you removed from the parts packages are now installed. [] Ensure that dryer is positioned in its fi- nal location. Make sure vent is not crushed or kinked. [] Ensure that dryer is level by placing a level on top of the dryer. Check side- to-side first, then check front-to-back. If dryer is not level, adjust the legs up or down. [] Check to make sure you have all the tools you started with.

    Final Steps

    [] Plug the power supply cord into the grounded outlet or connect direct wire to power supply. [] Turn power supply on. [] Wipe the interior of the drum thoroughly with a damp cloth to remove any dust. [] Remove the blue protective film on the console and any tape remaining on dryer. [] Read the rest of this manual to fully understand your new dryer. [] Start the dryer and allow it to complete a full heat cycle (not the

    Air

    Dry

    Cycle). After five minutes, open dryer door. You should feel heat inside the dryer. If you do not feel heat, see

    "Troubleshooting".

    Note:

    You may notice a burning odor. This smell is common when the heating element is first used. The smell will go away. 29

    Page 31

    Explosion Hazard Keep flammable materials and vapors, such as gasoline, away from dryer, Do not dry anything that has ever had anything flammable on it (even after washing). Failure to follow these instructions can result in death, explosion, or fire. Fire Hazard No washer can completely remove oil. Do not dry anything that has ever had any type of oil on it (including cooking oils). Items containing foam, rubber, or plastic must be dried on a clothesline or by using an Air Cycle. Failure to follow these instructions can result in death or fire.

    Starting Your Dryer

    Note:

    The drawings in this section show the basic features of all models cov- ered by this manual. Refer to the supplied "Feature Sheet" for your dryer's particular features.

    Step

  • Check
  • lint screen. Clean if needed.

    Step

  • Put
  • laundry into dryer and shut door.

    Step

  • Set Cycle
  • Selector Control (Timer)O; (see pages 31 and 33).

    Step

  • Set FABRIC/Temperature
  • Control

    O;

    (see page 32). Check clothes label for manufacturer's recommendations.

    Step

  • Press
  • Push

    To Start

    Button

    O

    Be sure door is closed.

    Stopping/Restarting

    Your

    Dryer

  • To stop
  • the dryer at any time, open dryer door.
  • To restart,
  • press

    Push

    To Start

    Button

    O

    Be sure door is closed.
  • If you wish
  • to end your drying cycle,_ turn Cycle Selector Control (Timer)Q to OFR s0 _ 7o '_' s0 TIMED

    Dry

    w_sN_ c,uA_, t 4o

    Sensing

    _

    " _0 Touch

    Up

    _o so

    Air

    Dr'/

    0

    Fabric

    T_Mperatu_E

    C_Sual

    Pe_Mpress

    Signal

    Push

    To

    Start

    3O

    Page 32

    Cycle Descriptions

    Ftuo,_Iel_Jo ;I_1 i[_ _e The automatic cycles save you time by providing the best drying results in the shortest time.This can help you save money on utility bills and reduce the risk of fabric damage.

    Auto

    Moisture

    Sensing

    /

    Evenheat

    TM with

    Auto

    Moisture

    Sensing

    Plus

    cycles Depending on your model, your dryer's automatic cycle is AUTO

    Moisture

    Sensing

    or

    Evenheat

    TM with AUTO

    Moisture

    Sensing

    Plus.

    Use this cycle for most loads. Drying time varies according to type of fabric, size of load, and dryness setting.
  • Set the
  • Cycle Selector Control (Timer) to NORMAL

    Dry(*)

    which is good for most fabrics.
  • At the
  • end of the cycle, feel the dried clothes. If they are damp, select

    More

    DRY the next time you do a similar load. If they are overdried, select

    Less

    Dry

    or DAMP

    Dry

    (depending on model) the next time you do a similar load.
  • Dryness
  • is determined by an electronic sensor that "feels" the amount of moisture in clothes as they pass over it. When the dryness selected is reached, the dryer goes into a Cool Down period of up to 10 minutes.
  • The
  • End-of-Cycle

    Signal

    sounds (if selected) once the cycle is completed.
  • If you
  • do not unload the dryer, it goes into WRINKLE

    Guard

    ® automatically. For an explanation of WRINKLE

    Guard

    ®, see page
  • Note:

  • On some models,

    Wrinkle

    Guard

    ® is selected by an option switch.

    Timed

    Dry

    Cycle

    Use this cycle to get up to 80 or 90 minutes (depending on model) of heated drying time.
  • The
  • heating cycle is followed by a 10- minute (approx.) Cool Down period.
  • The
  • End-of-Cycle

    Signal

    sounds (if selected) once the cycle is completed.

    Note:

    Dryers with a WRINKLE

    Guard

    ® Option control will go into WRINKLE

    Guard

    ® immediately following this cycle if it is selected.

    Touch

    Up Cycle

    Use this cycle to smooth synthetic and permanent press clothes that are clean but wrinkled from being crowded in a closet or suitcase.
  • This
  • setting provides about 15 minutes of heated tumbling followed by a 10- minute (approx.) Cool Down period.
  • Remove
  • clothes immediately when tumbling stops.

    Auto

    Moisture

    Sensing

    Or

    /--

    Even Heat

    lo zo 3e AIR

    Dry

    31

    Page 33

    Fabric/Temperature

    Control

    Proper use of this control helps ensure that fabrics are dried at the right temperature for maximum life. Use this control to select the drying temperature that matches the fabrics in your load.
  • Select
  • Low

    for delicate fabrics. Select

    High

    for durable fabrics such as sturdy work clothes or bath towels.
  • The
  • FABRIC/Temperature Control will not work when the Cycle Selector Control (Timer) is in the AIR

    Dry

    Cycle.

    Fabric

    Temperature

    F

    Knit

    /

    Normal

    /

    Casual

    Perm

    Press

    Medium

    Medium

    High

    • •

    Delicate

    _

    Cotton

    Low

    • •

    H_H

    \ The following chart lists suggested dryer settings and drying times for various loads. This is only a guide. Settings may require adjustment depending on the requirements of your load. Automatic Drying

    Timed Dry

    Type of Load Setting Temp Setting

    Cottons And Linens

    Extra Heavy - Bedspreads, mattress

    More Dry

    High

    70-80 min. pads, quilts Heavyweight -Towels, jeans, corduroys,

    More Dry

    High

    50-60 min. work clothes Mediumweight - Sheets, cotton underwear,

    Normal

    MEDiUM/HiGH 40-50 min. diapers

    Dry

    or MEDIUM* Lightweight - Batistes, organdies, lingerie

    Normal Dry

    Low

    30-40 min.

    Permanent Press, Synthetics And Blends

    Heavyweight -Work clothes, jackets,

    Normal

    High

    40-50 min raincoats

    Dry

    Mediumweight - Shirts, play clothes,

    Normal

    MEDIUM/HiGH 30-40 min. sheets, slacks

    Dry

    or MEDIUM* Lightweight - Lingerie, blouses,dresses

    Less Dry

    MEDIUM or LOW* 20-30 min. or DAMP DRY

    Knits

    Heavyweight - Cottons, rayons, blends,

    Normal

    High

    40-50 min. T-shirts, slacks, shirts

    Dry

    Mediumweight - Synthetics (polyester,

    Normal

    MEDIUM/HiGH 30-40 min. acrylic, etc.), dress slacks, skirts, sweaters

    Dry

    or MEDIUM* Lightweight - Synthetics (polyester, acrylic,

    Less Dry

    Low

    20-30 min. etc.) and blends, lingerie, blouses, dresses or DAMP DRY *Use the lowest temperature setting available on your dryer. 32

    Page 34

    Using Air Dry/Air Fluff

    Using these cycles gives you all the benefits of hang drying with a shorter drying time. Use the AIR

    Dry

    Cycle to get up to 30 minutes of drying time in room tem- perature air. Use this setting for items that will not tolerate heat such as plastics and foam rubber. Also use for airing and fluff- ing items such as pillows. The

    Air

    Fluff

    Setting operates exactly like the AIR

    Dry

    Cycle. This setting is available on models that do not have an

    Air

    DRY Cycle in the Cycle Selector Control (Timer). To use

    Air

    Fluff:

  • Set Cycle
  • Selector Control for the number of minutes you want in the

    Timed

    Dry

    Cycle.
  • Set FABRIC/Temperature
  • Control to AIR

    Flufr

  • Set other
  • options, press

    Push

    To

    Start

    Button. Refer to the following chart for examples of items that require drying without heat. Use the AIR DRY Cycle or AIR

    Fluff

    Setting (depending on model), or place the items on a line or rack to air dry. o__R 90 80 70

    6O

    5O Timed

    Dry

    Wrinkle

    Guard

    I

    Auto

    30

    Mo,,To.E

    Sensing

    Touch Up

    Less

    Dry

    Normal

    Dry

    More

    Dry

    Fabric Care

    Temperature

    Knit /

    Casual

    Ultra Delicate

    Me_Um"

    Norma_

    /

    _Perm

    Press

    Extra Low

    ® • MEDItJh4 +tlGH

    Air

    FLUFF e •

    Cotton

    NOflgAT +ll_fl lo 20 30 AIR DRY AIR DRY Cycle/ Type of Load

    Air Fluff

    Setting

    Delicate

    Fabrics

    Sheer curtains (2 or 3 panels), gauze, lace, etc. 20-30 min. (Use AIR DRY/AIR FLUFF if iow heat is not available.) 20-30 min.

    Rubber,

    Plastic,

    Heat-Sensitive

    Fabrics

    Foam rubber - Pillows, padded bras, stuffed toys
  • Make sure coverings
  • are securely stitched.
  • Shake and fluff pillows by hand several times during the cycle.
  • Make sure pillows are completely
  • dry. Foam rubber pillows take a Iong time to dry.* Plastic - Shower curtains, tablecloths Rubber-backed rugs Olefin, Polypropylene, Sheer nylon 20-30 min. 40-50 min. 10-20 min. *Reset time, as needed, to allow these items to dry completely. 33

    Page 35

    End=Of-Cycle

    Signalcontrol

    I rteJ_i_{oj_i "I:-] i[_ i'[-" Your dryer sounds a signal when a drying cycle is finished. The signal is helpful when you are drying permanent press, synthetics, and other items.These items should be removed from the dryer as soon as it stops in order to prevent wrinkles.
  • The volume of the signal can be
  • adjusted.

    Signal

    End Ofcycle

    Soft

    o

    Off@

    Loud

    Push

    To Start

    Button

    Use this control to start the dryer. Be sure the dryer door is closed. Opening the door stops the dryer. It will not start again until you close the door and press the

    Push

    To Start

    But- ton. Be sure the Cycle Selector Control (Timer) is still on a drying cycle or air setting.

    Push To Start

  • The
  • variable control lets you select a volume anywhere from

    Off

    to

    Loud.

    Signal

    End

    Of Cycle

    Off,Loud

    34

    Page 36

    Soft-Hea'I "_ System

    Using Wrinkle

    Guard ®

    IteJo_teJ_o "-I_ i1[_ _o SOFT-HEAT ® System guards against overdrying. This helps your fabrics retain the natural moisture they need, prevents static, and reduces pilling - the formation of small lint-like balls on the surface of garments. Pilling is the natural result of washing and wearing of garments. Kenmore dryers help prevent overdrying so you get outstanding fabric care. In the AUTO

    Moisture

    Sensing

    and

    Timed

    Dry

    Cycles, clothes are dried at the temperature you selected until the last few minutes of the cycle. The dryer then switches to low heat.

    Cool

    Down

    Approximately ten minutes before the end of the AUTO

    Moisture

    Sensing

    and

    Timed

    Dry

    Cycles, clothes are tumbled without heat to help reduce wrinkles and make clothes more comfortable to handle.

    Wrinkle

    Guard

    ® helps keep your permanent press items wrinkle free when you don't unload the dryer promptly at the end of the automatic cycle. If you do not open the door at the end of the automatic cycle,

    Wrinkle

    Guard

    ® will tumble the clothes without heat for about 15 seconds periodically throughout the cycle.
  • On
  • dryers with WRINKLE

    Guard

    ® I,

    the dryer will tumble the clothes continuously for about 30 minutes unless you open the dryer door.
  • On
  • dryers with WRINKLE

    Guard

    ® Ii,

    periodic tumbling will continue for about 40 minutes unless you open the dryer door.
  • On
  • dryers with WRINKLE

    Guard

    ® Iii,

    periodic tumbling will continue for about 21/2 hours unless you open the dryer door.

    • Wrinkle

    Guard

    ® III has a selectable

    On/Off

    Option. When

    Wrinkle

    Guard

    ® Ill is set at OFF, the dryer stops after Cool Down and may be unloaded. The End-of-Cycle

    Signal

    will sound after each period of tumbling, unless it is off.

    Wrinkle

    Guard

    Itl

    Off

    On

    35

    Page 37

    Heated

    Tumble

    Free

    Dryer

    Rack

    Your dryer may include a dryer rack. If your dryer does not have a rack, you can purchase one by calling Sears (see back cover). IzeJJlrte_._,, "I_ i[:a i]" Use the heated Tumble Free Dryer Rack for items that you do not want to tumble dry, such as sweaters and tennis shoes. When you use the heat- ed dryer rack, the heated air inside the dryer flows in a concentrated pattern to allow efficient and uniform drying. To use the heated dryer rack: Do not remove lint screen.

    Step

  • Open
  • dryer door.

    Step

  • Slide
  • dryer rack over the bottom of the dryer door opening. Push down to secure it on the frame.

    Step

  • Place
  • wet items on top of the rack. Allow space around items for air to circulate. The rack does not move, but the drum will rotate. Make sure items do not hang over the edges or between rack grill.

    Step

  • Close
  • dryer door.

    Step

  • Use
  • the TIMED

    Dry

    or AIR

    Dry

    Cycle. Refer to the chart below.

    Step

  • Set the FABRIC/Temperature
  • Control if available. Refer to the chart below.

    Step

  • Start
  • the dryer. To remove the rack, lift it straight up and out of the dryer.

    Note:

    Check the lint screen and remove any lint accumulated from items dried on the rack.

    Fabric/

    Cycle Selector Suggested Suggested Items Temperature (Timer) Time for Rack Drying Setting Setting (minutes)* Washable wool items (block to

    Delicate

    Timed

    Dry

    20 shape and iay fiat on rack) Stuffed toys (cotton or polyester

    Cotton

    Timed

    Dry

    20 fiber fiiling) Stuffed toys (foam rubber fiiling)

    Air Fluff

  • or-
  • Air Dry

    50 Galoshes (rubber)

    Air Fluff

  • or-
  • Air Dry

    20 Foam rubber pillows

    Air Fluff

  • or-
  • Air Dry

    50 Tennis shoes

    Air Fluff

  • or-
  • Air Dry

    20 *Reset time, as needed, to complete drying. 36

    Page 38

    Follow these recommendations to help save on utility bills and prolong the life of your garments.

    Preparing

    Clothes

    For

    Drying

  • Refer to your Washer
  • Owner's Manual for proper washing techniques and additional laundry tips.
  • See page 5 of this book for important
  • Safety instructions.

    Sorting Clothes

    Choosing

    Load

    Sizes

  • Mix large
  • items with smaller items. Load the dryer by the amount of space items take up, not by their weight. Do not over- load the dryer. Overcrowding causes uneven drying and wrinkling, and can cause items to wear out faster (because of pilling).
  • You may
  • need to rearrange large items (sheets, blankets, tablecloths) during a cycle to reduce bailing or rolling up.
  • For better
  • tumbling action, when drying only a few small items, add one or two lint-free towels. This also prevents small lightweight items from blocking airflow.
  • Separate
  • dark colors from light colors; colorfast from non-colorfast. Items properly sorted by color for washing are usually properly sorted for drying.
  • Separate
  • heavy fabrics (denim, towels) from light fabrics (synthetics, permanent press).
  • Separate
  • lint givers (towels, chenille) from lint takers (corduroy, synthetics, permanent press). When possible, turn lint takers inside out.

    King Size Capacity Dryers

    Heavy Work Clothes 4 jeans 4 workpants 4 workshirts 2 sweatshirts 2 sweatpants Towels Mixed Load 10 bath towels 3 sheets 10 hand towels (1 king, 2 twin) 14 wash cloths 4 pillowcases 3 shirts 3 blouses 9 T-shirts 9 shorts 10 handkerchiefs 37

    Page 39

    Drying Tips

  • Close
  • zippers, snaps, and hooks to avoid snagging other items. Remove heat-sensitive trim that can be damaged by drying. Tie strings and sashes so they will not tangle.
  • Check
  • garments for spots and stains left after washing. Do not tumble these items. Heat may permanently set stains.
  • Check
  • pockets before drying. Sharp or metal objects can damage your dryer. Do not lay these objects on your dryer, they can damage the finish. Turn pockets of heavy garments inside out for even drying.
  • Place
  • small items such as baby socks or hankies in laundry bag for easier removal.
  • Articles
  • to be ironed should be removed while still damp.

    Using

    Dryer

    Fabric

    Softeners

    Dryer fabric softeners are recommended for reducing static cling. Always follow package instructions carefully.
  • Put one
  • fabric softener sheet on top of the load before starting the dryer. De not add a fabric softener sheet after the drying cycle has started. Instant heat can cause the fabric softener to spot fabrics.
  • Remove
  • fabric softener stains by wetting the stains and rubbing them with liquid detergent or bar soap and rewash.
  • Some
  • fabric softeners can clog the lint screen and slow drying. Use fabric soft- eners labeled as dryer safe.

    Saving

    Energy

  • Sort
  • loads by fabric weight and type.
  • Use the automatic
  • cycle to dry most loads.
  • Dry full
  • loads only. Do not overdry.
  • Avoid
  • overloading dryer, adding wet items to a partly dried load, or opening the door unnecessarily.
  • Shorten
  • drying times by exhausting dryer properly and cleaning exhaust vent and outside exhaust hood as needed.
  • Keep
  • the lint screen clean.
  • Use dryer
  • where room air temperature is above

    45°R

    38

    Page 40

    Cleaning Your Dryer

    Proper care of your dryer can extend its life and help you avoid costly service calls.

    Exterior

    Use a soft, damp cloth to clean the cabinet and console. Avoid using harsh abrasives. Do not put sharp metal objects on or in your dryer. They can damage the finish.

    Interior

    To clean dryer drum:

    Step

  • Make
  • a paste with detergent and very warm water and apply to a soft cloth. Continue with

    Steps

    2-4. or

    Step

    la. Spray non-flammable liquid household cleaner on the stained area. Continue with

    Steps

    2-4. STEP 2. Scrub area until all excess dye is removed. Explosion Hazard Use nonflammable cleaner. Failure to do so can result in death, explosion, or fire. Garments that contain unstable dyes, such as denim blue jeans or brightly colored cotton items, may discolor the drum interior. These stains are not harmful to your dryer and will not stain future loads of clothes. It is helpful to dry unstable dye items inside out to prevent dye transfer.

    Step

  • Wipe
  • thoroughly with a damp cloth.

    Step

  • Tumble
  • a load of clean towels for 20 minutes to dry. 39

    Page 41

    Cleaningthelintscreen

    RemoveLintBeforeEveryLoad The lint screen is located in the door opening. Remove lint before starting every load. A screen blocked by lint can increase drying time. To clean:

    Step

  • Pull the
  • lint screen straight up.

    Step

  • Roll
  • lint off the screen with your fingers. Do not rinse or wash screen to remove lint. Wet lint is hard to remove.

    Step

  • Push
  • the lint screen firmly back into place.

    Important:

  • Do not
  • run the dryer with the lint screen loose, damaged, blocked, or missing. Doing so can cause overheating and damage to both the dryer and fabrics.
  • Some
  • towels made of synthetic fibers and natural fibers (polyester and cotton blends) may shed more lint than other towels, causing your dryer's lint screen to fill up faster. Be sure to remove lint from the lint screen before and after drying new towels.
  • If lint falls off the
  • screen during removal and into the dryer, periodically check the exhaust hood and remove the accumu- lated lint (see "Connect Exhaust"). Wash Lint Screen As Needed Laundry detergents and fabric soft- eners can cause a residue buildup on the lint screen. Wash the lint screen with a nylon brush if it becomes clogged due to a residue buildup. To wash:

    Step

  • Wet
  • both sides of lint screen with hot water.

    Step

  • Wet a nylon
  • brush with hot water and liquid detergent; scrub lint screen with the brush to remove residue buildup.

    Step

  • Rinse
  • screen with hot water.

    Step

  • Thoroughly
  • dry lint screen with a clean towel; replace in dryer.

    Checking

    For

    Obstructed

    Airflow

    From time to time, you may find it helpful to check your dryer and exhaust system for proper airflow. Poor airflow can result in longer drying times. To check for obstructed airflow:

    Step

  • Check
  • to ensure nothing is blocking ventilation slots on dryer rear panel.

    Step

  • Inspect
  • exhaust hood. It should not be blocked or obstructed.

    4O

    Page 42

    Removing

    Accumulated

    Lint

    Toremoveaccumulated lintfrom exhaustvent: STEP1.Disconnect exhaust vent from the dryer.

    Step

  • Clean
  • one section of vent at a time until you reach the exhaust hood. To clean out lint, you can use the hose attachment on your vacuum, or use a pole or wire with a feather duster or rag attached.

    Step

  • Reconnect
  • vent as described in the "INSTALLATION

    Instructions"

    of this Owner's Manual. To remove accumulated lint from inside the dryer: Lint should be removed every 2 years, or more often, depending on dryer usage. Cleaning should be done by a qualified person.

    Moving

    Care

  • Disconnect
  • power.
  • Make
  • sure leveling legs are secure in dryer base.
  • Use
  • masking tape to secure dryer door.

    Vacation

    Care

  • Disconnect
  • power.
  • Wash lint screen.
  • 41

    Page 43

    Changing

    The Drum Light

    The dryer light automatically turns on inside the dryer drum when you open the door.Your dryer drum light may be one of two types, as shown. To change drum light type 1:

    Step

  • Unplug
  • dryer or disconnect power.

    Step

  • Open
  • the dryer door. Remove the screw that holds the lens in )lace.

    Step

  • Remove
  • the lens by pulling it down and away from drum.

    Step

  • Push
  • tab to allow bulb to swing out.

    Step

  • Remove
  • the light bulb by turning it counterclockwise.

    Step

  • install
  • light bulb by turning it clockwise. Replace the bulb with a 15-watt, appliance bulb only.

    Step

  • Push
  • bottom of light and socket assembly in until tab locks. 42

    Step

  • Place
  • the top of the lens onto the top of the holder. Rotate the bottom of the lens down until it is in place. Replace screw.

    Note:

    It is very important that the lens is replaced properly.

    Step

  • Plug
  • in dryer or reconnect power. To change drum light type 2:

    Step

  • Unplug
  • dryer or disconnect power.

    Step

  • Open
  • the dryer door. Remove the screw that holds the lens in place.

    Step

  • Remove
  • the lens by pulling it down and away from drum.

    Step

  • Remove
  • the light bulb by turning it counterclockwise.

    Step

  • Install
  • light bulb by turning it clockwise. Replace the bulb with a 15-watt, appliance bulb only.

    Step

  • Place
  • the top of the lens onto the top of the holder. Rotate the bottom of the lens down until it is in place. Replace screw.

    Note:

    It is very important that the lens is replaced properly.

    Step

  • Plug
  • in dryer or reconnect power.

    Page 44

    Most laundering problems are easily solved if you understand the cause. Using the charts below will save you time and money by helping you avoid unnecessary service calls. Problem Not Drying Satisfactorily Solution Clean Iint screen. Run dryer for 5-10 minutes. Hold hand under outside exhaust hood to check air movement. If you do not feel air moving, clean exhaust system of lint or replace exhaust vent with heavy metal or flexible metal vent (see "Installation Instructions," Section

    D).

    Exhaust vent is crushed Replace with heavy metal or or kinked, flexible metal vent (see "Installation Instructions," Section

    D).

    One fuse is blown or circuit Replace fuse or reset breaker. breaker is tripped. The dryer will appear to operate, but you will not get any heat. Timer or the temperature Select the right cycle for the types control is set on AIR DRY of garments being dried (see or AIR FLUFR "Operating Your Dryer"). Load not contacting the Level dryer (see "Installation sensor strips and automatic Instructions," Section

    B).

    cycle ending early. Fabric softener sheets Use only one softener sheet per load biocking outiet griil, and only use it once. Dryer located in room with Move dryer where it can operate in temperature below 45°R ambient air temperatures above 45°R Large amount of moisture Expect longer dry times with items in the load. that hold more moisture (cottons). Cold rinse water used. Expect longer dry times, but you are saving energy and reducing wrinkles. Load too large and bulky to Separate load to tumble freely. dry quickly. Dryer Will Power cord not firmly plugged Plug power cord into a live circuit. Not Run into a Iive circuit with proper voltage. Fuses blown or circuit Replace fuses or reset breakers. breakers tripped. Possible Cause Lint screen is clogged with lint. Restricted air movement. Exhaust vent or outside exhaust hood is clogged with lint. 43

    Page 45

    Problem Possible Cause Solution Dryer Will Using a regular fuse. Replace with a time-delay fuse. Not Run Dryer door not firmly closed. Close dryer door tightly. (ton't) PUSH TO START Button Press PUSH TO START Button again. not firmly pressed. Controls not set in an Reset controls in an ON position. ON position. Lint in Load Lint screen is clogged. Clean lint screen. Check for air movement. Improper sorting. Sort lint givers from lint takers and by color. Load is too big or heavy. Dry smaller loads so lint can be carried to the lint screen. Load is overdried. Use correct dryer settings for fabric. Overdrying can cause lint-attracting static (see "Operating Your Dryer"). Paper or tissue in pockets. Clean out pockets before drying. Pilling being mistaken for lint. Pilling (surface fuzz) is caused by normal wear and laundering. Stains on Load Improper use of fabric softener Use fabric softener sheets in dryer. Add in washer, at beginning of cycle when toad is cold. Drying soiled items. Items need to be clean before being dried. Items Overdrying. Match dryer settings to fabric type Shrinking (see "Operating Your Dryer"). Poor garment quality. Check quality of garment before purchasing. Manufacturer's care label Follow fabric care label instructions instructions not followed, carefully. Loads are Overloading. Dry smaller loads that can tumble freel Wrinkled Overdrying. Match dryer settings to fabric type (see "Operating Your Dryer"). Load left in dryer at the Remove load as soon as tumbling end of cycle, stops. Odors Household chemicals, paint, Do not use dryer while these chemical or varnish being drawn fumes are in the air. into dryer. First use of dryer element. Odors wilt be gone after the first cycle. Unusual Thumping of rollers when Thump wilt go away after 5 minutes Sounds dryer has set. of drying. 44

    Page 46

    Kenmoredryers

    "WeServiceWhatWeSell"isourassurance thatyoucandependonSearsfor service.YourKenmore appliance hasaddedvaluewhen you consider that Sears has service units nationwide, staffed with professional technicians trained on all appliances Sears sells. They have the knowledge and skills, tools, parts, and equipment to ensure our pledge to you that "We Service What We Sell." Maintain the value of your purchase with a Sears Maintenance Agreement. Kenmore appliance are designed, manufactured, and tested for years of dependable operation. Yet, any appliance may require service from time to time. The Sears Maintenance Agreement offers you an outstanding service program for your product. The Sears Maintenance Agreement:
  • Is your way
  • to buy tomorrow's service at today's prices.
  • Eliminates
  • repair bills resulting from normal use.
  • Allows
  • for as many service calls as required.
  • Provides
  • an annual Preventive Maintenance Check at your request to keep your dryer in proper running condition. For more information call: 1-800-827-6655 45

    Page 50

    In U.S.A. or Canada for in-home major brand repair service: Call 24 hours a day, 7 days a week

    1-800-4-My-Home

    5°(1-800-469-4663) Para pedir servicio de reparacibn a domicilio - 1-800-676-5811 Au Canada pour tout le service - 1-877-LE-FOYEF_ M(1-877-533-6937) For the repair or replacement parts you need: Call 6 a.m. - 11 p.m. CST, 7 days a week PartsDirect

    1-800-366-Part

    (1-800-366-7278) www.sears.com/partsdirect Para erdenar piezas con entrega a domicilio
  • 1-800-659-7084
  • For the location of a Sears Service Center in your area: Call 24 hours a day, 7 days a week 1-800-488-1222 To purchase or inquire about a Sears Maintenance Agreement: Call 7 a.m. - 5 p.m. CST, Monday - Saturday 1-800-827-6655

    More from Kenmore

    Similar Dryers
