27 totalWhat is the maximum 4G download and upload speed of the 4G03 router?
The 4G03 supports a maximum 4G download speed of 150 Mbps and upload speed of 50 Mbps. It is based on LTE CAT4 technology, allowing you to enjoy uninterrupted HD movies, rapid file downloads, and smooth video chats. (Page 3-4)
How many devices can connect to the 4G03 router at the same time?
The 4G03 can share Wi-Fi with up to 32 devices simultaneously. This is supported by the router's powerful 880MHz and 28nm processor for a dependable network experience. (Page 3)
What type of SIM card does the 4G03 router use?
The 4G03 uses a Mini SIM card (2FF) inserted into the SIM card slot. You can instantly access a mobile network by inserting an authorized Mini SIM card. (Page 4)
What 4G LTE frequency bands does the 4G03 support?
The 4G03 supports 4G FDD LTE bands B1, B2, B3, B4, B5, B7, B8, B20, and B28AB, as well as 4G TDD-LTE bands 38 and 40. It also supports 3G WCDMA on bands B1, B2, B5, and B8. (Page 4)
What happens if my fixed internet connection fails on the 4G03?
The 4G03 features automatic failover between Ethernet and 4G connections. If the fixed internet connection fails, the router will automatically switch to a 3G or 4G network, ensuring continued internet access. (Page 3)
What are the power supply requirements for the 4G03 router?
The 4G03 uses a power adapter with an input of AC 100V–240V at 50/60Hz and an output of DC 9V at 1A. This makes it compatible with a wide range of power outlets internationally. (Page 4)
Show 21 more questions
What Wi-Fi security protocols does the 4G03 support?
What is the operating temperature range for the 4G03 router?
What Wi-Fi frequency band and speed does the 4G03 support?
What advanced features and management options does the 4G03 offer?
How many devices can connect to the 4G03 router's Wi-Fi at once?
What power supply does the 4G03 router require?
Does the 4G03 router automatically switch to 4G if the wired internet connection fails?
What 4G and 3G bands does the 4G03 router support?
What are the operating temperature and humidity limits for the 4G03 router?
What Wi-Fi security protocols does the 4G03 router support?
What is included in the 4G03 router package?
What are the maximum download and upload speeds for the 4G03?
How many Wi-Fi devices can the 4G03 support simultaneously?
What type of SIM card does the 4G03 require?
What power supply specifications does the 4G03 use?
What are the physical dimensions and weight of the 4G03?
What operating temperature range is safe for the 4G03?
What happens if my Ethernet connection fails?
What Wi-Fi security standards does the 4G03 support?
What are the humidity requirements for the 4G03?
What is included in the 4G03 package?
Full Manual
6 pages
www.tendacn.com
4G03
N300 Wi-Fi 4G LTE Router
4G03
4G03 | N300 Wi-Fi 4G LTE Router 01 N300 Wi-Fi 4G LTE Router Tenda 4G03 is a wireless gateway that integrates LTE and high-speed Ethernet uplink access, which provides users with flexible and diversified data access .
4G03 | N300 Wi-Fi 4G LTE Router 02 Main Features Fast 4G broadband for smoother experience Wiring free Broadband access wherever you are Stronger and Wider Wi-Fi Signal Share your Wi-Fi up to 32 devices Instantly access a mobile network with a Mini SIM card The Tenda 4G03 delivers maximum speeds of LTE CAT4 150 Mbps,you can enjoy uninterrupted HD movies, rapid file downloads, and smooth video chats. High power gain wireless signal via 2.4 GHz band enlarge your Wi-Fi coverage, andBeamforming+ technology makes Wi-Fi signal of 4G03 outstanding behind multiple walls.
Thanks to a powerful 880MHz and 28nm processor ,it shares the Wi-Fi up to 32 devicees base on dependable network. Failover between the Ethernet and 4G Connection If the fixed internet connection should fail, this modem can easily switch to a 3G or 4G network automatically;In another way, the Internet can be replaced normally. Access a mobile network instantly just with an authorized Mini SIM cardr.
With LTE Advanced signal coverage for best performance and allows you to receive Internet access without cable and fiber ,it is the ideal choice for remote areas such as rural and suburban ,temporary store,holiday home ,giving devices ability to access to the Internet wherever and whenever the user is located.
4G03 | N300 Wi-Fi 4G LTE Router 03 Specification
Lte Cat.4
Fdd Lte,Tdd-Lte,Wcdma;
4G Fdd Lte:B1/B2/B3/B4/B5/B7/B8/B20/B28Ab;
4G TDD-LTE:Band38/Band40;3G Wcdma:B1/B2/B5/B8
4G Cartgory 4G/3G standards 4G Mobile Bands 2.4GHz:300Mbps ; Wi-Fi speed 2.4GHz:up to 20dBm ; Wi-Fi transmit Power Power on/off WPS/Reset Button 185*126*60mm Dimensions（L*W*H） About 350g Weight Power adapter:Input power AC 100V-240V 50/60Hz Output power:DC 9V==1A Power supply Power Wi-FiLan
Internet 4G/3G Signal strength(3 Bars) LED indicators 1 × 10/100 Mbps LAN/WAN Port 1 × 10/100 Mbps LAN Port 1 × 2FF SIM Card Slot Interface Antennas DL:150Mbps UL:50Mbps 802.11b/g/n Max 4G speed 2.4GHz Wi-Fi frequency Wi-Fi standards Hardware Specification 2 Internal 4G/3G Antennas; 2 Internal Wi-Fi Antennas;
4G03 | N300 Wi-Fi 4G LTE Router Auto-APN Auto dial-up Roaming SMS(Send/Receive/Delete)
Ussd
Data limted PIN Management Broadcast and Hide Wi-Fi name Guest network Wi-Fi schedule Wi-Fi functions APP/Local/remote management Parental control DHCP(DHCP Server and Client) Virtual Server(UPnP/DMZ/Port Forwarding) DDNS(DynDns, 88ip) VPN(PPTP Client/L2TP Client/PPTP Server) FirewallQos
Upgrade firmware from local or OTAIpv4/Ipv6
Tr069
FCC Granted CE Granted ROHS Granted Operating Humidity: 10% ~ 90% RH Non-condensing Storage Humidity: 5% ~ 90% RH Non-condensing Software featuresWep,Wpa-Psk, Wpa2-Psk, Wpa/Wpa2
Wi-Fi security Operating Temperature: 0℃~40℃ Storage Temperature: -30ºC~70ºC Temperature 1 * 4G LTE Router 1 * Ethernet cable 1 * Power adapter 1 * Quick Installation Guide Contents Humidity 4G/3G or Wired WAN Type 4G/3G Features 04 Specification Software Specifications Certifications Working Environment Package lists
Specifications are subject to change without notice.Copyright ©2018 SHENZHEN TENDA TECHNO LOGY CO.,LTD. All rights reserved. Tenda is the trademark of SHENZHEN TENDA TECHNO LOGY CO.,LTD. All other brand names mentioned herein are the trademark or registered trademarks of their respective holders. E-mail:[email protected] Tel:+86-755-2765 7098 Fax:+86-755-2765 7178
