Craftsman 150 Psi Air Compressor

What is the maximum PSI rating for the Craftsman 150 PSI Air Compressor?

The maximum PSI rating for this air compressor is 150 PSI, which is the cut-out pressure at which the motor stops when the tank has reached maximum air pressure. The compressor will automatically start refilling when pressure drops below the cut-in pressure of 120 PSI.

How long can I continuously run the Craftsman 150 PSI Air Compressor?

This is a 50% duty cycle air compressor and should not be run for more than 30 minutes at a time. Running the compressor longer than recommended could damage the unit, so it is important to follow this duty cycle guideline.

What are the power requirements for the Craftsman 150 PSI Air Compressor?

The compressor requires 120 VAC single-phase power with a minimum circuit requirement of 15 Amps. The motor is 1.5 HP with an oil-free, direct drive pump design.

What is the air tank capacity of the Craftsman 921.164710 Air Compressor?

The air tank capacity is 26 gallons, which stores compressed air until the cut-out pressure of 150 PSI is reached. The compressor delivers 5.1 SCFM at 40 PSI and 3.8 SCFM at 90 PSI.

Where should I locate my Craftsman air compressor?

The air compressor should be placed in a clean, dry, and well-ventilated environment with a minimum of 12 inches of clear space on each side. The air filter intake must be free of any debris or obstructions, and you should check the air filter daily to ensure it is clean and in working order.

What safety precautions should I take before performing maintenance?

Before any maintenance, you must turn off the air compressor, unplug it from the power source, bleed the air from the tank, and allow the unit time to cool. This prevents personal injuries from moving parts, electrical sources, compressed air, or hot surfaces.
