Common questions
Common Questions
25 totalHow do I switch curl direction when using the Airwrap barrels?
To change the curl direction, rotate the cool tip of the barrel. This allows you to style curls in alternate directions without needing to change attachments. (Page 5)
What does the red LED light mean on my Dyson Airwrap?
The red LED light means you need to clean the filter. If the red LED lights and the filter has already been cleaned, you should contact the Dyson Helpline. (Page 3)
When should I clean the filter on my Dyson Airwrap?
You should clean the filter when the white LED starts flashing. The Dyson Airwrap has highly tuned technology that needs to be kept free from dust and hair product residue, and regular maintenance is required to maintain performance. (Page 7)
How do I safely remove and clean the filter cage?
First, unplug the appliance from the mains electricity supply and allow it to cool down before cleaning. Hold the handle and pull the filter cage downwards onto the cable, gently pull it open, and slide it off the cable. Wash the filter cage under a warm, running tap, then shake to remove excess water and leave to dry naturally. (Page 7)
Can I use water to clean the filter mesh?
No, you should not use water or chemicals to clean the filter mesh. Instead, use the filter cleaning brush with a rotating and up-and-down action until all debris has been removed. (Page 8)
How do I reattach the filter cage after cleaning?
Gently pull the filter cage open and slide it onto the cable, then slide the filter cage towards the handle and twist until it snaps into place. You should hear a click when it is correctly secured. (Page 8)
Show 19 more questions
How do I connect and change attachments on the Dyson Airwrap?
How do I use the Coanda smoothing dryer to smooth my hair?
How do I know when the filter needs cleaning?
How do I remove and clean the filter cage?
How do I safely change attachments during use?
How do I use the Airwrap barrels to curl my hair?
How many heat and airflow settings does the Dyson Airwrap have?
Do I need to unplug the device before cleaning the filter?
How do I use the Coanda smoothing dryer for smoothing?
What should I do when the red LED light appears on my Dyson Airwrap?
How do I properly connect an attachment to the main body?
How do I change attachments safely?
What is the correct way to curl hair with the Airwrap barrel?
When should I clean the filter?
What steps are involved in cleaning the filter cage?
How do I clean the filter mesh?
How do I reinstall the filter cage after cleaning?
What should I do before using the Coanda smoothing dryer for curling?
How do I use the contact bar to hide flyaways?
Full Manual
8 pages
User manual
Sv12 Jn.00000 Pn.000000-00-00
00.00.00 Version No.01
In the box Getting started Using your attachments Pre-styling Curling Shaping Smoothing Regular filter maintenance dyson airwrap logo
In the box Some attachments may not be included. You can buy additional attachments at www.dyson.com/mynewairwrap Dyson Airwrap™ multi-styler main body Coanda smoothing dryer Filter cleaning brush Storage case 30mm Airwrap™ barrel 20mm Airwrap™ barrel 30mm Airwrap™ long barrel 40mm Airwrap™ long barrel 40mm Airwrap™ barrel Firm smoothing brush Small soft smoothing brush Small firm smoothing brush Round volumising brush Small round volumising brush Wide-tooth comb Soft smoothing brush The main body of the product without any attachments. A flat, hook shaped nozzle A cylindrical tool that fits on to the bottom of the Dyson airwrap styler
Getting started Power on/off with cold shot Sliding switch with cold shot to set your style.
Led
Clean the filter. See the ‘Regular filter maintenance’ section for details. If the red LED lights, and the filter has already been cleaned, contact the Dyson Helpline. Removable filter cage Easy to remove for cleaning (see the ‘Regular filter maintenance’ section for details). Airflow control 3 airflow speeds. Temperature control 2 heat settings plus a cold setting to finish your style. The LED lights are loacated at the bottom of the handle above the filter cage The filter cage is located at the bottom of the handle. The temperature control button is located on the back, right hand side of the handle. The power button is located in the middle of the handle. It is a slider button that pushes upwards and downwards. The airflow control button is located on the back, left hand side of the handle.
Using your attachments Connecting the attachment Turn attachment into the main body until it fits securely. Changing attachments To change attachment, pull down on the switch to release. Cool touch tip During use, the Airwrap™ barrels, Round volumising brush and Coanda smoothing dryer will get hot. To change to another attachment, hold the tip. Take care when handling hot attachments Hold the attachment only in the area indicated. Some attachments may need occasional cleaning. For more information, go to www.dyson.com/mynewairwrap Coanda smoothing dryer Airwrap™ barrel Round volumising brush
Pre-styling Barrels Step 1 Take a section of hair and bring barrel towards tips. Hair will start to wrap around barrel. Step 2 Move styler towards head, no need to twist. Hold for 15 seconds or until dry. Step 3 Press cold shot for 5-10 seconds to set curl. Switch off to release. To change curl direction, rotate the cool tip. Coanda smoothing dryer Before curling, pre-dry the hair until almost dry. Comes with two modes (i) drying (ii) smoothing. Use the cool tip to switch between the two modes. Curling clik
Shaping Smoothing Smoothing brushes Step 1 Rough-dry hair with Coanda smoothing dryer. Step 2 Use Smoothing brush to brush from root to tip. Tips: For volume, face bristles outwards. Turn brush inwards at the ends to create shape. Coanda smoothing dryer Rotate cool tip to select Smoothing mode.
Press against hair to switch airflow direction. How to use the contact bar Position contact bar against the head until you hear a click and hair attracts. Run from root to tip to hide flyaways. clik Step 3 Use on dry hair to hide flyaways. Position against hair until it attracts then slowly run down to tips. For use on dry and straight hair.
Regular filter maintenance The filter must be cleaned when the white LED starts flashing. Ensure that you unplug your appliance from the mains electricity supply and allow to cool down before cleaning your filter. The Dyson Airwrap™ multi-styler has highly tuned technology to give outstanding performance. This technology needs to be kept free from dust and hair product residue. Maintenance is required to maintain performance. Step 1 Slide the filter cleaning brush over the cable and onto the filter cage. Using a rotating action, clean the filter cage thoroughly. Remove the filter cleaning brush. Step 2 Hold the handle of your appliance and pull the filter cage downwards, onto the cable.
Gently pull open the filter cage and slide it off the cable. Filter mesh Filter cleaning brush Filter cage Step 3 Wash the filter cage under a warm, running tap. Gently pull the filter cage downwards towards the cable. Wash the filter cage under the tap.t Slide the filter brush onto the filter cage and rotate to clean the filter cage
Step 4 Shake the filter cage to remove the majority of the excess water, then leave to dry naturally. Step 5 Using a rotating and up and down action, clean the filter mesh with the filter cleaning brush until all the debris has been removed. Do not use water or chemicals to clean the filter mesh. Step 6 Gently pull the filter cage open and slide it onto the cable. Slide the filter cage towards the handle and twist until it snaps into place. clik Gently open the filter cage and slide the cage towards the handle, twist until it snaps into place Rotate filter brush around filter mesh to clean Slide the filter brush towards the filter.
