Dyson Airwrap i.d. Hair Dryer

8930970 08.23.24 ©2024 Dyson

In the box You can buy additional attachments at www.dyson.com/hair-care/accessories Dyson Airwrap i.d.™ multi-styler and dryer main body Filter cleaning brush Fast dryer 1.2" Airwrap™ barrel 0.8" Airwrap™ barrel 1.2" Airwrap™ long barrel 1.6" Airwrap™ long barrel Conical Airwrap™ barrel 1.6" Airwrap™ barrel Firm smoothing brush Small soft smoothing brush Small firm smoothing brush Round volumizing brush Small round volumizing brush Soft smoothing brush Large volumizing round brush Fast dryer Blade concentrator Dryer+ Flyaway smoother Wave+Curl diffuser Diffuser Wide-tooth comb The main body of the machine without any attachments. A cylindrical tool that fits on to the filter at bottom of the Dyson Airwrap multi-styler for cleaning. The Fast dryer attachment.

Getting started Power on/off Sliding switch

Led

Unlock i.d. curl™ personalized curling sequence by connecting to the MyDyson™ app Download on the App Store. Get it on Google Play. Step 1 Download the MyDyson™ app and create your account. If you already have an account, log in. Step 2 Power on your Dyson Airwrap i.d.™ multi-styler and dryer and add machine to the app. Bluetooth® wireless technology must be enabled on your mobile device. Step 3 Follow the steps to pair your Airwrap i.d.™. Airflow will be active during this time. Step 4 Once paired, power off your Airwrap i.d.™. Continue set-up in the app to enable features such as the i.d. curl™ personalized curling sequence. Apple, the Apple logo and Siri are trademarks of Apple Inc., registered in the U.S. and other countries. App Store is a service mark of the Apple Inc., registered in the U.S. and other countries. Google Play, the Google Play logo, Google Assistant are trademarks of Google Inc. MyDyson™ app connectivity App functionality may vary per market. Requires internet connection. Operating system and mobile device requirements for the MyDyson™ app can be found on the App Store or Google Play. The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Dyson is under license. Hold Airwrap i.d.™ close to smartphone to connect. Once set up, slide the power button up and release to activate i.d. curl™ personalized curling sequence. Logos of MyDyson app, App store and Google Play.

Using your attachments Connecting the attachment Turn attachment into the main body until it fits securely. Changing attachments To change attachment, pull down on the switch to release. Cool touch tip During use, the Dyson Airwrap™ barrels, round brushes and Dryer+Flyaway smoother will get hot. To change to another attachment, hold the tip. Take care when handling hot attachments Hold the attachment only in the area indicated. Some attachments may need occasional cleaning. For more information, go to www.dyson.com/hair-care/accessories Dryer+Flyaway smoother Conical Airwrap™ barrel Round volumizing brush Lower the attachment onto the multi-styler’s main body and turn gently clockwise until it locks into place. Pull down on the release switch located at the head of the main body and lift the current attachment away. Lower the new attachment onto the multi-styler’s main body and turn gently clockwise until it locks into place. Hold onto the rotating cool tip at the top end of the attachment, pull down on the release switch and lift the attachment away.

Pre-styling Barrels Step 1 Take a section of hair and bring barrel towards tips. Hair will start to wrap around barrel. Using i.d. curl™ sequence The Dyson Airwrap i.d.™ multi-styler and dryer remembers your personalized i.d. curl™ sequence. This tailors wrapping and styling times to your personal hair profile, using the MyDyson™ app. Slide up and release the power switch to activate i.d. curl™ sequence, following initial app set-up. Step 2 Move styler towards head, no need to twist. Your personalized i.d. curl™ sequence will run. Step 3 Cold shot will automatically activate to set the curl. Airflow will automatically reduce when sequence is complete. Move device downwards to release. To change curl direction, rotate the barrel’s cool tip. For straight and wavy hair, use a dryer attachment – Fast dryer or Dryer+Flyaway smoother. The Dryer+Flyaway smoother has two modes (i) drying and (ii) smoothing. Use the cool tip to switch between the modes. Hair should look dry but feel cold to the touch before curling with barrels. For curly and coily hair, use the Firm smoothing brush. Brush hair downwards in small sections, starting from the ends and working towards the roots, until slightly damp to touch. Curling clik A person holding a section of hair, bringing it towards the barrel until it starts to wrap, whilst holding the Dyson device vertically. A person moving the device towards their head, allowing more hair to wrap and hold around the barrel. Twist the rotating cool tip to change curl direction. A person holding the device with the Coanda smoothing dryer attachment above their head, with airflow blowing their long, straight hair. A person moving the device with the Coanda smoothing dryer attachment down their hair to hide flyaways.

Shaping Volumizing Smoothing brushes Use Smoothing brush to brush from root to tip. Tip: For volume, face bristles outwards. Turn brush inwards at the ends to create shape. Round volumizing brush The Round volumizing brush has long fine bristles to direct air into the hair whilst giving body, creating tension to shape the hair as it dries. Tip Lift sections upwards as you dry to add volume. Wrap hair around and under the brush to shape the ends A person using the Smoothing brush attachment with bristles facing inwards and running along the length of rough- dried hair. The Smoothing brush with bristles facing outwards combing hair near the tips. As the brush reaches the hair tips, the attachment is turned inwards to help create shape. A person with long hair using both hands to curl and shape a section of hair using the Round volumizing brush attachment. The Round volumizing brush with a length of hair over the top of it and to an angle as it brushes from root to tip. The Round volumizing brush showing the hair curled around shaping the ends.

360 The Blade concentrator To create a smooth style. Dry with a high-velocity blade of air for precision styling. Focused airflow to create bends and flicks with a brush. Once secured, the Blade concentrator can be rotated 360 degrees for ease when styling. Tip Angle attachment down the hair tress to avoid disruption and to create a smooth, aligned finish. Smoothing Dryer+Flyaway smoother Rotate cool tip to select Smoothing mode. Press against hair to switch airflow direction. How to use the contact bar Position contact bar against the head until you hear a click and hair attracts. Run from root to tip to hide flyaways. Use on dry hair to hide flyaways. Position against hair until it attracts then slowly run down to tips. For use on dry and straight hair. clik On the side of the Dryer+Flyaway smoother, twist the rotating cool tip to select Smoothing mode. Run the attachment downwards to the hair tips. A person using the Dryer and Flyaway smoother on dry, straight hair, moving the attachment along roots to tips of hair. A person styling their hair using the Blade concentrator. The easy unlocking functionality and 360 degrees maneuverability highlighted on the Blade concentrator attachment. One image showing the Blade concentrator correctly angled down a section of hair, and another angled incorrectly at a perpendicular angle.

Stretching Wide-tooth comb Comb hair downwards in small sections. Starting from the ends and working upwards towards the roots, until desired result is achieved. Diffusing Diffuse mode Detachable prongs disperse airflow to the roots for textured, voluminous curls and coils. Wave+Curl diffuser Dome mode Airflow is drawn into the dome to help enhance and smooth natural waves or curls. A person with coily hair holding the device with Wide-tooth comb attachment combing hair downwards near the hair tips. Illustration of person with long curly hair using the Wave and Curl diffuser in Dome mode. Prong bed being lifted from the center of the Wave and Curl diffuser to change between Dome mode and Diffuser mode. Illustration of person with long curly hair using the Wave and Curl diffuser in Diffuse mode.

Regular filter maintenance Filter cleaning is overdue when the white LED starts flashing. Ensure that you unplug your appliance from the mains electricity supply and allow to cool down before cleaning your filter. The Dyson Airwrap i.d.™ multi-styler and dryer has highly tuned technology to give outstanding performance. This technology needs to be kept free from dust and hair product residue. Maintenance is required to maintain performance. Step 1 Slide the filter cleaning brush over the cable and onto the filter cage. Using a rotating action, clean the filter cage thoroughly. Remove the filter cleaning brush. Step 2 Hold the handle of your appliance and pull the filter cage downwards, onto the cable. Gently pull open the filter cage and slide it off the cable. Filter mesh Filter cleaning brush Filter cage Step 3 Wash the filter cage under a warm, running tap. Gently pull the filter cage downwards towards the cable. Open the filter cage and remove. Wash the filter cage under the tap. Slide the filter brush onto the filter cage and rotate from side to side and upwards and downwards to clean the filter cage.

Step 4 Shake the filter cage to remove the majority of the excess water, then leave to dry naturally. Step 5 Using a rotating and up and down action, clean the filter mesh with the filter cleaning brush until all the debris has been removed. Do not use water or chemicals to clean the filter mesh. Step 6 Gently pull the filter cage open and slide it onto the cable. Slide the filter cage towards the handle and twist until it snaps into place. clik Gently open the filter cage and slide the cage towards the handle, twist until it snaps into place. Rotate the filter brush from side to side and upwards and downwards around filter mesh to clean. A person shaking the excess water from the filter cage. Slide the filter brush towards the filter.
