Common questions
Common Questions
28 totalWhat are the power output levels and what are they used for?
The microwave has five power levels: Low (17%) for softening ice cream, Med. Low/Defrost (33%) for soups, stews, and defrosting, Med. (55%) for stew and fish, Med. High (77%) for rice, fish, and chicken, and High (100%) for reheating, boiling water, and beverages. Turn the POWER knob to the desired level, then set the TIMER knob to your required cooking time. The oven will automatically start cooking once both are set. (Page 13)
What should I do if my microwave oven won't start?
Check that the power cord is plugged in tightly — unplug it and plug it back in after 10 seconds. Also verify that the fuse has not blown or the circuit breaker has not tripped, and test the outlet with another appliance to confirm it is working. Additionally, make sure the door is closed properly, as the oven will not start if the door is not fully shut. (Page 15)
How do I properly clean my microwave oven?
Always unplug the appliance before cleaning, then wipe the cavity with a slightly damp cloth and clean accessories in soapy water. The door frame, seal, and neighboring parts should be cleaned carefully with a damp cloth. Do not use harsh abrasive cleaners or sharp metal scrapers on the oven door glass, as these can scratch the surface and may cause the glass to shatter. (Page 8)
Is it normal for steam to accumulate on the oven door during cooking?
Yes, steam accumulating on the oven door is completely normal. During cooking, steam comes out of food and most exits through the vents, but some may accumulate on cooler surfaces like the oven door. This is not a malfunction and requires no action. (Page 15)
What is the easiest way to clean stubborn food residue from the oven cavity?
Place half a lemon in a bowl, add 300ml (half a pint) of water, and heat on 100% microwave power for 10 minutes. After heating, wipe the oven clean using a soft, dry cloth. This tip makes cleaning the cavity walls much easier. (Page 8)
What clearances are required when installing the microwave?
The oven requires a minimum clearance of 30cm above it and a minimum clearance of 20cm between the oven and any adjacent walls. The minimum installation height is 85cm, and the rear surface of the appliance must be placed against a wall. Do not remove the legs from the bottom of the oven, and never install the oven over a range cooktop or other heat-producing appliance. (Page 12)
Show 22 more questions
What materials should never be used inside the microwave oven?
What are the specifications for this microwave oven?
Is it safe to run the microwave oven with no food inside?
Can children use the microwave oven, and are there any supervision requirements?
What is the model number of this Kenmore microwave?
Where can I find the complete user manual for my Kenmore 721.80042 microwave?
What should I do if I need troubleshooting help for my microwave?
Where should I look for safety information for my Kenmore microwave?
How do I set up my new Kenmore microwave?
How do I access the full manual content if I cannot view the embedded PDF?
What are the specifications for the Kenmore 721.80042 microwave?
Where can I find maintenance and care instructions for my Kenmore microwave?
How do I set up my Kenmore microwave for the first time?
My microwave won't turn on. What should I do?
How do I defrost food using my Kenmore microwave?
What are the key specifications for the Kenmore 721.80042 microwave?
How should I clean and maintain my Kenmore microwave?
What safety warnings should I know about before using my microwave?
How do I properly install the Kenmore microwave in my kitchen?
What should I do if my microwave is making unusual noises?
Are there any foods I shouldn't heat in this microwave?
What do I do if my microwave stops heating food properly?
Full Manual
16 pages
Instruction Manual
Microwave OvenMw2-Mg20Pe(Bk)
Read these instructions carefully before using your microwave oven, and keep it carefully.If you follow the instructions, your oven will provide you with many years of good service.Save These Instructions Carefully
Contents.
PRECAUTIONS .....................................................................................................3 IMPORTANT SAFETY INSTRUCTIONS ..........................................................4To Reduce The Risk Of Injury To Persons Grounding
INSTALLATION .....................................................................................................7 CLEANING ............................................................................................................8Materials You Can Use In Microwave Oven ..................................9
Materials To Be Avoided In Microwave Oven
...........................
10 SET UP & INSTALLATION ............................................................................11 OPERATION ........................................................................................................13 TROUBLE SHOOTING ......................................................................................15........
3
Precautions
Precautions To Avoid Possible Exposure To Excessive
Microwave Energy
(a) Do not attempt to operate this oven with the door open since this can result in harmful exposure to microwave energy. It is important not to break or tamper with the safety interlocks. (b)Do not place any object between the oven front face and the door or allow cleaner residue to accumulate on sealing surface. (c) WARNING: If the door or door seals are damaged, the oven must not be operated until it has been repaired by a competent person.Addendum
If the apparatus is not maintained in a good state of cleanliness, its surface could be degraded and affect the life span of the apparatus and lead to a dangerous situation.Specifications
Model:Mw2-Mg20Pe(Bk)
Rated Voltage: 230V~ 50Hz Input Power (Microwave):1050W
Output Power (Microwave):700W
Capacity:20L
Turntable Diameter: Φ 255mm Outside Dimensions (Wx D x H): 440x356x259mm Net Weight: Approx. 11.1 kg Grill Power:1000W
4
Important Safety Instructions
To reduce the risk of fire, electric shock, injury to persons or exposure to excessive microwave oven energy when using your appliance, follow basic precautions, including the following:Exposureto Excessive Microwave Energy".
5
6
Read Carefully And Keep For Future Reference
7 To Reduce the Risk of Injury to Persons Grounding Installation
Danger
Electric Shock HazardTouching some of the internal components can cause serious personal injury or death. Do not disassemble this appliance.Warning
Electric Shock HazardImproper use of the grounding can result in electric shock. Do not plug into an outlet until appliance is properly installed and grounded. This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire for the electric current. This appliance is equipped with a cord having a grounding wire with a grounding plug. The plug must be plugged into an outlet that is properly installed and grounded. Consult a qualified electrician or serviceman if the grounding instructions are not completely understood or if doubt exists as to whether the appliance is properly grounded. If it is necessary to use an extension cord, use only a 3-wire extension cord.
8
Cleaning
Be sure to unplug the appliance from the power supply.Utensils
Caution
Personal Injury Hazard It is hazardous for anyone other than a competent person to carry out any service or repair operation that involves the removal of a cover which gives protection against exposure to microwave energy. See the instructions on "Materials you can use in microwave oven or to be avoided in microwave oven." There may be certain non- metallic utensils that are not safe to use for microwaving. If in doubt, you can test the utensil in question following the procedure below. Utensil Test:Note: Keep The Cavity And Wave Guide Area Clean
9 Materials you can use in microwave oven Utensils Remarks Browning dish Follow manufacturer's instructions. The bottom of browning dish must be at least 3/16 inch (5mm) above the turntable. Incorrect usage may cause the turntable to break. Dinnerware Microwave-safe only. Follow manufacturer's instructions. Do not use cracked or chipped dishes. Glass jars Always remove lid. Use only to heat food until just warm. Most glass jars are not heat resistant and may break. Glassware Heat-resistant oven glassware only. Make sure there is no metallic trim. Do not use cracked or chipped dishes. Oven cooking bags Follow manufacturer's instructions. Do not close with metal tie. Make slits to allow steam to escape. Paper plates and cups Use for short-term cooking/warming only. Do not leave oven unattended while cooking. Paper towels Use to cover food for reheating and absorbing fat. Use with supervision for a short-term cooking only. Parchment paper Use as a cover to prevent splattering or a wrap for steaming. Plastic Microwave-safe only. Follow the manufacturer's instructions. Should be labeled "Microwave Safe". Some plastic containers soften, as the food inside gets hot. "Boiling bags" and tightly closed plastic bags should be slit, pierced or vented as directed by package. Plastic wrap Microwave-safe only. Use to cover food during cooking to retain moisture. Do not allow plastic wrap to touch food. Wax paper Use as a cover to prevent splattering and retain moisture.
10 Utensils Remarks Aluminum tray May cause arcing. Transfer food into microwave-safe dish. Food carton with metal handle May cause arcing. Transfer food into microwave-safe dish. Metal or metal- trimmed utensils Metal shields the food from microwave energy. Metal trim may cause arcing. Metal twist ties May cause arcing and could cause a fire in the oven. Paper bags May cause a fire in the oven. Plastic foam Plastic foam may melt or contaminate the liquid inside when exposed to high temperature. Wood Wood will dry out when used in the microwave oven and may split or crack. Materials to be avoided in microwave oven
11
Set Up & Installation
Setting Up Your Oven
Names of Oven Parts and Accessories. Remove the oven and all materials from the carton and oven cavity. Your oven comes with the following accessories: Glass tray1 Turntable ring assembly 1 Turntable Shaft 1 Grill Rack 1 Instruction Manual 1 A) Control panel B) Turntable shaft C) Turntable ring assembly D) Glass tray E) Observation window F) Door assembly G) Safety interlock system a. Never place the glass tray upside down. Follow the instruction to place the glass tray on the turntable ring with correct direction. The glass tray should rotate smoothly. b. Both glass tray and turntable ring assembly must always be used during cooking. c. All food and containers of food are always placed on the glass tray for cooking. d. If glass tray or turntable ring assembly cracks or breaks, contact your nearest authorized service center. Turntable Installation Hub (underside) Turntable shaft Glass tray Turntable ring assembly Grill Rack (Can not be used in microwave function and must be placed on the glass tray)H
H) Waveguide cover
12 Remove all packing material and accessories. Examine the oven for any damage such as dents or broken door. Do not install if oven is damaged.Cabinet: Remove any protective film found on the microwave oven cabinet surface. Do not remove the light brown waveguide cover that is attached to the oven cavity to protect the magnetron. Installation
Countertop Installation
13
Operation
POWER knob TIMER knob Function/Power Output Application Low 17% Micro. Soften Ice Cream Med. Low (Defrost) 33% Micro. Soup Stew, Soften Butter or Defrost Med. 55% Micro. Stew, Fish Med. High 77% Micro. Rice, Fish, Chicken, Ground Meat High 100% Micro. Reheat, Milk, Boil Water, Vegetables, Beverage To set cooking power by turning POWER knob to desired level.
14 Function/Power Output Application Combi.1 80% Grill & 20% Micro. Sausage, Lamb, Kabobs, Seafood, Steak Combi.2 70% Grill & 30% Micro. Chicken Pieces, Chicken Breasts, Pork Chops Combi.3 60% Grill & 40% Micro. Whole Chicken 100% Grill Bake Bread, Slice Food Notice: When removing food from the oven, please ensure that the oven power is switched off by turning the timer switch to O (zero). Failure to do so, and operating the microwave oven without food in it, can result in overheating and damage to the magnetron.
15
Trouble Shooting
Normal Microwave oven interfering TV reception Radio and TV reception may be interfered when microwave oven operating.It is similar to the interference of small electrical appliance, like mixer, vacuum cleaner, and electric fan.It is normal. Dim oven light In low power microwave cooking, oven light may become dim. It is normal. Steam accumulating on door, hot air out of vents In cooking, steam may come out of food. Most will get out from vents. But some may accumulate on cool place like oven door. It is normal. Oven started accidentally with no food in. It is forbidden to run the until without any food inside. It is very dangerous. Normal Possible Cause Remedy Oven can not be started. (1) Power cord not plugged in tightly. Unplug. Then plug again after 10 seconds. (2) Fuse blowing or circuit breaker works. Replace fuse or reset circuit breaker (repaired by professional personnel of our company) (3) Trouble with outlet. Test outlet with other electrical appliances. Oven does not heat. (4) Door not closed well. Close door well.Pn:16170000A91892
