HP LaserJet Pro 200 Color MFP M276 Multifunction Printer manual
Printers · 23 Q&As

HP LaserJet Pro 200 Color MFP M276 Multifunction Printer

Ask AI

— answers from the official manual

AI-powered answers from the official manual. Verify critical info.

Common questions

Common Questions

23 total
1

What should I avoid touching when installing a new toner cartridge?

Do not touch the imaging drum on the bottom of the toner cartridge. Fingerprints on the imaging drum will negatively affect print quality. (Page 12)

2

How do I replace a toner cartridge in the HP LaserJet Pro 200 Color MFP M276?

Open the front cover, pull out the toner cartridge drawer, and lift the old cartridge straight up by its handle to remove it. Insert the new cartridge after gently rocking it back and forth to distribute the toner evenly, remove the plastic shield from the bottom, and pull the seal tape straight up from the left side. Close the cartridge drawer and front cover, and place the old cartridge in the new cartridge's packaging for recycling. (Pages 10-13)

3

How do I perform duplex (two-sided) printing from Windows?

In your software program, click Print, select the product, and click Properties or Preferences, then click the Finishing tab and check the 'Print on Both Sides (Manually)' checkbox. Click OK to print the first side, then remove the printed stack from the output bin and reload it print-side down into the input tray in the same orientation. Press OK on the control panel to print the second side. (Pages 17-18)

4

How do I optimize copy quality on the HP LaserJet Pro 200 Color MFP M276?

Place your document on the scanner glass or in the document feeder, touch the Copy button on the home screen, then touch Settings and scroll to the Optimize button. You can select from Auto Select (default), Mixed (for text and graphics), Text (mostly text), or Picture (mostly graphics), then touch Black or Color to start copying. (Page 8)

5

How do I change the color print options in Windows for the HP LaserJet Pro 200 Color MFP M276?

From your software program, select the Print option, select the product, click Properties or Preferences, then click the Color tab. Choose Automatic for most color print jobs, or Manual to adjust color settings individually; HP recommends that only color graphics experts change manual color settings, as doing so may affect output. (Page 15)

6

How do I print a color document in grayscale on the HP LaserJet Pro 200 Color MFP M276?

In the printer Properties or Preferences dialog, click the Color tab and select the 'Print in Grayscale' option to print color documents using black and gray shades. This option is useful for documents intended to be photocopied or faxed, or to save color toner when printing drafts. (Page 15)

Show 17 more questions

Full Manual

16 pages
Page 1

Laserjet Pro 200 Color Mfp

M276

Page 3

HP LaserJet Pro 200 color MFP

M276 系列

Quick Reference Guide

Page 5

目录 快速参考指南 ............................................................................................................................... 1 优化复印质量 ........................................................................................................................ 2 使用 HP 扫描软件进行扫描 (Windows) ................................................................................... 3 更换碳粉盒 ........................................................................................................................... 4 检查扫描仪玻璃板上是否有灰尘和污渍 .................................................................................... 8 更改颜色选项 (Windows) ....................................................................................................... 9 打印清洁页 ......................................................................................................................... 10 通过 Windows 执行双面打印 ............................................................................................... 11

Zhcn

iii

Page 7

快速参考指南

Zhcn

1

Page 8

优化复印质量 可使用以下复印质量设置: ● 自动选择:如果对复印质量要求不高,则可以使用此设置。此项为默认设置。 ● 混合:对同时包含文本和图形的文档使用此设置。 ● 文本:对所含内容大部分是文本的文档使用此设置。 ● 图片:对所含内容大部分是图形的文档使用此设置。

  • 将文档放在扫描仪玻璃板上或文档进纸器
  • 中。

  • 在主页屏幕上,轻触复印按钮。
  • 轻触设置按钮,然后滚动查看并轻触优化按
  • 钮。轻触箭头按钮浏览选项,然后轻触选项 以选中它。

  • 轻触黑色或彩色按钮开始复印。
  • 2 快速参考指南

    Zhcn

    Page 9

    使用 HP 扫描软件进行扫描 (Windows)

  • 双击计算机桌面上的 Hp 扫描图标。

  • 选择一个扫描快捷方式,然后根据需要调整设置。
  • 单击扫描。
  • 注: 单击高级设置访问更多选项。 单击创建新快捷方式,创建一个自定义的设置集,然后保存到快捷方式列表中。

    Zhcn

    使用 HP 扫描软件进行扫描 (Windows) 3

    Page 10

    更换碳粉盒

  • 打开前挡盖。
  • 拉出碳粉盒抽屉。
  • 握住碳粉盒上的手柄,然后竖直向上拉起碳
  • 粉盒以将其卸下。

    4 快速参考指南

    Zhcn

    Page 11

  • 从包装中取出新碳粉盒。
  • 缓缓地前后摇动碳粉盒,以使碳粉均匀分散
  • 在碳粉盒中。

  • 从新碳粉盒的底部取下塑料板。
  • Zhcn

    更换碳粉盒 5

    Page 12

  • 不要触摸碳粉盒底部的成像鼓。如果成像鼓
  • 上有手印,将影响打印质量。

  • 将新碳粉盒插入产品中。
  • 竖直向上拉碳粉盒左侧的拉坏,以完整地取
  • 出密封胶带。撕下密封胶带。

    6 快速参考指南

    Zhcn

    Page 13

  • 关闭碳粉盒抽屉。
  • 关闭前挡盖。
  • 将旧碳粉盒及塑料护罩放入新碳粉盒的包装
  • 箱中。请按照包装箱中附带的回收说明进行 操作。

    Zhcn

    更换碳粉盒 7

    Page 14

    检查扫描仪玻璃板上是否有灰尘和污渍 随着时间的推移,在扫描仪玻璃板和白色塑料底板上聚集的灰尘斑点会影响扫描作业的质量。按照以下步 骤清洁扫描仪玻璃板和白色塑料底板。

  • 用电源开关关闭本产品,然后从电气插座上
  • 拔下电源线。

  • 打开扫描仪盖。
  • 使用浸有非磨蚀玻璃清洁剂的软布或海绵清
  • 洁扫描仪玻璃板和白色塑料底板。 注意: 不要使用研磨剂、丙酮、苯、氨水、 普通酒精或四氯化碳擦拭产品的任何部分, 因为它们可能损坏产品。切勿将液体直接倒 在玻璃板或压板上。液体可能会渗入并损坏 产品。

  • 用软皮或纤维海绵擦干玻璃板和白色塑料底
  • 板,以免留下污点。

  • 插上产品插头,然后使用电源开关打开产品
  • 电源。

    8 快速参考指南

    Zhcn

    Page 15

    更改颜色选项 (Windows)

  • 从软件程序中,选择打印选项。
  • 选择产品,然后单击属性或首选项按钮。
  • 单击颜色选项卡。
  • 单击自动或手动设置。
  • ● 自动设置:为大多数彩色打印作业选择 此设置。 ● 手动设置:选择此设置可单独调整颜色 设置,而其它设置仍保持不变。 注: 手动更改颜色设置可能影响输

    出。Hp 建议只由彩色图形专家更改这

    些设置。

  • 单击灰度打印选项以用黑色和灰度阴影打印
  • 彩色文档。使用此选项打印要复印或传真的 彩色文档。也可以使用此选项来打印草稿或 节省彩色碳粉。

  • 单击确定按钮。
  • Zhcn

    更改颜色选项 (Windows) 9

    Page 16

    打印清洁页

  • 在主页屏幕上,轻触设置
  • 按钮。
  • 轻触服务菜单。
  • 轻触清洁页按钮。
  • 提示后请装入普通的 letter 或 A4 纸。
  • 轻触确定按钮开始清洁过程。
  • 产品先打印一面,然后提示从出纸槽中取出纸,再保持相同方向将纸重新装入纸盘 1。等待直到此 过程结束。丢弃打印的页面。 10 快速参考指南

    Zhcn

    Page 17

    通过 Windows 执行双面打印

  • 在软件程序的文件菜单中,单击打印。
  • 选择产品,然后单击属性或首选项按钮。
  • 单击完成选项卡。
  • Zhcn

    通过 Windows 执行双面打印 11

    Page 18

  • 选中双面打印(手动)复选框。单击确定按
  • 钮打印作业的第一面。

  • 从出纸槽中取出打印的纸叠,保持同一方向,
  • 将纸叠打印面朝下装入进纸盘中。

  • 在控制面板上,按下确定按钮以打印作业的
  • 第二面。

    12 快速参考指南

    Zhcn

    Page 20

    © 2012 Hewlett-Packard Development Company, L.P. www.hp.com
