30 totalWhat should I do when the CLEAN light is flashing and there is a beeping sound?
A flashing CLEAN light accompanied by a beeping sound indicates a control error. Press the START/RESET pad to turn off the beeper and the dishwasher will attempt to reset, then restart the wash cycle. If the error continues, call for service. (Page 6)
What is the correct water temperature for effective cleaning in the GSD4500?
The entering water must be at least 120°F and not more than 150°F for effective cleaning and to prevent dish damage. You can check the water temperature using a candy or meat thermometer by running the hot water faucet nearest the dishwasher into a glass until the temperature stops rising. (Page 6)
How do I unlock the control panel on the GSD4500?
To unlock the dishwasher, touch the LOCK pad twice within 3 seconds. The light above the LOCK pad will turn off, making all pads operative again. The LOCK feature is activated the same way — by touching the LOCK pad twice within 3 seconds. (Page 5)
How do I remove suds from the tub if I accidentally used the wrong detergent?
Open the dishwasher and let suds evaporate, then add 1 gallon of cold water to the tub. Close and latch the dishwasher, then pump out the water by pressing the START/RESET pad and immediately pressing it again. Repeat if necessary, and in the future use only automatic dishwasher detergents such as Cascade® or Electrasol®. (Page 12)
How do I add a dish I forgot to load after the cycle has already started?
A forgotten dish can be added any time before the main wash. Push the door latch to the left, and once the water calms, open the door — be aware that steam may rise out. Add the forgotten dish, then close the door and push the latch to the far right. (Page 7)
How do I fix spots and film on glasses and flatware?
Use Jet-Dry® rinse agent to remove spots and prevent new film buildup. To remove stubborn pre-existing film, run the longest cycle without detergent or metal utensils, and after 18–22 minutes pour 2 cups of white vinegar into the bottom of the dishwasher and allow the cycle to complete. If vinegar doesn't work, repeat the process using 1/4 cup of citric acid crystals instead. (Page 13)
Show 24 more questions
How long are the wash cycles and how much water does the GSD4500 use?
What is covered under the GSD4500 warranty?
How should I load knives and silverware in the dishwasher?
What should I do to winterize or protect the GSD4500 dishwasher from freezing?
What do the flashing display lights mean on my GSD4500 and what should I do?
What is the correct water temperature for the GSD4500 dishwasher?
How do I cancel or change a cycle after the dishwasher has already started?
How do I use the Control Lock feature to prevent accidental operation?
Why isn't my dishwasher draining properly, and how do I fix it?
How do I remove spots and film from glasses and flatware?
How do I load silverware safely in the GSD4500?
What detergents are approved for use in the GSD4500 dishwasher?
How long are the wash cycles and how much water does each cycle use on the GSD4500?
What warranty coverage does the GSD4500 dishwasher come with?
What water temperature should I use with my GSD4500 dishwasher?
How do I add a dish that I forgot before the main wash cycle starts?
What should I load in the upper rack of my dishwasher?
Why is there water standing in the bottom of my dishwasher tub?
What type of detergent should I use in my GSD4500?
How do I use the Delay Start feature on my dishwasher?
What should I do if my dishwasher won't drain?
How can I remove spots and film from my glasses?
How do I lock the controls on my dishwasher?
What is the warranty coverage for my GSD4500 dishwasher?
Full Manual
16 pages
GEAppliances.com
Gsd4500
Gsd4800
Owner’s Manual Dishwashers165D4700P257 49-5931 10-01 Jr
Safety Instructions . . . . . . . . 2, 3 Operating Instructions Care and Cleaning . . . . . . . . . . .10 Control Panels . . . . . . . . . . . . . . .4 Control Settings . . . . . . . . . . . . . 5 Flashing Display Lights . . . . . . . .6 Loading the Dishwasher Racks . . . . . . . . . .8, 9 Optional Accessories . . . . . . . . .11 Using the Dishwasher . . . . . . .6, 7 Troubleshooting Tips . . . . 12, 13 Consumer Support Consumer Support . . . Back Cover Warranty . . . . . . . . . . . . . . . . . . 15 Write the model and serial numbers here: Model # ____________________ Serial # ____________________ You can find them on a label on the tub wall just inside the door.
2 Operating Instructions Safety Instructions Consumer Support Troubleshooting Tips I Do not tamper with controls. I Do not abuse, sit on, or stand on the door or dish rack of the dishwasher. I Do not discard a dishwasher without first removing the door of the washing compartment. I Do not store or use combustible materials, gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. I Do not allow children to play around dishwasher when opening or closing door due to the possibility of small fingers being pinched in door. I Do not allow children to play with, on or around this appliance or any discarded appliance.
Do Not…
Warning!
Important Safety Information.
Read All Instructions Before Using.
Warning!
For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, personal injury, or death. Under certain conditions hydrogen gas may be produced in a water heater that has not been used for two weeks or more. HYDROGEN GAS IS EXPLOSIVE. If the hot water has not been used for two weeks or more, prevent the possibility of damage or injury by turning on all hot water faucets and allow them to run for several minutes. Do this before using any electrical appliance which is connected to the hot water system. This simple procedure will allow any built-up hydrogen gas to escape. Since the gas is flammable, do not smoke or use an open flame or appliance during this process.Water Heater Safety
Use this appliance only for its intended purpose as described in this Owner’s Manual.Proper Installation And Maintenance
This dishwasher must be properly installed and located in accordance with the Installation Instructions before it is used. If you did not receive an Installation Instructions sheet with your dishwasher, you can receive one by visiting our website at GEAppliances.com. I Connect to a grounded metal, permanent wiring system; or run an equipment-grounding conductor with the circuit conductors and connect to the equipment-grounding terminal or lead of the appliance. I Improper connection of the equipment- grounding conductor can result in a risk of electric shock. Check with a qualified electrician or service representative if you are in doubt whether the appliance is properly grounded. I Use supply conductors rated at least 75°C(167°F).
I Dispose of discarded appliances and shipping or packing material properly. I Do not attempt to repair or replace any part of your dishwasher unless it is specifically recommended in this manual. All other servicing should be referred to a qualified technician. I To minimize the possibility of electric shock, disconnect this appliance from the power supply before attempting any maintenance. NOTE: Turning the dishwasher off does not disconnect the appliance from the power supply. We recommend having a qualified technician service your appliance.
Consumer Support Troubleshooting Tips Operating Instructions Safety Instructions 3
Proper Disposal Of The Dishwasher
Junked or abandoned dishwashers are dangerous…even if they will sit for “just a few days.” If you are getting rid of your old dishwasher, please follow the instructions below to help prevent accidents. Before You Throw Away Your Old Dishwasher: ITake off the door of the washing compartment or remove the door latch keeper (as shown).Warning! Risk Of Child Entrapment
When Using Your Dishwasher
IUse only powder, tabs, liquid detergents or rinse agents recommended for use in a dishwasher and keep them out of the reach of children. Cascade®, Cascade Complete® and Electrasol® Automatic Dishwashing Detergents, and Jet-Dry® rinse agent have been approved for use in all GE dishwashers. ILocate sharp items so that they are not likely to damage the door seal. ILoad sharp knives with the handles up to reduce the risk of cut-type injuries. IDo not wash plastic items unless marked dishwasher-safe or the equivalent. For plastic items not so marked, check the manufacturer’s recommendations. INon-Dishware Items: Do not wash items such as electronic air cleaner filters, furnace filters and paint brushes in your dishwasher. Damage to dishwasher and discoloration or staining of dishwasher may result. IDo not touch the heating element during or immediately after use. IDo not operate your dishwasher unless all enclosure panels are properly in place. IClose supervision is necessary if this appliance is used by or near children. ILoad light, plastic items so they will not become dislodged and drop to the bottom of the dishwasher—they might come into contact with the heating element and be damaged.Read And Follow This Safety Information Carefully.
Save These Instructions
Door latch keeper GEAppliances.com
Cycle Chart Model Cycle Water Usage (gal.) Cycle Time (min.)
Gsd4500
Pots & Pans 11.5 66 Normal Wash 9.9 58 Light Wash 8.2 52 Rinse Only 1.6 4Gsd4800
Pots & Pans 11.5 66 Normal Wash 9.9 58 Light Wash 8.2 52 China Crystal 8.2 36 Rinse Only 1.6 4 Operating Instructions Safety Instructions Consumer Support Troubleshooting Tips 4 About the dishwasher control panel.Clean
Options
Cycle Selections
Start
Reset
Delay
4 6 8Start
Lock
(2 Times)
Heated
Dry
Pots
& Pans
Hi Temp
Wash
Hi Temp
Rinse
Rinse
Only
Light
Wash
Normal
Clean
Options
Cycle Selections
Start
Reset
Delay
2 4 8Start
Lock
(2 Times)
Heated
Dry
Pots
& Pans
Hi Temp
Wash
Hi Temp
Rinse
Rinse
Only
China
Crystal
Light
Wash
Normal
Model GSD4800 Models GSD4500 You can locate your model number on the tub wall just inside the door. Throughout this manual, features and appearance may vary from your model.
Consumer Support Troubleshooting Tips Operating Instructions Safety Instructions Options The light above the selected pad will be ON to indicate which OPTION has been selected. HI TEMP Turns on the heater in all postrinse and final rinse cycles to help prevent spotting on dishware. This option may be turned RINSE ON or OFF during the wash cycle. HI TEMP Energizes the heater to boost water temperature in all prewash and main wash fill cycles. Recommended for use with WASH heavily soiled dishes. Option may be turned ON or OFF during the wash cycle. HEATED DRY Shuts off the drying heat option. Dishes air dry naturally and energy is saved. You can prop the door open after the OFF CLEAN light illuminates. HEATED DRY Turns the heater on for fast drying. This cycle will extend the time to your wash cycle by 30 minutes. NOTE: Cannot be ON selected with RINSE ONLY cycle. LOCK When the LOCK pad is touched twice within 3 seconds, all pads become inoperative. You can lock the controls to prevent any selections from being made. Or you can lock the controls after you have started a cycle or selected DELAY START so the cycle or DELAY START is not interrupted. Children cannot accidentally start dishwasher by touching pads with this option selected. To unlock the dishwasher after it has been locked, touch the LOCK pad twice within 3 seconds. The light above the LOCK pad will turn off. DELAY START You can delay the start of a wash cycle for up to 8 hours. Press the DELAY START pad to choose the number of hours you want to delay the start of the cycle. The machine will count down and start automatically at the correct time. Pressing the START/RESET button will cancel the DELAY START selection. NOTE: If you forget to latch the door, a reminder signal will beep until you do so. RESET To change a cycle after washing starts, touch the START/RESET pad to cancel the cycle. After water is pumped out and the motor stops, you can reprogram and restart the dishwasher. This will take approximately 90 seconds. Cycle Selections The light above the selected pad will be ON to indicate which CYCLE SELECTION has been selected. POTS & PANS For heavily soiled dishes or cookware with dried-on or baked-on soils. Everyday dishes may be included. This cycle will not remove burned-on foods. NORMAL For loads of everyday dishes, glasses and cookware with medium soils. NOTE: Many dishes have lighter soil than normal. Choosing a cycle other than NORMAL will save energy and water. LIGHT WASH For dishes with light soils. CHINA CRYSTAL For lightly soiled china and crystal. RINSE ONLY For rinsing partial loads that will be washed later. Do not use detergent. Start Close and latch the door. Touch the START/RESET pad to begin the cycle. Water fill begins and approximately 40 seconds later the wash action begins. NOTE: The dishwasher remembers your last cycle so you don’t have to reprogram each time. When the dishwasher is loaded and the door latch is in the locked position, the control panel lights will be ON and display the last settings you selected. If you don’t want to change any of the settings, simply touch the START/RESET pad to begin the cycle. Also, if a power failure occurs, NORMAL and HEATED DRY will automatically be programmed. Make any new selections and touch the START/RESET pad to begin the cycle. Control Settings GEAppliances.com 5 Clean This light is illuminated when a wash cycle is complete. The light will stay ON until the door is opened.
Flashing display lights. Operating Instructions Safety Instructions Consumer Support Troubleshooting Tips 6 Lights What It Means What To Do This is normal. Allow the dishwasher to drain and reset before you start a new wash cycle. The START/RESET pad has been pressed. Control Error Press the START/RESET pad to turn off the beeper. If the CLEAN light continues to flash, call for service. Control Error Press the START/RESET pad to turn off the beeper and the dishwasher will attempt to reset. Then restart the wash cycle. If this error continues, call for service.
Normal
Plus A
Beeping
Sound
Reset
Start
Start
Clean
Clean
Plus A
Beeping
Sound
Filling the Dispenser Fill the rinse agent dispenser until it reaches the bottom of lip inside the opening. Replace cap. To check if rinse agent is needed: On some models, remove the cap and look into the dispenser. On some models, press the clear center of the fill cap 2 or 3 times. If rinse agent fills the center of the cap, you have enough. A full dispenser should last about one month. If rinse agent spills, wipe up the excess. Check the Water Temperature The entering water must be at least 120°F and not more than 150°F for effective cleaning and to prevent dish damage. Check the water temperature with a candy or meat thermometer. Turn on the hot water faucet nearest the dishwasher, place the thermometer in a glass and let the water run continuously into the glass until the temperature stops rising. Use Jet-Dry ® Rinse Agent Jet-Dry® rinse agent removes spots and prevents new film buildup on your dishes, glasses, flatware, cookware and plastic. Using the dishwasher.
Forget to Add a Dish? A forgotten dish can be added any time before the main wash. Push the door latch to the left. Once the water calms, open the door. Steam may rise out of the dishwasher. Add forgotten dishes. Close the door and push the latch to the far right. 4 3 2 1 Proper Use of Detergent Use only detergent specifically made for use in dishwashers. Cascade®, Cascade® Complete and Electrasol® Automatic Dishwashing Detergents have been approved for use in all GE dishwashers. Keep your detergent fresh and dry. Don’t put powder detergent into the dispenser until you’re ready to wash dishes. The amount of detergent to use depends on whether your water is hard or soft. With hard water, you need extra detergent. With soft water, you need less detergent. Protect your dishes and dishwasher by contacting your water department and asking how hard your water is. Twelve or more grains is extremely hard water. A water softener is recommended. Without it, lime can build up in the water valve, which could stick while open and cause flooding. Too much detergent with soft water can cause a permanent cloudiness of glassware, called etching. You’ll find two detergent dispensers on the inside door of your dishwasher. All wash cycles—except RINSE ONLY—require detergent in the main cup. Wash cycles with two washes will also use the open cup. When using automatic dishwashing detergent tabs, simply place one tab in the main cup and close. NOTE: To open detergent cup after it has been closed, unlatch the door. Press the START/RESET pad three times within two seconds and the detergent cup will release. A snapping sound may be heard. Open cup Main cup 7 Consumer Support Troubleshooting Tips Operating Instructions Safety Instructions GEAppliances.com Using the Dishwasher Door The door must be closed and locked into place to select a LOAD SELECTION or an OPTION. If the door is opened during a cycle and left open, the dishwasher will beep once every minute until the door is closed and latched into place. 2 1
Loading the dishwasher racks. Operating Instructions Safety Instructions Consumer Support Troubleshooting Tips 8 For best dishwashing results, follow these loading guidelines. Features and appearance of racks and silverware baskets may vary from your model. The Wash Tower Keep the center area clear in the lower rack. The wash tower rises through the center of the lower rack during the wash and rinse portions of the cycle. Don’t block or load tall things next to the Wash Tower. Also, be careful not to let a portion of an item such as a pot or dish handle extend through the bottom rack. This could block the wash arm and cause poor washing results. Lower Rack When loading the lower rack, do not load large platters or trays in the front right corner. They may prevent detergent from circulating during the wash cycle. The lower rack is best used for plates, saucers and cookware. Large items such as broiler pans and racks should go along the sides. Load platters, pots and bowls along the sides, in corners, or in the back. The soiled side of items should face the center of the rack. Upper Rack The upper rack is for glasses, cups and saucers. Cups and glasses fit best along the sides. This is also a secure place for dishwasher-safe plastics. The upper rack is good for all kinds of odd-shaped utensils. Saucepans, mixing bowls and other items should be placed face down. The cup shelf (on some models) may be placed in the up or down position to add flexibility. Secure larger dishwasher-safe plastics over two fingers when possible. Make sure small plastic items are secure so they can’t fall onto the heating element. Check to make sure that tall items will not block the rotation of the top wash arm.
9 Consumer Support Troubleshooting Tips Operating Instructions Safety Instructions GEAppliances.com Silverware Basket Put flatware in the removable basket with fork and knife handles up to protect your hands. Place spoons in the basket with handles down. Mix knives, forks and spoons so they don’t nest together. Distribute evenly. Small plastic items, such as measuring spoons and lids from small containers, should go in the bottom of the silverware basket with silverware on top. Don’t let any item extend through bottom. Single basket
Operating Instructions Safety Instructions Consumer Support Troubleshooting Tips 10 Caring for the dishwasher. To clean the control panel use a lightly dampened cloth then dry thoroughly. To clean the exterior use a good appliance polish. Never use sharp object, scouring pads or harsh cleaners on any part of the dishwasher. If your dishwasher is left in an unheated place during the winter, ask a service technician to: Cut off electrical power to the dishwasher. Remove fuses or trip circuit breaker. Turn off the water supply and disconnect the water inlet line from the water valve. Drain water from the inlet line and water valve. (Use a pan to catch the water.) Reconnect the water inlet line to the water valve. Remove the plastic sump cover in the tub bottom and use a sponge to soak up water in the rubber boot. 5 4 3 2 1 Sump cover screws An air gap protects your dishwasher against water backing up into it if a drain clogs. The air gap is not a part of the dishwasher. It is not covered by your warranty. Not all plumbing codes require air gaps, so you may not have one. The air gap is easy to clean. Turn off the dishwasher and lift off the chrome cover. Unscrew the plastic cap and clean with a toothpick. 2 1 Check the air gap any time your dishwasher isn’t draining well. Two types of air gaps Does Your Dishwasher Have an Air Gap? Protect Against Freezing
11 Consumer Support Troubleshooting Tips Operating Instructions Safety Instructions About optional accessories. GEAppliances.com You can change the door and lower access panel appearance of your dishwasher by ordering one of these optional accessories: I 1/4” Wood Panel Trim Kit I 3/4” Trimless Wood Panel Kit These accessories are available at extra cost (VISA, MasterCard or Discover cards accepted) by calling 800.626.2002. Specify accessory number when ordering. Descriptions of Optional Accessories Wood panel trim kit–This accessory contains trim and instructions for you to supply and install a 1⁄4″ thick decorative wood door and lower access panel: I GPF425A (Almond) I GPF425C (Bisque) I GPF425B (Black) I GPF425W (White) NOTE: The GPF100 dishwasher door spring kit must also be ordered and installed when the door panel weighs four lbs. or more. Trimless wood panel kit–This accessory contains parts and instructions for you to supply and install a 3 ⁄4″ thick decorative wood door and lower access panel:
I Gpf475
NOTE: The GPF100 dishwasher door spring kit will be included with the trimless wood panel kit and must be installed with it. About rack accessories. Baby Bottle Holder Part Number: WX69X200 I Prevents movement of baby bottles during the dishwasher cycle I Snaps easily onto any dishwasher upper rack I Eliminates hand washing I Fits all baby bottles You can order a package of 5 Baby Bottle Holders, at extra cost, by calling 800.626.2002, or through the Internet at GEAppliances.com (Visa, MasterCard or Discover cards accepted). For best results, the Baby Bottle Holder should be installed on the upper rack of the dishwasher.
Problem Possible Causes What To Do Control panel lights go Time too long between
Consumer Support Troubleshooting Tips Operating Instructions Safety Instructions Problem Possible Causes What To Do Dishes and flatware Inlet water temperature • Raise the water heater temperature to 120°F. not clean is below 120°F
Warning
Before cleaning interior, wait at least 20 minutes after a cycle for the heating element to cool down. Failure to do so can result in burns. An overall yellow or
Notes. 14 Operating Instructions Safety Instructions Consumer Support Troubleshooting Tips
15 Consumer Support Troubleshooting Tips Operating Instructions Safety Instructions What Is Not Covered: For The Period Of: GE Will Replace: One Year Any part of the dishwasher which fails due to a defect in materials or workmanship. During From the date of the this full one-year warranty, GE will also provide, free of charge, all labor and in-home service original purchase to replace the defective part. Second Year Any part of the Water Distribution System which fails due to a defect in materials or From the date of the workmanship. Associated inlet and drain plumbing parts are not covered by this warranty. original purchase During this second-year limited warranty, you will be responsible for any labor or in-home service costs. Five Years The electronic control module, if it should fail due to a defect in materials or workmanship. From the date of the During this five-year limited warranty, you will be responsible for any labor or in-home original purchase service costs. Ten Years The PermaTuf ®tub or door liner, if it fails to contain water due to a defect in materials or From the date of the workmanship. During this full warranty, GE will also provide, free of charge, all labor and original purchase in-home service to replace the defective part. GE Dishwasher Warranty. IService trips to your home to teach you how to use the product. IImproper installation. IFailure of the product if it is abused, misused, or used for other than the intended purpose or used commercially. IReplacement of house fuses or resetting of circuit breakers. IDamage to the product caused by accident, fire, floods or acts of God. IIncidental or consequential damage caused by possible defects with this appliance. ICleaning or servicing of the air gap device in the drain line. This warranty is extended to the original purchaser and any succeeding owner for products purchased for home use within the USA. In Alaska, the warranty excludes the cost of shipping or service calls to your home. Some states do not allow the exclusion or limitation of incidental or consequential damages. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. To know what your legal rights are, consult your local or state consumer affairs office or your state’s Attorney General. Warrantor: General Electric Company. Louisville, KY 40225 All warranty service provided by our Factory Service Centers, or an authorized Customer Care® technician. To schedule service, on-line, 24 hours a day, visit us at GEAppliances.com, or call
800.Ge.Cares (800.432.2737).
Staple your receipt here. Proof of the original purchase date is needed to obtain service under the warranty.
Printed in the United States Consumer Support. GE Appliances Website GEAppliances.com Have a question or need assistance with your appliance? Try the GE Appliances Website 24 hours a day, any day of the year! For greater convenience and faster service, you can now download Owner’s Manuals, order parts, catalogs, or even schedule service on-line. You can also “Ask Our Team of Experts™” your questions, and so much more... Schedule Service GEAppliances.com Expert GE repair service is only one step away from your door. Get on-line and schedule your service at your convenience 24 hours any day of the year! Or call 800.GE.CARES (800.432.2737) during normal business hours. Real Life Design Studio GEAppliances.com GE supports the Universal Design concept–products, services and environments that can be used by people of all ages, sizes and capabilities. We recognize the need to design for a wide range of physical and mental abilities and impairments. For details of GE’s Universal Design applications, including kitchen design ideas for people with disabilities, check out our Website today. For the hearing impaired, please call
