Common questions
Common Questions
30 totalWhat do the flashing display lights mean and what should I do when they appear?
Flashing lights indicate different errors depending on which light is flashing. A flashing Sensing light indicates a CleanSensor error — the dishwasher will continue to work but you should call for service. A flashing Rinsing light with a beeping sound indicates a Control Error — press START/RESET to turn off the beeper, then turn off power at the circuit breaker for 10 seconds and restore power; if it continues, call for service. A flashing Washing and Rinsing light with beeping indicates a Control or Sequence Switch Error — press START/RESET to attempt a reset, then restart the wash cycle. (Page 6)
How do I reset or cancel a cycle on the EDW3000 dishwasher?
Touch the START/RESET pad to cancel a cycle after washing has started. Allow approximately 90 seconds for the dishwasher to drain and reset before selecting a new cycle. After the water is pumped out and the motor stops, you can reprogram and restart the dishwasher. (Page 5)
What water temperature is required for effective cleaning?
The entering water must be at least 120°F and not more than 150°F for effective cleaning and to prevent dish damage. You can check the water temperature using a candy or meat thermometer by running hot water from the nearest faucet into a glass until the temperature stops rising. If the temperature is below 120°F, raise your water heater temperature accordingly. (Page 6)
How do I add a forgotten dish after the cycle has already started?
A forgotten dish can be added any time before the main wash begins. Push the door latch to the left, wait for the water to calm, then open the door — be aware that steam may rise out. Add the forgotten dish, close the door, and push the latch to the far right to resume the cycle. (Page 7)
How do I use the Delay Start feature on the dishwasher?
Press the DELAY START pad to choose the number of hours (up to 8 hours) you want to delay the start of the cycle. The machine will count down and start automatically at the correct time. Pressing the START/RESET pad will cancel the DELAY START selection. Note that if you forget to latch the door, a reminder signal will beep until you do so. (Page 5)
How do I remove spots and film from glasses and flatware?
Use Jet-Dry® rinse agent to remove spots and prevent new film buildup on dishes, glasses, flatware, cookware, and plastic. To remove stubborn pre-existing film from glassware, run the longest cycle without detergent, and after 18–22 minutes (during the main wash), open the door and pour 2 cups of white vinegar into the bottom of the dishwasher, then allow the cycle to complete. If the vinegar rinse doesn't work, repeat the process using 1/4 cup of citric acid crystals instead of vinegar. (Page 14)
Show 24 more questions
Why won't water pump out of the dishwasher tub?
How do I use and refill the rinse agent dispenser?
How do I lock the control panel to prevent accidental use by children?
What warranty coverage does the GE EDW3000 dishwasher come with?
What should I do if the rinsing light is flashing and the dishwasher is beeping?
What water temperature is required for effective cleaning in the EDW3000?
How do I reset the dishwasher if I want to change a cycle after washing has started?
How do I use the Delay Start feature on the EDW3000?
How do I lock the dishwasher controls to prevent children from accidentally starting it?
Why are my glasses coming out cloudy or etched after washing?
What should I do if there are suds in the dishwasher tub?
How do I check and refill the rinse agent dispenser?
What is covered under the EDW3000 dishwasher warranty?
How should I load sharp knives and silverware in the dishwasher?
What water temperature should I use for my dishwasher?
How do I add a forgotten dish during a cycle?
What detergents are approved for use in GE dishwashers?
How do I use the rinse agent dispenser?
What does the SANITIZED light indicate?
How do I clean the air gap in my dishwasher?
What should I do if water won't pump out of the tub?
How do I prevent cloudiness or etching on glassware?
How do I lock the control panel to prevent accidental operation?
What should I do if I accidentally close the detergent cup without adding detergent?
Full Manual
16 pages
GEAppliances.com
Edw3000
Gsd5400
Gsd5500
Gsd5560
Gsd5600
Gsd5700
Gsd5800
Gsd5900
Owner’s Manual Dishwashers165D4700P249 49-5923 11-01 Jr
Safety Instructions . . . . . . . . 2, 3 Operating Instructions Care and Cleaning . . . . . . . . . . .11 Control Panels . . . . . . . . . . . . . . .4 Control Settings . . . . . . . . . . . . . 5 Flashing Display Lights . . . . . . . .6 Loading the Dishwasher Racks . . . . . . . . . .8, 9 Loading Place Settings . . . . . . .10 Optional Accessories . . . . . . . . .12 Using the Dishwasher . . . . . . .6, 7 Troubleshooting Tips . . . . 13, 14 Consumer Support Consumer Support . . . Back Cover Warranty . . . . . . . . . . . . . . . . . . 15 Write the model and serial numbers here: Model # ____________________ Serial # ____________________ You can find them on a label on the tub wall just inside the door.
2 Operating Instructions Safety Instructions Consumer Support Troubleshooting Tips I Do not tamper with controls. I Do not abuse, sit on, or stand on the door or dish rack of the dishwasher. I Do not discard a dishwasher without first removing the door of the washing compartment. I Do not store or use combustible materials, gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. I Do not allow children to play around dishwasher when opening or closing door due to the possibility of small fingers being pinched in door. I Do not allow children to play with, on or around this appliance or any discarded appliance.
Do Not…
Warning!
Important Safety Information.
Read All Instructions Before Using.
Warning!
For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, personal injury, or death. Under certain conditions hydrogen gas may be produced in a water heater that has not been used for two weeks or more. HYDROGEN GAS IS EXPLOSIVE. If the hot water has not been used for two weeks or more, prevent the possibility of damage or injury by turning on all hot water faucets and allow them to run for several minutes. Do this before using any electrical appliance which is connected to the hot water system. This simple procedure will allow any built-up hydrogen gas to escape. Since the gas is flammable, do not smoke or use an open flame or appliance during this process.Water Heater Safety
Use this appliance only for its intended purpose as described in this Owner’s Manual.Proper Installation And Maintenance
This dishwasher must be properly installed and located in accordance with the Installation Instructions before it is used. If you did not receive an Installation Instructions sheet with your dishwasher, you can receive one by visiting our website at GEAppliances.com. I Connect to a grounded metal, permanent wiring system; or run an equipment-grounding conductor with the circuit conductors and connect to the equipment-grounding terminal or lead of the appliance. I Improper connection of the equipment- grounding conductor can result in a risk of electric shock. Check with a qualified electrician or service representative if you are in doubt whether the appliance is properly grounded. I Use supply conductors rated at least 75°C(167°F).
I Dispose of discarded appliances and shipping or packing material properly. I Do not attempt to repair or replace any part of your dishwasher unless it is specifically recommended in this manual. All other servicing should be referred to a qualified technician. I To minimize the possibility of electric shock, disconnect this appliance from the power supply before attempting any maintenance. NOTE: Turning the dishwasher off does not disconnect the appliance from the power supply. We recommend having a qualified technician service your appliance.
Consumer Support Troubleshooting Tips Operating Instructions Safety Instructions 3
Proper Disposal Of The Dishwasher
Junked or abandoned dishwashers are dangerous…even if they will sit for “just a few days.” If you are getting rid of your old dishwasher, please follow the instructions below to help prevent accidents. Before You Throw Away Your Old Dishwasher: ITake off the door of the washing compartment or remove the door latch keeper (as shown).Warning! Risk Of Child Entrapment
When Using Your Dishwasher
IUse only powder, tabs, liquid detergents or rinse agents recommended for use in a dishwasher and keep them out of the reach of children. Cascade®, Cascade Complete® and Electrasol® Automatic Dishwashing Detergents, and Jet-Dry® rinse agent have been approved for use in all GE dishwashers. ILocate sharp items so that they are not likely to damage the door seal. ILoad sharp knives with the handles up to reduce the risk of cut-type injuries. IDo not wash plastic items unless marked dishwasher-safe or the equivalent. For plastic items not so marked, check the manufacturer’s recommendations. INon-Dishware Items: Do not wash items such as electronic air cleaner filters, furnace filters and paint brushes in your dishwasher. Damage to dishwasher and discoloration or staining of dishwasher may result. IDo not touch the heating element during or immediately after use. IDo not operate your dishwasher unless all enclosure panels are properly in place. IClose supervision is necessary if this appliance is used by or near children. ILoad light, plastic items so they will not become dislodged and drop to the bottom of the dishwasher—they might come into contact with the heating element and be damaged.Read And Follow This Safety Information Carefully.
Save These Instructions
Door latch keeper GEAppliances.com
Cycle Chart Model Cycle Water Usage (gal.) Cycle Time (min.)
Edw3000,
SaniWash 8.5 56–101Gsd5500,
Pots & PansGsd5560,
Heavy 11.5 70–85Gsd5600,
Medium 9.9 65Gsd5700,
Light 8.2 61Gsd5800,
Normal WashGsd5900
Heavy 9.9 70 Medium 8.2 62 Light 6.6 56 Speed Wash/Light Wash 8.3 39 China Crystal 6.6 34 Rinse Only 1.6 5 Operating Instructions Safety Instructions Consumer Support Troubleshooting Tips 4 About the dishwasher control panel.Options
Load Selections
Status
Pots
& Pans
Speed
Wash
Rinse
Only
Speed
Dry
Delay
Start
Lock
(2 Times)
Power
Presoak
Sani
Wash
Normal
China
Crystal
Sensing
Clean SensorWashing
Rinsing
Drying
Sanitized
2 4 8Clean
Start
Reset
Model EDW3000Options
Load Selections
Status
Pots
& Pans
Light
Wash
Rinse
Only
Heated
Dry
Delay
Start
Lock
(2 Times)
Sani
Wash
Normal
China
Crystal
Sensing
Clean SensorWashing
Rinsing
Drying
Sanitized
2 4 8Clean
Start
Reset
Models GSD5500 and GSD5560Options
Load Selections
Status
Pots
& Pans
Speed
Wash
Rinse
Only
Speed
Dry
Delay
Start
Lock
(2 Times)
Sani
Wash
Normal
China
Crystal
Sensing
Clean SensorWashing
Rinsing
Drying
Sanitized
2 4 8Clean
Start
Reset
Models GSD5600 and GSD5700Options
Load Selections
Status
Pots
& Pans
Light
Wash
Rinse
Only
Heated
Dry
Delay
Start
Lock
(2 Times)
Power
Presoak
Sani
Wash
Normal
China
Crystal
Sensing
Clean SensorWashing
Rinsing
Drying
Sanitized
2 4 8Clean
Start
Reset
Model GSD5800Options
Load Selections
Status
Pots
& Pans
Speed
Wash
Rinse
Only
Speed
Dry
Delay
Start
Lock
(2 Times)
Power
Presoak
Sani
Wash
Normal
China
Crystal
Sensing
Clean SensorWashing
Rinsing
Drying
Sanitized
2 4 8Clean
Start
Reset
Model GSD5900 You can locate your model number on the tub wall just inside the door. Throughout this manual, features and appearance may vary from your model.
Consumer Support Troubleshooting Tips Operating Instructions Safety Instructions Options The light above the selected pad will be ON to indicate which OPTION has been selected. POWER For use with heavily soiled and/or dried-on, baked-on soils. This option MUST be selected PRIOR to starting the cycle. PRESOAK This option adds 16 minutes to the cycle time. SPEED DRY/ Shuts off the drying heat option. Dishes air dry naturally and energy is saved. You can prop the door open after the HEATED DRY CLEAN light illuminates.
Off
SPEED DRY/ Turns the heater on for fast drying. This cycle will extend the time to your wash cycle by 23 minutes for the NORMAL HEATED DRY cycle and 30 minutes for the SANI WASH cycle. NOTE: Cannot be selected with RINSE ONLY cycle.On
LOCK When the LOCK pad is touched twice within 3 seconds, all pads become inoperative. You can lock the controls to prevent any selections from being made. Or you can lock the controls after you have started a cycle or selected DELAY START so the cycle or DELAY START is not interrupted. Children cannot accidentally start dishwasher by touching pads with this option selected. To unlock the dishwasher after it has been locked, touch the LOCK pad twice within 3 seconds. The light above the LOCK pad will turn off. DELAY START You can delay the start of a wash cycle for up to 8 hours. Press the DELAY START pad to choose the number of hours you want to delay the start of the cycle. The machine will count down and start automatically at the correct time. Pressing the START/RESET button will cancel the DELAY START selection. NOTE: If you forget to latch the door, a reminder signal will beep until you do so. RESET To change a cycle after washing starts, touch the START/RESET pad to cancel the cycle. After water is pumped out and the motor stops, you can reprogram and restart the dishwasher. This will take approximately 90 seconds. Load Selections The light above the selected pad will be ON to indicate which LOAD SELECTION has been selected. SANI WASH This cycle raises the water temperature in the final rinse to sanitize your dishware. The cycle length will vary depending on the temperature of your inlet water. NOTE: The SaniWash cycle is monitored for sanitization requirements. If the cycle is interrupted during or after the main wash portion or if the incoming water temperature is so low that adequate water heating cannot be achieved, the sanitizing conditions will not be met. In these cases, the sanitized light will not illuminate at the end of the cycle. POTS & PANS For heavily soiled dishes or cookware with dried-on or baked-on soils. Everyday dishes may be included. This cycle will not remove burned-on foods. NORMAL For loads of everyday dishes, glasses and cookware with medium soils. NOTE: Many dishes have lighter soil than normal. Choosing a cycle other than NORMAL will save energy and water. SPEED WASH/ For dishes with light soils.Light Wash
CHINA CRYSTAL For lightly soiled china and crystal. RINSE ONLY For rinsing partial loads that will be washed later. Do not use detergent. The Status The Status display tells you what is happening while the dishwasher is in operation and also any malfunctions if they occur (see page 6). The lights will come ON indicating the sequence of operation the dishwasher is in. SENSING Displayed during periods using CleanSensor technology to measure the amount of soil in the load and decide if another prewash is needed. The SENSING light is displayed only during NORMAL and POTS & PANS cycles. WASHING Displayed during prewash and main wash periods. RINSING Displayed during rinse periods. DRYING Displayed during SPEED DRYING/HEATED DRYING. SANITIZED Displayed when cycle has met sanitization conditions. Light remains ON until door is opened. Start Close and latch the door. Touch the START/RESET pad to begin the cycle. Water fill begins, and approximately 40 seconds later the wash action begins. NOTE: The dishwasher remembers your last cycle so you don’t have to reprogram each time. When the dishwasher is loaded and the door latch is in the locked position, the control panel lights will be ON and display the last settings you selected. If you don’t want to change any of the settings, simply touch the START/RESET pad to begin the cycle. Also, if a power failure occurs, NORMAL and SPEED DRY/HEATED DRY will automatically be programmed. Make any new selections and touch the START/RESET pad to begin the cycle. Control Settings GEAppliances.com Clean This light is illuminated when a wash cycle is complete. The light will stay ON until the door is opened. 5
Flashing display lights. Operating Instructions Safety Instructions Consumer Support Troubleshooting Tips 6 Status Lights What It Means What To Do CLEANSENSOR Error If the sensing light doesn’t come on during the first part of the NORMAL or POTS & PANS cycles, the CLEANSENSOR is not working. Call for service. The dishwasher will continue to work without the CLEANSENSOR. NOTE: This light will NOT stay on the entire cycle. START/RESET pad Allow up to 90 seconds for the dishwasher to drain and reset before selecting has been pressed a new cycle. Control Error Press the START/RESET pad to turn off the beeper. Turn off power at the circuit breaker for 10 seconds, then restore power. If the rinsing light continues to flash, then call for service. Control or Sequence Press the START/RESET pad to turn off the beeper and the dishwasher will Switch Error attempt to reset. Then restart the wash cycle. If this error continues, call for service. Filling the Dispenser Fill the rinse agent dispenser until it reaches the bottom of lip inside the opening. Replace cap. To check if rinse agent is needed, press the clear center of the fill cap 2 or 3 times. If rinse agent fills the center of the cap, you have enough. A full dispenser should last about one month. If rinse agent spills, wipe up the excess. Check the Water Temperature The entering water must be at least 120°F and not more than 150°F for effective cleaning and to prevent dish damage. Check the water temperature with a candy or meat thermometer. Turn on the hot water faucet nearest the dishwasher, place the thermometer in a glass and let the water run continuously into the glass until the temperature stops rising. Use Jet-Dry ® Rinse Agent Jet-Dry® rinse agent removes spots and prevents new film buildup on your dishes, glasses, flatware, cookware and plastic. Using the dishwasher.
Status
Sensing
Washing
Rinsing
Drying
Sanitized
Status
Sensing
Washing
Rinsing
Drying
Sanitized
Status
Sensing
Washing
Rinsing
Drying
Sanitized
Plus A
Beeping
Sound
Status
Sensing
Washing
Rinsing
Drying
Sanitized
Plus A
Beeping
Sound
Forget to Add a Dish? A forgotten dish can be added any time before the main wash. Push the door latch to the left. Once the water calms, open the door. Steam may rise out of the dishwasher. Add forgotten dishes. Close the door and push the latch to the far right. 4 3 2 1 Proper Use of Detergent Use only detergent specifically made for use in dishwashers. Cascade®, Cascade® Complete and Electrasol® Automatic Dishwashing Detergents have been approved for use in all GE dishwashers. Keep your detergent fresh and dry. Don’t put powder detergent into the dispenser until you’re ready to wash dishes. The amount of detergent to use depends on whether your water is hard or soft. With hard water, you need extra detergent. With soft water, you need less detergent. Protect your dishes and dishwasher by contacting your water department and asking how hard your water is. Twelve or more grains is extremely hard water. A water softener is recommended. Without it, lime can build up in the water valve, which could stick while open and cause flooding. Too much detergent with soft water can cause a permanent cloudiness of glassware, called etching. You’ll find two detergent dispensers on the inside door of your dishwasher. All wash cycles–except RINSE ONLY–require detergent in the main cup. Wash cycles with two washes will also use the open cup. When using automatic dishwashing detergent tabs, simply place one tab in the main cup and close. NOTE: To open detergent cup after it has been closed, unlatch the door. Press the START/RESET pad three times within two seconds and the detergent cup will release. A snapping sound may be heard. Open cup Main cup 7 Consumer Support Troubleshooting Tips Operating Instructions Safety Instructions GEAppliances.com Using the Dishwasher Door The door must be closed and locked into place to select a LOAD SELECTION or an OPTION. If the door is opened during a cycle and left open, the dishwasher will beep once every minute until the door is closed and latched into place. 2 1
Loading the dishwasher racks. Operating Instructions Safety Instructions Consumer Support Troubleshooting Tips 8 For best dishwashing results, follow these loading guidelines. Features and appearance of racks and silverware baskets may vary from your model. Upper Rack Although the upper rack is for glasses, cups and saucers, pots and pans can be placed in this rack for effective cleaning. Cups and glasses fit best along the sides. This is also a secure place for dishwasher-safe plastics. The cup shelf (on some models) may be placed in the up or down position to add flexibility. The upper rack is good for all kinds of odd-shaped utensils. Saucepans, mixing bowls and other items should be placed face down. Secure larger dishwasher-safe plastics over two fingers when possible. Make sure small plastic items are secure so they can’t fall onto the heater. Be sure that items do not protrude through the bottom of the rack and block rotation of the middle spray arm. This could result in poor wash performance for items in the upper rack. Check to make sure that tall items will not block rotation of the top wash arm. The Wash Tower Keep the center area clear in the lower rack. The wash tower rises through the center of the lower rack during the wash and rinse portions of the cycle. The wash tower shoots water into the mid-level wash arm located under the upper rack. Blocking the wash tower could result in poor wash performance for items in the upper rack. Don’t block or load tall things next to the Wash Tower. Lower Rack When loading the lower rack, do not load large platters or trays in the front right corner. They may prevent detergent from circulating during the wash cycle. The lower rack is best used for plates, saucers and cookware. Large items such as broiler pans and racks should go along the right-hand side. Load platters, pots and bowls along the sides, in corners, or in the back. The soiled side of items should face the center of the rack. If necessary, oversized glasses and mugs can be placed in the lower rack to maximize loading flexibility. Also, be careful not to let a portion of an item such as a pot or dish handle extend through the bottom rack. This could block the wash arm and result in poor wash performance. Fold-down fingers (on some models) provide flexibility for extra-large and hard-to-fit items. The fingers may be left in the up position or folded down to customize the lower rack.
9 Consumer Support Troubleshooting Tips Operating Instructions Safety Instructions Silverware Basket Put flatware in the removable basket with knife handles up to protect your hands. Place spoons in the basket with handles down. Mix knives, forks and spoons so they don’t nest together. Distribute evenly. Small plastic items, such as measuring spoons and lids from small containers, should go in the bottom of the silverware basket with silverware on top. Lids can be assembled to either end of the silverware basket to contain small items. To assemble an end lid, place the outer lid stud into the hole on the outside of the silverware basket. Then place the inside lid stud into the inner hole in the silverware basket. Repeat for other side if desired. Long items can be placed on the cupshelf in the upper rack. The silverware basket can be placed in the front, side or back of the lower rack. The accessory basket (on some models) can hold small items such as: baby bottle nipples, plastic lids, corn cob holders, etc. It can hang from the top hoop of the upper rack along the right side or it can also hang on the right or left side of the lower rack. When hanging the accessory basket on the right side in the upper rack, make sure the top is closed and nothing is sticking out. Don’t let any item extend through bottom. GEAppliances.com
Operating Instructions Safety Instructions Consumer Support Troubleshooting Tips 10 Follow these guidelines for loading 10 place settings. Features and appearance of racks and silverware baskets may vary from your model. Upper Rack—10 place settings Lower Rack—10 place settings Follow these guidelines for loading 12 place settings. Features and appearance of racks and silverware baskets may vary from your model. Upper Rack—12 place settings Lower Rack—12 place settings Loading place settings.
11 Caring for the dishwasher. GEAppliances.com To clean the control panel use a lightly dampened cloth then dry thoroughly. To clean the exterior use a good appliance polish. Never use sharp object, scouring pads or harsh cleaners on any part of the dishwasher. If your dishwasher is left in an unheated place during the winter, ask a service technician to: Cut off electrical power to the dishwasher. Remove fuses or trip circuit breaker. Turn off the water supply and disconnect the water inlet line from the water valve. Drain water from the inlet line and water valve. (Use a pan to catch the water.) Reconnect the water inlet line to the water valve. Remove the plastic sump cover in the tub bottom and use a sponge to soak up water in the rubber boot. 5 4 3 2 1 Sump cover screws An air gap protects your dishwasher against water backing up into it if a drain clogs. The air gap is not a part of the dishwasher. It is not covered by your warranty. Not all plumbing codes require air gaps, so you may not have one. The air gap is easy to clean. Turn off the dishwasher and lift off the chrome cover. Unscrew the plastic cap and clean with a toothpick. 2 1 Check the air gap any time your dishwasher isn’t draining well. Two types of air gaps Does Your Dishwasher Have an Air Gap? Protect Against Freezing Consumer Support Troubleshooting Tips Operating Instructions Safety Instructions The stainless steel panels can be cleaned with Stainless Steel Magic or a similar product using a clean, soft cloth. You can order Stainless Steel Magic #WX10X15 through GE Parts by calling 800.626.2002. The Stainless Steel Panels
12 About optional accessories. You can change the door and lower access panel appearance of your dishwasher by ordering one of these optional accessories: I 1/4” Wood Panel Trim Kit I 3/4” Trimless Wood Panel Kit These accessories are available at extra cost (VISA, MasterCard or Discover cards accepted) by calling 800.626.2002. Specify accessory number when ordering. Descriptions of Optional Accessories Wood panel trim kit–This accessory contains trim and instructions for you to supply and install a 1⁄4″ thick decorative wood door and lower access panel: I GPF425A (Almond) I GPF425C (Bisque) I GPF425B (Black) I GPF425W (White) NOTE: The GPF100 dishwasher door spring kit must also be ordered and installed when the door panel weighs four lbs. or more. Trimless wood panel kit–This accessory contains parts and instructions for you to supply and install a 3 ⁄4″ thick decorative wood door and lower access panel:
I Gpf475
NOTE: The GPF100 dishwasher door spring kit will be included with the trimless wood panel kit and must be installed with it. I Prevents movement of baby bottles during the dishwasher cycle I Snaps easily onto any dishwasher upper rack I Eliminates hand washing I Fits all baby bottles You can order a package of 5 Baby Bottle Holders, at extra cost, by calling 800.626.2002, or through the Internet at GEAppliances.com (Visa, MasterCard or Discover cards accepted). For best results, the Baby Bottle Holder should be installed on the upper rack of the dishwasher. About rack accessories. Baby Bottle Holder Part Number: WX69X200 Operating Instructions Safety Instructions Consumer Support Troubleshooting Tips
Problem Possible Causes What To Do Control panel lights go Time too long between
Problem Possible Causes What To Do Dishes and flatware Inlet water temperature • Raise the water heater temperature to 120°F. not clean is below 120°F
Warning
Before cleaning interior, wait at least 20 minutes after a cycle for the heating element to cool down. Failure to do so can result in burns. An overall yellow or
15 Consumer Support Troubleshooting Tips Operating Instructions Safety Instructions What Is Not Covered: For The Period Of: GE Will Replace: One Year Any part of the dishwasher which fails due to a defect in materials or workmanship. During From the date of the this full one-year warranty, GE will also provide, free of charge, all labor and in-home service original purchase to replace the defective part. Second Year Any part of the Water Distribution System which fails due to a defect in materials or From the date of the workmanship. Associated inlet and drain plumbing parts are not covered by this warranty. original purchase During this second-year limited warranty, you will be responsible for any labor or in-home service costs. Five Years The electronic control module, if it should fail due to a defect in materials or workmanship. From the date of the During this five-year limited warranty, you will be responsible for any labor or in-home original purchase service costs. Ten Years The PermaTuf ®tub or door liner, if it fails to contain water due to a defect in materials or From the date of the workmanship. During this full warranty, GE will also provide, free of charge, all labor and original purchase in-home service to replace the defective part. GE Dishwasher Warranty. IService trips to your home to teach you how to use the product. IImproper installation. IFailure of the product if it is abused, misused, or used for other than the intended purpose or used commercially. IReplacement of house fuses or resetting of circuit breakers. IDamage to the product caused by accident, fire, floods or acts of God. IIncidental or consequential damage caused by possible defects with this appliance. ICleaning or servicing of the air gap device in the drain line. This warranty is extended to the original purchaser and any succeeding owner for products purchased for home use within the USA. In Alaska, the warranty excludes the cost of shipping or service calls to your home. Some states do not allow the exclusion or limitation of incidental or consequential damages. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. To know what your legal rights are, consult your local or state consumer affairs office or your state’s Attorney General. Warrantor: General Electric Company. Louisville, KY 40225 All warranty service provided by our Factory Service Centers, or an authorized Customer Care® technician. To schedule service, on-line, 24 hours a day, visit us at GEAppliances.com, or call
800.Ge.Cares (800.432.2737).
Staple your receipt here. Proof of the original purchase date is needed to obtain service under the warranty.
Printed in the United States Consumer Support. GE Appliances Website GEAppliances.com Have a question or need assistance with your appliance? Try the GE Appliances Website 24 hours a day, any day of the year! For greater convenience and faster service, you can now download Owner’s Manuals, order parts, catalogs, or even schedule service on-line. You can also “Ask Our Team of Experts™” your questions, and so much more... Schedule Service GEAppliances.com Expert GE repair service is only one step away from your door. Get on-line and schedule your service at your convenience 24 hours any day of the year! Or call 800.GE.CARES (800.432.2737) during normal business hours. Real Life Design Studio GEAppliances.com GE supports the Universal Design concept–products, services and environments that can be used by people of all ages, sizes and capabilities. We recognize the need to design for a wide range of physical and mental abilities and impairments. For details of GE’s Universal Design applications, including kitchen design ideas for people with disabilities, check out our Website today. For the hearing impaired, please call
