Common questions
Common Questions
29 totalWhat should I do if the RINSING light keeps flashing and the dishwasher is beeping?
This indicates a Control Error. Press the START/RESET pad to turn off the beeper, then turn off power at the circuit breaker for 10 seconds and restore power. If the rinsing light continues to flash after restoring power, call for service. (Page 11)
What is the correct water temperature for the dishwasher to clean effectively?
The entering water must be at least 120°F and not more than 150°F for effective cleaning and to prevent dish damage. You can check the water temperature using a candy or meat thermometer by running hot water from the nearest faucet into a glass until the temperature stops rising. (Page 12)
Why are there spots and film on my glasses and flatware, and how do I fix it?
Spots and film are commonly caused by hard water, low inlet water temperature, or an empty rinse agent dispenser. Use Jet-Dry rinse agent to remove spots and prevent new film buildup. For stubborn existing film, run the longest cycle without detergent, and after 18–22 minutes pour 2 cups of white vinegar into the bottom of the dishwasher and allow the cycle to complete. (Page 21)
How do I remove suds from the dishwasher tub if the wrong detergent was used?
Open the dishwasher and let the suds dissipate, then add 1 gallon of cold water to the tub. Close and latch the door, then pump out the water by pressing START/RESET and immediately pressing START/RESET again. Repeat this process if necessary, and always use only automatic dishwasher detergents to avoid sudsing. (Page 20)
How do I delay the start of a wash cycle?
Press the DELAY START pad to choose the number of hours you want to delay the start, up to a maximum of 8 hours. The machine will count down and start automatically at the correct time. Pressing the START/RESET button will cancel the DELAY START selection. (Page 10)
Why didn't the SANITIZED light come on at the end of the SaniWash cycle?
The SANITIZED light will not illuminate if the cycle was interrupted during or after the main wash portion, or if the incoming water temperature was too low to achieve adequate heating. To prevent this, do not open the door anytime during or after the main wash, and ensure your water heater is set to at least 120°F. (Page 23)
Show 23 more questions
What is the warranty coverage for the GSD5610 dishwasher?
How do I clean the air gap if the dishwasher is not draining well?
How should I load sharp knives and flatware in the dishwasher safely?
What should I do if the control panel lights are flashing and the dishwasher is beeping?
What is the correct water temperature for the dishwasher to work effectively?
How do I unlock the control panel if it has been locked?
How do I use the Delay Start feature to postpone a wash cycle?
Why is there water standing in the bottom of the dishwasher tub?
How do I remove spots and film from glasses and flatware?
What detergent is recommended for the GE GSD5610 dishwasher?
How do I protect the dishwasher from freezing if it is left in an unheated space?
What does the warranty cover and for how long on the GSD5610 dishwasher?
How do I safely add a forgotten dish after the wash cycle has already started?
What water temperature should I use with my GSD5610 dishwasher?
How do I use the Jet-Dry rinse agent in my dishwasher?
What should I do if a dish is forgotten before the main wash starts?
How much detergent should I use in my GSD5610?
What does the CLEANSENSOR error mean and what should I do?
How do I unlock the control panel if I've locked it with the LOCK option?
What is the POWER PRESOAK option and how much time does it add?
How do I clean the air gap in my dishwasher's drain system?
What should I do if the SANITIZED light doesn't illuminate at the end of a SaniWash cycle?
How do I properly load the silverware basket in my GSD5610?
Full Manual
32 pages
GE Appliances Dishwashers
165D4700P218
49-5892-1 05-01 Jr
www.geappliances.comGsd5610
Gsd5620
Gsd5630
Gsd5640
Gsd5650
Gsd5720
Gsd5730
Gsd5750
Gsd5910
Gsd5920
Gsd5930
Gsd5940
Gsd5950
Gsdl322
Gsdl332
Gsdl352
Owner’s Manual Triton™Profile™
Congratulations! You Are Now Part of the GE Family. Welcome to the GE family. We’re proud of our quality products and we are committed to providing dependable service. You’ll see it in this easy-to-use Owner’s Manual and you’ll hear it in the friendly voices of our customer service department. Best of all, you’ll experience these values each time you use your dishwasher. That’s important, because your new dishwasher will be part of your family for many years. And we hope you will be part of ours for a long time to come. We thank you for buying GE. We appreciate your purchase, and hope you will continue to rely on us whenever you need quality appliances for your home. 2 Important! Fill out and return the Consumer Product Registration Card. There are two easy ways to register your appliance. I Through the Internet at www.geappliances.com. I Complete and mail the enclosed card. Write the model and serial numbers here. # # You can find them on the tub wall just inside the door. Staple sales slip or cancelled check here. Proof of the original purchase date is needed to obtain service under the warranty.
Review the Section on Troubleshooting Tips Customer Service Troubleshooting Tips Operating Instructions Safety Information GE & You, A Service Partnership. Inside you will find many helpful hints on how to use and maintain your dishwasher properly. Just a little preventive care on your part can save you a great deal of time and money over the life of your dishwasher. Read this Manual Ask any GE appliance owner and they will tell you we stand behind our products with unmatched quality service. However, did you know that most questions result from simple problems that you can easily fix yourself in just a few minutes? This Owner’s Manual can tell you how. You’ll find many answers to common problems here. If you review our chart of Troubleshooting Tips first, you may not need to call for service at all. If you do need service, you can relax knowing help is only a phone call away. A list of toll-free customer service numbers is included in the back section. Or you can always call the GE Answer Center® at 800.626.2000, 24 hours a day, 7 days a week. If You Need Service Safety Information . . . . . .4–7 Operating Instructions Control Panel and Settings . . . . . . . . . . . . . . .8–11 Using the Dishwasher . . .12–13 Loading the Racks . . . . . .14–16 Optional Accessories . . . . . . .17 Care and Cleaning . . . . . . . . .18 Troubleshooting Tips Before You Call For Service . . . . . . . . 19–23 Customer Service Product Registration . . . . .29–30 Warranty . . . . . . . . . . . . . . . .31 Service Telephone Numbers . . . . . . . . . .Back Cover 3
Safety Information Operating Instructions Troubleshooting Tips Customer Service
Important Safety Information.
Read All Instructions Before Using.
4Warning!
For your safety, the information in this manual must be followed to minimize the risk of fire, explosion, electric shock, or to prevent property damage, personal injury, or loss of life. Under certain conditions hydrogen gas may be produced in a water heater that has not been used for two weeks or more. HYDROGEN GAS IS EXPLOSIVE. If the hot water has not been used for two weeks or more, prevent the possibility of damage or injury by turning on all hot water faucets and allow them to run for several minutes. Do this before using any electrical appliance which is connected to the hot water system. This simple procedure will allow any built-up hydrogen gas to escape. Since the gas is flammable, do not smoke or use an open flame or appliance during this process.Water Heater Safety
5 Customer Service Troubleshooting Tips Operating Instructions Safety Information Use this appliance only for its intended purpose as described in this Owner’s Manual. This dishwasher must be properly installed and located in accordance with the Installation Instructions before it is used. If you did not receive an Installation Instructions sheet with your dishwasher, you can receive one by calling us toll-free at the GE Answer Center®, 800.626.2000. I Connect to a grounded metal, permanent wiring system; or run an equipment- grounding conductor with the circuit conductors and connect to the equipment- grounding terminal or lead of the appliance. I Improper connection of the equipment-grounding conductor can result in a risk of electric shock. Check with a qualified electrician or service representative if you are in doubt whether the appliance is properly grounded. I Dispose of discarded appliances and shipping or packing material properly. I Do not attempt to repair or replace any part of your dishwasher unless it is specifically recommended in this manual. All other servicing should be referred to a qualified technician. I To minimize the possibility of electric shock, disconnect this appliance from the power supply before attempting any maintenance. NOTE: Turning the dishwasher off does not disconnect the appliance from the power supply. We recommend having a qualified technician service your appliance.
Proper Installation
And Maintenance
Safety Information Operating Instructions Troubleshooting Tips Customer Service
Important Safety Information.
Read All Instructions Before Using.
6Do Not…
I Do not tamper with controls. I Do not abuse, sit on, or stand on the door or dish rack of the dishwasher. I Do not discard a dishwasher without first removing the door of the washing compartment. I Do not store or use combustible materials, gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. I Do not allow children to play inside, on or with this appliance or any discarded appliance.Warning!
7 Customer Service Troubleshooting Tips Operating Instructions Safety Information
When Using Your Dishwasher
CAUTION: Contents washed in SaniWash cycle may be hot to the touch. Use care before unloading. I Use only powder, tabs, liquid detergents or rinse agents recommended for use in a dishwasher and keep them out of the reach of children. Cascade® Automatic Dishwashing Detergent has been approved for use in all GE dishwashers. I Locate sharp items so that they are not likely to damage the door seal. I Load sharp knives with the handles up to reduce the risk of cut-type injuries. I Do not wash plastic items unless marked dishwasher safe or the equivalent. For plastic items not so marked, check the manufacturer’s recommendations. I Non-Dishware Items: Do not wash items such as electronic air cleaner filters, furnace filters and paint brushes in your dishwasher. Damage to dishwasher and discoloration or staining of dishwasher may result. I Do not touch the heating element during or immediately after use. I Do not operate your dishwasher unless all enclosure panels are properly in place. I Close supervision is necessary if this appliance is used by or near children. I Load light, plastic items so they will not become dislodged and drop to the bottom of the dishwasher— they might come into contact with the heating element and be damaged. Read and follow this Safety Information carefully.Save These Instructions
Safety Information Operating Instructions Troubleshooting Tips Customer Service About the dishwasher control panel. You can locate your model number on the tub wall just inside the door. Throughout this manual, features and appearance may vary from your model. 8
Options
Load Selections
Status
Pots
& Pans
Speed
Wash
Rinse
Only
Speed
Dry
Delay
Start
Lock
(2 Times)
Power
Presoak
Sani
Wash
Normal
China
Crystal
Sensing
Clean SensorWashing
Rinsing
Drying
Sanitized
2 4 8 1 2 3 4 5Clean
Start
Reset
1 Control Settings The Status The Status display tells you what’s happening while the dishwasher is in operation and also any malfunctions if they occur (see page 10). The lights will come ON indicating the sequence of operation the dishwasher is in. SENSING Displayed during periods using CleanSensor technology to measure the amount of soil in the load and decide if another prewash is needed. The SENSING light is displayed only during NORMAL and POTS & PANS cycles. WASHING Displayed during prewash and main wash periods. RINSING Displayed during rinse periods. DRYING Displayed during SPEED DRYING. SANITIZED Displayed when cycle has met sanitization conditions. Light remains ON until door is opened.
Customer Service Troubleshooting Tips Operating Instructions Safety Information 9 Load Selections The light above the selected pad will be ON to indicate which LOAD SELECTION has been selected.
Sani Wash
8.5 gal., 56–101 min. Prewash Prewash Main wash Prerinse Final rinse This cycle raises the water temperature in the final rinse to sanitize your dishware. The cycle length will vary depending on the temperature of your inlet water. NOTE: The SaniWash cycle is monitored for sanitization requirements. If the cycle is interrupted during or after the main wash portion or if the incoming water temperature is so low that adequate water heating cannot be achieved, the sanitizing conditions will not be met. In these cases, the sanitized light will not illuminate at the end of the cycle.Pots & Pans
Heavy 11.5 gal., 70–85 min. Prewash Prewash Prewash Prewash Main wash Prerinse Final rinse Medium 9.9 gal., 65 min. Prewash Prewash Prewash Main wash Prerinse Final rinse Light 8.2 gal., 61 min. Prewash Prewash Main wash Prerinse Final rinse For heavily soiled dishes or cookware with dried-on or baked-on soils. Everyday dishes may be included. This cycle will not remove burned-on foods.Normal
Heavy 11.5 gal., 64 min. Prewash Prewash Prewash Main wash Prerinse Prerinse Final rinse Medium 9.9 gal., 59 min. Prewash Prewash Prewash Main wash Prerinse Prerinse Final rinse Light 8.2 gal., 55 min. Prewash Main wash Prerinse Prerinse Final rinse For loads of everyday dishes and glassware with medium soils. CHINA CRYSTAL 6.6 gal., 34 min. Prewash Main wash Prerinse Final rinse For lightly soiled china and crystal.Speed Wash
8.3 gal., 39 min. Prewash Prewash Main wash Prerinse Final rinse For lightly soiled dishes and glassware.Rinse Only
1.6 gal., 5 min. Rinse For rinsing partial loads that will be washed later. Do not use detergent with this cycle. 2
Safety Information Operating Instructions Troubleshooting Tips Customer Service 10 About the dishwasher control panel. Options The light above the selected pad will be ON to indicate which OPTION has been selected. POWER For use with heavily soiled and/or dried-on, baked-on soils. This option MUST be PRESOAK selected PRIOR to starting the cycle. This option adds 16 minutes to the cycle time. SPEED DRY Shuts off the drying heat option. Dishes air dry naturally and energy is saved.
Off
You can prop the door open after the CLEAN light illuminates. SPEED DRY Turns the heater on for fast drying. This cycle will extend the time to your washOn
cycle by 23 minutes for the NORMAL cycle and 30 minutes for the SANI WASH cycle. NOTE: Cannot be selected with RINSE ONLY cycle. LOCK When the LOCK pad is touched twice within 3 seconds, all pads become inoperative. You can lock the controls to prevent any selections from being made. Or you can lock the controls after you have started a cycle or selected DELAY START so the cycle or DELAY START is not interrupted. Children cannot accidentally start dishwasher by touching pads with this option selected. To unlock the dishwasher after it has been locked, touch the LOCK pad twice within 3 seconds. The light above the LOCK pad will turn off. DELAY START You can delay the start of a wash cycle for up to 8 hours. Press the DELAY START pad to choose the number of hours you want to delay the start of the cycle. The machine will count down and start automatically at the correct time. Pressing the START/RESET button will cancel the DELAY START selection. NOTE: If you forget to latch the door a reminder signal will beep until you do so. RESET To change a cycle after washing starts, touch the START/RESET pad to cancel the cycle. After water is pumped out and the motor stops, you can reprogram and restart the dishwasher. This will take approximately 90 seconds. Start Close and latch the door. Touch the START/RESET pad to begin the cycle. Water fill begins, and approximately 40 seconds later the wash action begins. NOTE: The dishwasher remembers your last cycle so you don’t have to reprogram each time. When the dishwasher is loaded and the door latch is in the locked position, the control panel lights will be ON and display the last settings you selected. If you don’t want to change any of the settings, simply touch the START/RESET pad to begin the cycle. Also, if a power failure occurs, NORMAL and SPEED DRY will automatically be programmed. Make any new selections and touch the START/RESET pad to begin the cycle. 3 4 Clean This light is illuminated when a wash cycle is complete. The light will stay ON until the door is opened. 5
Customer Service Troubleshooting Tips Operating Instructions Safety Information 11 Status Lights What It Means What To Do CLEANSENSOR Error If the sensing light doesn’t come on during the first part of the NORMAL or POTS & PANS cycles, the CLEANSENSOR is not working. Call for service. The dishwasher will continue to work without the
Cleansensor.
NOTE: This light will NOT stay on the entire cycle. START/RESET pad has Allow up to 90 seconds for the been pressed dishwasher to drain and reset before selecting a new cycle. Control Error Press the START/RESET pad to turn off the beeper. Turn off power at the circuit breaker for 10 seconds, then restore power. If the rinsing light continues to flash, then call for service. Control or Sequence Press the START/RESET pad to turn Switch Error off the beeper and the dishwasher will attempt to reset. Then restart the wash cycle. If this error continues call for service. Flashing display lights.Status
Sensing
Washing
Rinsing
Drying
Sanitized
Plus A
Beeping
Sound
Status
Sensing
Washing
Rinsing
Drying
Sanitized
Status
Sensing
Washing
Rinsing
Drying
Sanitized
Status
Sensing
Washing
Rinsing
Drying
Sanitized
Plus A
Beeping
Sound
Safety Information Operating Instructions Troubleshooting Tips Customer Service Using the dishwasher. 12 Check the Water Temperature Use Jet-Dry ® Rinse Agent Jet-Dry® rinse agent removes spots and prevents new film build-up on your dishes, glasses, flatware, cookware and plastic. Fill the rinse agent dispenser until it reaches the bottom of lip inside the opening. Do not overfill the dispenser. Replace cap. To check if rinse agent is needed, press the clear center of the fill cap 2 or 3 times. If rinse agent fills the center of the fill cap, you have enough. A full dispenser should last about one month. If rinse agent is spilled, wipe up the excess. Using the Dishwasher Door The door must be closed and locked into place to select a LOAD SELECTION or an OPTION. If the door is opened during a cycle and left open, the dishwasher will beep once every minute until the door is closed and latched into place. 2 1 Dish Preparation Prior to Loading I No pre-rinsing of normal food soil is required. I Scrape off hard soils, including bones, toothpicks, skins, and seeds. I Remove large quantities of any remaining food. I Remove leafy vegetables, meat trimmings, and excessive amounts of grease or oil. I Remove acidic food soils that can discolor stainless steel. The entering water must be at least 120°F. and not more than 150°F., for effective cleaning and to prevent dish damage. Check the water temperature with a candy or meat thermometer. Turn on the hot water faucet nearest the dishwasher, place the thermometer in a glass and let the water run continuously into the glass until the temperature stops rising.
Customer Service Troubleshooting Tips Operating Instructions Safety Information 13 Forget to Add a Dish? A forgotten dish can be added any time before the main wash. Push the door latch to the left. Do not open the door until the water spray action stops. Steam may rise out of the dishwasher. Add forgotten dishes. Close the door and push the latch to the far right. 4 3 2 1 Proper Use of Detergent Use only detergent specifically made for use in dishwashers. Cascade® Automatic Dishwashing Detergent has been approved for use in all GE dishwashers. Keep your detergent fresh and dry. Don’t put detergent into the dispenser until you’re ready to wash dishes. You’ll find two detergent dispensers on the inside door of your dishwasher. All wash cycles except RINSE ONLY require detergent in the main cup. Wash cycles with a pre-wash and a main wash will also use the open cup. The amount of detergent to use depends on whether your water is hard or soft. With hard water, fill the main cup and open cup completely. With soft water, fill both cups halfway. When using automatic dishwashing detergent tabs, simply place one tab in the main cup and close. Protect your dishes and dishwasher by contacting your water department and asking how hard your water is. Twelve or more grains is extremely hard water. A water softener is recommended. Without it, lime can build up in the water valve, which could stick while open and cause flooding. Too much detergent with soft water can cause a permanent cloudiness of glassware, called etching. NOTE: To open detergent cup after it has been closed, unlatch the door. Press the START/RESET pad three times within two seconds and the detergent cup will release. You may also turn the detergent cup handle counter-clockwise until it releases. A snapping sound may be heard. Open cup Main cup
Safety Information Operating Instructions Troubleshooting Tips Customer Service Loading the dishwasher racks. For best dishwashing results, follow these loading guidelines. Features and appearance of racks and silverware baskets may vary from your model. Upper Rack Although the upper rack is for glasses, cups and saucers, pots and pans can be placed in this rack for effective cleaning. Cups and glasses fit best along the sides. This is also a secure place for dishwasher-safe plastics. The cup shelf (on some models) may be placed in the up or down position to add flexibility. A wine glass holder (on some models) secures wine glasses at an angle for best washability. Because wine glasses come in various sizes, after loading, slowly push in the rack to make sure they will clear the top of the dishwasher. The upper rack is good for all kinds of odd- shaped utensils. Saucepans, mixing bowls and other items should be placed face down. Fold- down fingers (on some models) provide flexibility for extra-large and hard-to-fit items. Secure larger dishwasher-safe plastics over two fingers when possible. Make sure small plastic items are secure so they can’t fall onto the heater. Be sure that items do not protrude through the bottom of the rack and block rotation of the middle spray arm. This could result in poor wash performance for items in the upper rack. Check to make sure that tall items will not block rotation of the top wash arm. The Wash Tower Keep the center area clear in the lower rack. The wash tower rises through the center of the lower rack during the wash and rinse portions of the cycle. The wash tower shoots water into the mid-level wash arm located under the upper rack. Blocking the wash tower could result in poor wash performance for items in the upper rack. Don’t block or load tall things next to the Wash Tower. 14
Customer Service Troubleshooting Tips Operating Instructions Safety Information 15 Lower Rack When loading the lower rack, do not load large platters or trays in the front right corner. They may prevent detergent from circulating during the wash cycle. The lower rack is best used for plates, saucers, and cookware. Large items such as broiler pans and racks should go along the right-hand side. Load platters, pots and bowls along the sides, in corners, or in the back. The soiled side of items should face the center of the rack. If necessary, oversized glasses and mugs can be placed in the lower rack to maximize loading flexibility. Also, be careful not to let a portion of an item such as a pot or dish handle extend through the bottom rack. This could block the wash arm and cause poor washing results. Fold-down fingers (on some models) provide flexibility for extra-large and hard-to-fit items. The fingers may be left in the up position or folded down to customize the lower rack. Silverware Basket A variety of options is available regarding the three-piece silverware basket in your dishwasher. The complete basket is designed to fit on the right side or back of the lower rack. Additionally, each end of the basket is removable to better accommodate flatware and lower rack capacity needs. To load flatware, simply push the adjustable handle to either side. Put flatware in the basket with knife handles up to protect your hands. Place spoons in the basket with handles down. Mix knives, forks and spoons so they don’t nest together. Distribute evenly. Small plastic items, such as measuring spoons and lids for small containers, should go in the bottom of the silverware basket with silverware on top. The lids of both end baskets can be closed to contain small items. Long items can be placed on the cupshelf in the upper rack. Don’t let any item extend through bottom. To remove end baskets, grasp the basket at opposite corners and slide apart. The basket sections should be placed in the lower rack by hanging them on the top hoop.
Loading place settings… 16 Follow these guidelines for loading 10 place settings. Features and appearance of racks and silverware baskets may vary from your model. Upper Rack—10 place settings Lower Rack—10 place settings Safety Information Operating Instructions Troubleshooting Tips Customer Service Follow these guidelines for loading 12 place settings. Features and appearance of racks and silverware baskets may vary from your model. Upper Rack—12 place settings Lower Rack—12 place settings
17 Customer Service Troubleshooting Tips Operating Instructions Safety Information You can change the door and lower access panel appearance of your dishwasher by ordering one of these optional accessories: I Color Panels I 1/4” Wood Panel Trim Kit I 3/4” Trimless Panel Kit These accessories are available at extra cost (VISA, MasterCard, or Discover cards accepted) by calling 800-626-2002. Specify accessory number when ordering. Descriptions of Optional Accessories Color panels— Replacement door panels and lower access panels are available in the following colors: I GPF400A (Almond) I GPF400B (Black) I GPF400W (White) I GPF400S (Stainless Steel) I GPF400C (Bisque) NOTE: The GPF100 dishwasher door spring kit is included with the stainless steel color panel kit and must be installed with it
(Gpf400S).
Wood panel trim kit— This accessory contains trim and instructions for you to supply and install a 1⁄4″ thick decorative wood door and lower access panel: I GPF425A (Almond) I GPF425B (Black) I GPF425W (White) I GPF425C (Bisque) NOTE: The GPF100 dishwasher door spring kit must also be ordered and installed when the door panel weighs four lbs. or more. Trimless panel kit— This accessory contains parts and instructions for you to supply and install a 3⁄4″ thick decorative wood door and lower access panel:I Gpf475
NOTE: The GPF100 dishwasher door spring kit is included with the trimless panel kit and must be installed with it. About optional accessories.
Check the air gap any time your dishwasher isn’t draining well. The Stainless Steel Panels The stainless steel panels can be cleaned with Stainless Steel Magic or a similar product using a clean, soft cloth. You can order Stainless Steel Magic # WX10X15 through GE Parts by calling 800-626-2002. Does Your Dishwasher Have an Air Gap? An air gap protects your dishwasher against water backing up into it if a drain clogs. The air gap is not a part of the dishwasher. It is not covered by your warranty. Not all plumbing codes require air gaps, so you may not have one. The air gap is easy to clean. Turn off the dishwasher and lift off the chrome cover. Remove the plastic cap and clean with a toothpick. 2 1 Two types of air gaps 18 Caring for the dishwasher. To clean the control panel use a lightly dampened cloth then dry thoroughly. To clean the exterior use a good appliance polish wax. Never use sharp objects, scouring pads or harsh cleaners on any part of the dishwasher. Protect Against Freezing If your dishwasher is left in an unheated place during the winter, ask a service technician to: Cut off electrical power to the dishwasher. Remove fuses or trip circuit breaker. Turn off the water supply and disconnect the water inlet line from the water valve. Drain water from the water inlet line and water valve. (Use a pan to catch the water.) Reconnect the water inlet line to the water valve. 4 3 2 1 Safety Information Operating Instructions Troubleshooting Tips Customer Service
19 Customer Service Troubleshooting Tips Operating Instructions Safety Information Problem Possible Causes What To Do Control panel lights go Time too long between
Safety Information Operating Instructions Troubleshooting Tips Customer Service 20 Before you call for service… Problem Possible Causes What To Do Water standing in This is normal
Customer Service Troubleshooting Tips Operating Instructions Safety Information 21 Problem Possible Causes What To Do Dishes and flatware Low inlet water
Problem Possible Causes What To Do Cloudiness on Combination of soft
Warning
Before cleaning interior wait at least 20 minutes after a cycle for the heating element to cool down. Failure to do so can result in burns. An overall yellow or
23 Customer Service Troubleshooting Tips Operating Instructions Safety Information Problem Possible Causes What To Do Dishes don’t dry Low inlet water
24 Safety Information Operating Instructions Troubleshooting Tips Customer Service Notes.
25 Customer Service Troubleshooting Tips Operating Instructions Safety Information
Notes. 26 Safety Information Operating Instructions Troubleshooting Tips Customer Service
27 Customer Service Troubleshooting Tips Operating Instructions Safety Information
Notes. 28 Safety Information Operating Instructions Troubleshooting Tips Customer Service
GE Service Protection Plus™ GE, a name recognized worldwide for quality and dependability, offers you Service Protection Plus™—comprehensive protection on all your appliances—No Matter What Brand! Benefits Include:
Day Year Street Address Consumer Product Ownership Registration Dear Customer: Thank you for purchasing our product and thank you for placing your confidence in us. We are proud to have you as a customer! Follow these three steps to protect your new appliance investment: Complete and mail your Consumer Product Ownership Registration today. Have the peace of mind of knowing we can contact you in the unlikely event of a safety modification. After mailing the registration below, store this document in a safe place. It contains information you will need should you require service. Our service number is 800 GE CARES (800-432-2737). Read your Owner’s Manual carefully. It will help you operate your new appliance properly. If you have questions, or need more information, call the GE Answer Center® 800.626.2000. 1 2 3 Model Number Serial Number Important: If you did not get a registration card with your product, detach and return the form below to ensure that your product is registered, or register online at www.geappliances.com. First Name Apt. # City Last Name Zip Code State Phone Number GE Appliances General Electric Company Louisville, Kentucky www.geappliances.com Mr. l Ms. l Mrs. l Miss l E-mail Address Occasionally, we may allow selected companies to send you information. l Check here if you do not want this information. Consumer Product Ownership Registration Model Number Serial Number Important Mail Today! Date Placed In Use Month Cut here " 30
GE Dishwasher Warranty. All warranty service provided by our Factory Service Centers, or an authorized Customer Care ® technician. For service, call 800-GE-CARES. This warranty is extended to the original purchaser and any succeeding owner for products purchased for home use within the USA. Proof of the original purchase date is needed to obtain service under the warranty. In Alaska, the warranty excludes the cost of shipping or service calls to your home. Some states do not allow the exclusion or limitation of incidental or consequential damages. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. To know what your legal rights are, consult your local or state consumer affairs office or your state’s Attorney General. For The Period Of: GE Will Replace: One Year Any part of the dishwasher which fails due to a defect From the date of the in materials or workmanship. During this full one-year original purchase warranty, GE will also provide, free of charge, all labor and in-home service to replace the defective part. Second Year Any part of the dishwasher which fails due to a defect From the date of the in materials or workmanship. During this second-year original purchase limited warranty, you will be responsible for any labor or in-home service costs. Five Years The dishwasher rack, if it should rust, or the electronic From the date of the control module if it should fail due to a defect in original purchase materials or workmanship. During this five-year limited warranty, you will be responsible for any labor or in-home service costs. Lifetime of Product The PermaTuf ® tub or door liner, if it fails to contain water due to a defect in materials or workmanship. During this full warranty, GE will also provide, free of charge, all labor and in-home service to replace the defective part. I Service trips to your home to teach you how to use the product. I Improper installation. I Replacement of house fuses or resetting of circuit breakers. I Failure of the product if it is abused, misused, or used for other than the intended purpose or used commercially. I Damage to the product caused by accident, fire, floods or acts of God. I Incidental or consequential damage to personal property caused by possible defects with this appliance. I Cleaning or servicing of the air gap device in the drain line. What GE Will Not Cover: Warrantor: General Electric Company. Louisville, KY 40225 31 Customer Service Troubleshooting Tips Operating Instructions Safety Information
Service Telephone Numbers. The GE Answer Center® is open 24 hours a day, 7 days a week.
