Common questions
Common Questions
23 total 1
What error codes can appear on the display and what do they mean?
The washer displays several error codes: water pressure sensing error, problem of overfilling water, door not closed, overload in motor (two separate codes), water inlet trouble, drainage trouble, unbalanced load, and water temperature trouble. If any of these error codes appear, you should refer to the troubleshooting guide for guidance on resolving the issue. (Page 19)
2
How do I remove the transit bolts before using the washing machine for the first time?
Before operating the washer, you must remove 4 transit bolts along with their rubber bungs by unscrewing them with the supplied spanner and slightly twisting the bungs. After removal, close the holes with the caps supplied, and keep the 4 bolts and spanner for future use in case the machine needs to be transported again. Failure to remove the transit bolts may cause heavy vibration, noise, and malfunction. (Page 5)
3
What type of detergent should I use in this front loading washing machine?
You should use powder detergent only for this front loading washer. Do not use solvents such as benzene, and do not exceed the maximum fill line in the detergent drawer. Using too much detergent can cause excessive suds, which decreases washing results and may cause heavy load on the motor leading to malfunction. Adjust detergent usage based on water temperature, water hardness, and load size. (Page 12)
4
How does the Time Delay function work and how do I set it?
The Time Delay function allows you to set the machine to finish washing at a later time, with a minimum delay of 3 hours and a maximum of 19 hours. To set it, press the Power button, select your program, press the Time Delay button to set the desired time (each press advances by one hour), then press Start/Pause. To cancel the Time Delay, press the Power button. Note that according to water supply conditions and temperature, the delayed time and actual washing time may vary. (Page 17)
5
What should I do to prepare the washing machine if it will be stored in freezing temperatures?
Turn off the water supply tap, disconnect hoses from the water supply, and drain the water from the hoses. Add 1 gallon (3.8L) of non-toxic recreational vehicle (RV) antifreeze into an empty wash drum, then run a spin cycle for 1 minute to drain out the water. Unplug the power cord, dry the drum interior, remove and dry the dispenser drawer, and store the washer upright. When resuming use after storage, run an empty wash cycle with detergent to remove the antifreeze. (Page 22)
6
Why won't the door open immediately after the wash cycle ends or when paused?
The door will not open for 1 to 2 minutes after pausing or at the end of the wash cycle, as the electric locking mechanism needs time to release. Once the Start/Pause button is pressed and the cycle starts, the door cannot be opened for safety reasons. If you need to pause the cycle, press the Start/Pause button and wait 1 to 2 minutes before the door can be opened. Note that if the washer is in pause mode, power will automatically turn off after 4 minutes. (Pages 16, 24)
Show 17 more questions
How do I activate and deactivate the Child Lock feature?
What type of detergent should I use, and how much should I add?
How do I set the Time Delay function?
How do I clean the drain pump filter?
What should I do if the washing machine will not drain or drains slowly?
What are the water supply pressure requirements for installation?
How do I protect the washing machine if it will be stored in freezing temperatures?
What are the maximum spin speeds available for the WD-1060F(H)D model?
What are the transit bolts and why do I need to remove them before using the washing machine?
How should I install the drain hose?
What water pressure is required for the washing machine?
What does the error code 'E1' mean and how do I fix it?
What is the maximum amount of detergent I should use?
How does the Time Delay function work and what is the maximum delay time?
What should I do if the washing machine vibrates excessively?
How do I activate and deactivate the Child Lock function?
What should I do if water does not enter the washer or enters slowly?
Full Manual
28 pages
Page 1
Washing Machine
Owner'S Manual
Wd-1060F(H)D/1065F(H)D
Wd-1260F(H)D/1265F(H)D
Wd-1460F(H)D/1465F(H)D
Thank you for buying a LG Fully Automatic Washing machine. Please read your owner's manual carefully, it provides instructions on safe installation, use and maintenance. Retain it for future reference. Record the model and serial numbers of your washing mach Page 2
roduct Feature
P
ontentsC
2 Warnings....................................................................................3 Specification ..............................................................................4 Installation..................................................................................5 Care before washing................................................................11 Adding detergent .....................................................................12 Function ...................................................................................13 How to use washer ..................................................................14 Maintenance ............................................................................20 Troubleshooting guide .............................................................23 Terms of Warranty ...................................................................26 Jumbo drum LG's jumbo drum can wash about 40% more load than conventional washing machines. A bigger drum improves the wash performance. More economical by Intelligent Wash System Intelligent Wash System detects the amount of load and water temperature, and then determines the optimum water level and washing time to minimize energy and water consumption. Direct Drive System The advanced Brushless DC motor rotates the Drum directly without belt and pulley. Child-Lock The Child-Lock system has been used to prevent children from pressing any button to change the program during operation. Low noise speed control system By sensing the amount of load and balance, it evenly distributes load to minimize the spinning noise level. Auto Restart If the washing machine is turned off by a power failure, it will restart automatically from the position it stopped at adjusting accordingly. 40% Wash Rinse Page 3
arnings
W
3 For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, personal injury, or loss of life. !Read All Instructions Before Use
Warning!
? Do not install or store the washer where it will be exposed to the weather. ? Do not tamper with controls. ? Do not repair or replace any part of the washer or attempt any servicing unless specifically recommended in the user-maintenance instructions or published user-repair instructions that you understand and have the skills to carry out. ? Keep the area underneath and around your appliances free of combustible materials such as lint, paper, rags, chemicals, etc. ? Close supervision is necessary if this appliance is used by or near children. Do not allow children to play on, with, or inside this or any other appliance. ? Do not leave the washer door open. An open door could entice children to hang on the door or crawl inside the washer. ? Never reach into washer while it is moving. Wait until the drum has completely stopped. ? The laundry process can reduce the flame retardant of fabrics. ? Do not wash or dry articles that have been cleaned in, washed in, soaked in, or spotted with combustible or explosive substances (such as wax, oil, paint, gasoline, degreasers, dry- cleaning solvents, kerosene, etc.) which may ignite or explode. ? To avoid such a result, carefully follow the garment manufacturer's wash and care instructions. ? Do not slam the washer door closed or try to force the door open when locked. This could result in damage to the washer. ? To minimize the possibility of electric shock, unplug this appliance from the power supply or disconnect the washer at the household distribution panel by removing the fuse or switching off the circuit breaker before attempting any maintenance or cleaning. ? Never attempt to operate this appliance if it is damaged, malfunctioning, partially disassembled, or has missing or broken parts, including a damaged cord or plug.Grounding Instructions
This appliance must be grounded. In the event of malfunction or breakdown, grounding will reduce the risk of electric shock by providing a path of least resistance for electric current. This appliance is equipped with a cord having an equipment-grounding conductor and grounding plug. The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinance. ? Do not use an adapter or otherwise defeat the grounding plug. ? If you don't have the proper outlet, consult an electrician.Important Safety Instructions
Warning
: To reduce the risk of fire, electric shock, or injury to persons when using the washer, follow basic precautions, including the following:Save These Instructions
Warning
: Improper connection of the equipment-grounding conductor can result in risk of electric shock. Check with a qualified electrician or serviceman if you are in doubt as to whether the appliance is properly grounded. Do not modify the plug provided with the appliance Page 4
pecification
S
4 Power plug Control panel Door Lower cover Leveling leg (For detergent and fabric softener) Drawer Drum Drain hose Lower cover cap Drain pump filter Drain plug If the supply cord is damaged, it must be replaced by the manufacturer or its service agents or a similarly qualified person in order to avoid a hazard. Name : Front loading washing machine Power supply : 220-240V~,50Hz Size : 600mm(W) 600mm(D) 850mm(H) Weight : 65kg Wash capacity : Refer to the Rating label Max. Watt: 2100W
Spin speed : No Spin/400/600/800/1000[WD-1060F(H)D] No Spin/400/800/1000/1200[WD-1260F(H)D/WD-1265F(H)D] No Spin/400/800/1000/1400[WD-1460F(H)D/WD-1465F(H)D] Water consumption :75 (10.7 /kg) Permissible water pressure : 0.3-10kgf/ (30-1000kPa) The appearance and specifications may be varied without notice to raise the units quality. Inlet hose(1EA) Option : Hot/Cold(2EA) Spanner Accessories Page 5
nstallation
I
5 cap Page 6
nstallation
I
6 Level floor : Allowable slope under entire washer is 1˚ Power outlet : Must be within 1.5 meters of either side of location of washer. Do not overload the outlet with more than one appliance. Additional Clearance : For wall, door and floor modeling is required. (10cm : rear /2cm:right & left side) Do not place or store laundry products on top of washer at any times. They can damage the finish or controls. Installation place requirement Laundry Tub Washer approx. 2cm Drain Hose BS Plug Safety Details (For U.K. User)Important
The Wires In This Mains Lead Are Coloured In
Accordance With The Following Code:
Green And Yellow: Earth
Blue: Neutral
Brown: Live
This appliance must be earthed As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: The wire which is coloured Green and Yellow must be connected to the terminal in the plug which is marked with the letter E or by the earth symbol or coloured Green or Green and Yellow. The wire which is coloured Blue must be connected to the terminal which is marked with the letter N or coloured Black. The wire which is coloured Brown must be connected to the terminal which is marked with the letter L or coloured Red. If a 13 amp (BS 1363) plug is used, fit a 13 amp BS 1362 fuse. Green and Yellow(Earth) Brown(Live) Blue(Neutral) Fuse Cord gripE
L
N
650 850 600 Page 7
7 nstallation
I
Water supply pressure must be between 30kPa and 1000kPa (0.3~10kgf/cm2) Don't strip or crossthread when connecting Inlet hose to the valve. If the water supply pressure is more than 1000kPa, a decompression device should be installed. ? Two rubber seals are supplied with the water inlet hoses these are in order to prevent water leaks. ? Check water tightness of washing machine connections by turning the tap completely on. ? Periodically check the condition of the hose and replace the hose if necessary. ? Make sure that there is no kink on the hose and that it is not crushed. When your washer has two valves, ? The Inlet hose which has red connector is for the hot water tap. ? If the washer has two valves, the energy is saved by using hot valve. Washing Machine is to be connected to the water mains using new hose- sets and that old hose-sets should not be used. Connecting water supply hose Rubber seal Hose connector Hot water tap Cold Hot(option) Cold water tap Page 8
8 nstallation
I
Normal Tap without thread & screw type inlet hose Normal Tap without thread & one touch type inlet hose Page 9
9 nstallation
I
Installation of drain hose max. 100 cm min. 60 cm ca. 105 cm ca. 145 cm ca. 100 cm max. 100cm min. 60cm Hose Retainer Laundry tub Tie strap max. 100cm min. 60cm max. 100 cm ca. 105 cm ca. 145 cm ca. 100 cm min. 60 cm ? The drain hose should not be placed higher than 100 cm above the floor. ? Proper securing of the drain hose will protect the floor from damage due to water leakage. ? When the drain hose is too long, do not force back into the washer. This will cause abnormal noise. ? When installing the drain hose sink, secure it tightly with a string. ? Proper securing of the drain hose will protect the floor from damage due to water leakage. This equipment is not designed for maritime use or for use mobile installations such as caravans, aircraft etc. Turn off the stopcock if the machine is to be left for any length of time (e.g. holiday), especially if there is no floor drain(gully) in the immediate vicinity. When disposing of the appliance, cut off the mains cable, and destroy the plug Disable the door lock to prevent young children being trapped inside. Packaging material (e.g. Films, Styrofoam) can be dangerous for children. There is a risk of suffocation ! Keep all packaging well away from children Page 10
10 nstallation
I
Level adjustment Page 11
11 are before washing
C
Page 12
12 dding detergent
A
? Main wash only U ?PreWash+MainWashU ? Do not exceed the maximum fill line. Overfilling can cause early dispensing of the fabric softener which could stain clothes. ? Do not leave the fabric softener in the detergent drawer for more than 2 days. (Fabric softener could harden) ? Softener will automatically be added during the last rinse cycle. ? Do not open the drawer when water is supplied. ? Solvents(benzene, etc) are not allowable.Max
Max
125 mlNote
Do not pour fabric softener directly on the cloths Page 13
13 unction
F
Recommended courses according to the laundry type Pre Wash : For heavily soiled and protein-stained items. Water Temperature : Select the water temperature to the wash cycles. Always follow garment manufacture's care label or instructions when laundering. Fabric Proper Washing Maximum Water Energy Time Program Temp. in in in Type (Option) (Option) Load Liter kWh Minutes Coloureds Synthetic Delicate Wool Rapid Whites Whites- Eco Color fast garments (shirts, night dresses, pajamas...)and lightly soiled white cotton (underwear...) Polyamide, Acrylic, Polyester Delicate laundry easily damaged (silk, curtains...) Machine washable woolens with pure new wool only Laundry type is the same in Coloureds and Synthetic. First check if laundry is machine washable. (white cotton, linen towels and sheets...) Laundry type is the same in Whites.40˚C
(Cold, 30˚C,60˚C)
40˚C
(Cold, 30˚C,60˚C)
Cold(30˚C,
40˚C)
Cold(30˚C,
40˚C)
Cold(30˚C,
40˚C)
95˚C
(40˚C,
60˚C)
60˚C
(40˚C)
Main(+Pre) Main(+Pre) Main Main Main Main(+Pre) Main(+Pre) Rating Less than 4.0 kg Less than 3.0 kg Less than 2.0 kg Rating Rating Rating 75 55 55 55 55 90 70 0.47 0.39 0.15 0.05 0.10 2.74 1.13 119 92 65 55 54 162 178 Page 14
14 ow to use washer
H
? Press the Power button to start. ? Press the Start/Pause button. ? Initial condition95˚C
Page 15
15 ow to use washer
H
Program ? 7 programs are available according to the laundry type. Page 16
16 ow to use washer
H
Start/Pause ? This Start/Pause button is used to start wash cycle or pause the wash cycle. ? If temporary stop of wash cycle is needed, press Start/Pause button. ? When in Pause, the power is turned off automatically after 4 minutes. ? NB. The door will not open before 1 to 2 minutes when Pause is selected, or at the end of the wash cycle. Page 17
17 ow to use washer
H
Page 18
18 ow to use washer
H
[Wd-1060F(H)D]
[Wd-1260F(H)D/
1265F(H)D]
[Wd-1460F(H)D/
1465F(H)D]
[Wd-1060F(H)D]
? Spin speed is available according to the program as follows.[Wd-1260F(H)D/1265F(H)D/1460F(H)D/1465F(H)D]
[Wd-1260F(H)D/
1265F(H)D]
[Wd-1460F(H)D/
1465F(H)D]
95˚C
? By pressing the Temp button, the water temperature can be selected.-30˚C/40˚C/60˚C/95˚C
? Water temperature can be selected as below according to the program.40˚C U
60˚C U
Cold U30˚C
95˚C U
40˚C U
60˚C
60˚C U
40˚C
30˚C U
40˚C
The required temperature lamp will light upfor identification. For the more detailed information, please refer to the page13. Page 19
19 ow to use washer
H
? If the washer encounters a fault during operation, the associated fault will be displayed. " " : Water pressure sensing error " " : Problem of overfilling water " " : Door is not closed " " : Over load in motor " " : Over load in motor " " : Water inlet trouble " " : Drainage trouble " " : Unbalanced load " " : Water temperature trouble If these error letters are displayed, please refer to the troubleshootingpage23 and follow the guide. Display ? When child lock is selected, the " " is displayed. ? When time delay is selected, it shows the remaining times to finish the selected program. ? When washing cycle is completed, " " is displayed on the "Multi display". ? During washing cycle, the remaining washing time is displayed. ? Recommended program by manufacturer. Page 20
20 aintenance
M
The water inlet filter -" " error message will blink on the control panel when water does not enter the detergent drawer.Caution
First drain using the drain hose and then open the pump filter to remove whatever any threads or objects. Be careful when draining if the water is hot. Allow the water to cool down before cleaning the drain pump, carrying out emergency emptying or opening the door in an emergency. Before cleaning the washer interior, unplug the electrical power cord to avoid electrical shock to avoid electrical shock hazards. When disposing of the appliance, cut off the mains cable, and destroy the plug Disable the door lock to prevent young children being trapped inside. Page 21
21 aintenance
M
Dispenser drawer After a while detergents and fabric softeners leave a deposit in the drawer. ? It should be cleaned from time to time with a jet of running water. ? If necessary it can be removed completely from the machine by pressing the catch downward and by pulling it out. ? To facilitate cleaning, the upper part of the fabric softener compartment can be removed. The drawer recess Detergent can also accumulate inside the recess which should be cleaned occasionally with an old toothbrush. ? Once you have finished cleaning, replace the drawer and run a rinse cycle without laundry. The washing drum ? If you live in a hard water area, limescale may continuously build up in places where it cannot be seen and thus not easily removed. Over time the build up of scale clogs appliances, and if it is not kept in check these may have to be replaced. ? Although the washing drum is made of Stainless steel, specks of rust can be caused by small metal articles (paper clips, safety pins) which have been left in the drum. ? The washing drum should be cleaned from time to time. ? If you use descaling agents, dyes or bleaches, make sure they are suitable for washing machine use. Descaler may contain chemicals that may damage part of your washing machine. Remove any spots with a stainless steel cleaning agent. Never use steel wool. max max Page 22
22 aintenance
M
Cleaning your washerNote
Remove hard water deposits using only cleaners labeled as washer safe. Page 23
23 roubleshooting guide
T
This washing machine is equipped with automatic safety functions which detect and diagnose faults at an early stage and react appropriately. When the machine does not function properly or does not function at all, check the following points before you contact your service provider. Symptom Possible Cause Solution Rattling and clanking noise Thumping sound Vibrating noise Water leaks. Oversudsing Water does not enter washer or it enters slowly Water in the washer does not drain or drains slowly. ? Foreign objects such as coins or safety pins maybe in drum or pump. ? Heavy wash loads may produce a thumping sound. This is usually normal. ? Have all the transit bolts and packing been removed? ? Are all the feet resting firmly on the ground? ? Fill hoses or drain hose are loose at tap or washer. ? House drain pipes are clogged. ? Water supply it not adequate in area. ? Water supply tap is not completely open. ? Water inlet hose(s) are kinked. ? The filter of the inlet hose(s) are clogged. ? Drain hose is kinked or clogged. ? The drain filter is clogged. Stop washer and check drum and drain filter. If noise continues after washer is restarted, call your authorized service centre. If sound continues, washer is probably out of balance. Stop and redistribute wash load. If not removed during installation, refer to Installation guide for removing transit bolts. Wash load may be unevenly distributed in drum. Stop washer and rearrange wash load. Check and tighten hose connections. Unclog drain pipe. Contact plumber if necessary. Too much detergent or unsuitable detergent may cause excessive foaming which may result in water leaks. Check another tap in the house. Fully open tap. Straighten hose(s). Check the filter of the inlet hose(s). Clean and straighten the drain hose. Clean the drain filter. Page 24
24 roubleshooting guide
T
Washer does not start Washer won't spin Door does not open Wash cycle time delayed ? Electrical power cord may not be plugged in or connection may be loose. ? House fuse blown, circuit breaker tripped,or a power outage has occurred. ? Water supply tap is not turned on. Check that the door is firmly shut. Make sure plug fits tightly in wall outlet. Reset circuit breaker or replace fuse. Do not increase fuse capacity. If problem is a circuit overload, have it corrected by a qualified electrician. Turn on water supply tap. Close the door and press the Start/Pause button. After pressing the Start/Pause button, it may take a few moments before the clothes washer begins to spin. The door must lock before spin can be achieved. Once started, the door can not be opened for safety reasons. Wait one or two minutes before opening the door to give the electric locking mechanism time to release. The washing time may vary by the amount of laundry, water pressure, water temperature and other using conditions. If the imbalance is detected or if the suds removing program works, the wash time shall be increased. Symptom Possible Cause Solution Page 25
25 roubleshooting guide TSymptom Possible Cause Solution ? Water supply is not adequate in area ? Water supply taps are not completely open. ? Water inlet hose(s) are kinked. ? The filter of the inlet hose(s) are clogged. ? Drain hose is kinked or clogged. ? The drain filter is clogged. ? Load is too small. ? Load is out of balance. ? The appliance has an unbalance detection and correction system. If individual heavy articles are loaded (ex. bath mat, both robe, etc.), this system may stop spinning or even interrupt the spin cycle altogether. ? If the laundry is still too wet at the end of the cycle, add smaller articles of laundry to balance the load and repeat the spin cycle. ? Is the door opened? ? Water overfills due to the faulty water valve. ? Water level sensor has malfunctioned. ? Over load in motor. ? Over load in motor. Check another tap in the house. Fully open tap. Straighten hose(s). Check the filter of the inlet hose(s). Clean and straighten the drain hose. Clean the drain filter. Add 1 or 2 similar items to help balance the load. Rearrange load to allow proper spinning Close the door. If " "is not released, call for service. Unplug the power plug and call for service. Close the water tap. Unplug the power plug. Call for service.
Page 26
erms of Warranty
T
26 What Is Not Covered: ? Service trips to your home to teach you how to use the product. ? If the product is connected to any voltage other than that shown on the rating plate. ? If the fault is caused by accident, neglect, misuse or Act of God. ? If the fault is caused by factors other than normal domestic use or use in accordance with the owner's manual. ? Provide instruction on use of product or change the set-up of the product. ? If the fault is caused by pests for example, rats or cockroaches etc.. ? Noise or vibration that is considered normal for example water drain sound, spin sound, or warming beeps. ? Correcting the installation for example, levelling the product, adjustment of drain. ? Normal maintenance which recommended by the owner's manual. ? Removal of foreign objects / substances from the machine, including the pump and inlet hose filter for example, grit, nails, bra wires, buttons etc. ? Replace fuses in or correct house wiring or correct house plumbing. ? Correction of unauthorized repairs. ? Incidental or consequential damage to personal property caused by possible defects with this appliance. ? If this product is used for commercial purpose, it is not warranted. (Example : Public places such as public bathroom, lodging house, training center, dormitory) If the product is installed outside the normal service area, any cost of transportation involved in the repair of the product, or the replacement of a defective part, shall be borne by the owner. Page 27
emo
M
27 Page 28
P/No.: 3828ER3005L
