Whirlpool 3363564 Top Load Washer

UseAndCare A Note to You ......................... 2 Washer Safety ........................ 3 Parts and Features.. ............... 4 Operating Your Washer ......... 5 Starting your washer.. ......... 5 Stopping/restarting your washer ........................ 8 Selecting a cycle and time ... 9 Using rinse and spin ......... 11 Using drain and spin ......... 11 Understanding normal washer sounds.. ................ 11 Understanding what happens in each cycle ...... 12 MAGIC CLEAN@lint filter.. .. 12 Adding liquid chlorine bleach ............................... 13 Adding liquid fabric softener.. ........................... 14 Caring for Your Washer.. ..... 15 Laundry Tips.. ....................... 16 Removing Stains .................. 21 Troubleshooting ................... 24 Requesting Assistance or Service .............................. 26 Warranty ............................... 28 1-800-253-l 301 Call us with questions or comments.

Two Speed Automatic

Washers

With Hand Washables

Cycle

Part No. 3363564

v7r D-Line

A Note to You Thank you for buying a WHIRLPOOL@ appliance. Because your life is getting busier and more complicated,

Whirlpool

washers are easy to use, save time, and help you manage your home better. To ensure that you enjoy years of trouble-free operation, we developed this Use and Care Guide. It contains valuable infor- mation about how to operate and maintain your washer properly and safely. Please read it carefully. Also, please complete and mail in the Ownership Registration Card provided with your appliance. The card helps us notify you about any new information on your appliance. Please record your model’s information. Whenever you call to request service on Model Number your appliance, you need to know your complete model number and serial number. Serial Number You can find this information on the model Purchase Date and serial number plate (see diagram on Dealer Name page 4 for location of plate). Please also record the purchase date of your appliance and your dealer’s name, address, and telephone number. Dealer Address Dealer Phone Keep this book and the sales slip together in a safe place for future reference.

I

Our Consumer Assistance Center number is toll-free 24 hours a day. 1-800-253-1301 1 2

Washer Safety Your safety is important to us. This guide contains safety statements under warning symbols. Please pay special attention to these symbols and follow any This symbol will help alert you to such instructions given. Here is a brief explana- dangers as fire, electrical shock, burns, tion of the symbol. and personal injury.

Important

Safety

Instructions

Understanding your responsibilities l Store laundry aids and other materials in a l Do not use chlorine bleach and ammonia cool, dry place where children cannot reach or acids (such as vinegar or rust remover) them (in a locked cabinet if possible). in the same wash. Hazardous fumes can l Read and follow instructions on packages of form. detergent and laundry aids, especially l Unplug power supply cord before attempt- warnings and precautions. ing to service your washer. l Do not wash or dry items that are soiled with l Do not machine wash fiberglass materials. vegetable or cooking oil. These items may Small particles can stick to fabrics washed contain some oil after laundering. Due to the in following loads and cause skin irritation. remaining oil, the fabric may smoke or catch _. ._ 3 tire by rtselt. l Read all instructions before using your washer. l Do not machine wash or machine dry items cleaned, washed, soaked in, or spotted with wax, paint, gasoline, oil, or other flammable fluids. The fumes can create a fire hazard or explosion. Always hand wash and line dry items containing these materials. l Flammable fluids (dry-cleaning solvents, kerosene, gasoline, etc.) should not be used or stored in or near your washer. Do not add flammable fluids to your wash water. These substances give off vapors that can create a fire hazard or explosion. l Do not allow children to operate, play with, or crawl on or inside your washer. Supervise children closely when your washer is used near them. *Before your washer is removed from service or discarded, remove the lid to prevent accidental entrapment. *After starting a cycle, do not reach into the basket unless the Cycle Control Knob is pushed in and all motion stops. l Do not tamper with the controls. l If your hot water has not been used recently (usually 2 weeks or longer), hydrogen gases may build up in your water heater and your hot water pipes.

Hydrogen

Gas Is Explosive.

To prevent injury or damage, before using your washer, turn on all hot water faucets and allow water to run for several minutes. This will allow gases to escape. Do not smoke or use any open flame near your faucet while it is open. Please . . . l Have only a qualified person install, repair, or replace parts on washer. *Maintain washer properly. l Protect washer from the weather and keep it where the temperature will not fall below freezing. l Install and level washer on a floor that can support the weight.* l Connect washer to the correct 3-prong outlet, electrical supply, water supply, and drain.* aGround washer properly.* l See the Installation Instructions.

- Save These Instructions

-

Parts and Features The parts and features of your washer are illustrated on this page. Become familiar with all parts and features before using your washer.

Notes:

l The drawings in this book may vary from your washer model. They are designed to show the different features of all models covered by this book. Your model may not include all features. l Page references are included next to some features. Refer to those pages for more information about the features. Load size Water temperature Cycle signal Extra rinse selector

(P. 6)

selector /

(P. 8)

Clean Touch@

panel*

(Pp. 7,8)

Liquid fabric softener / dispenser*

(P. 14)

Liquid chlorine

I

bleadh dispenser l On some models. Other models have rotary knobs. Model and serial

number

plate (under lid)

Basket

ITub

Magic Cleaw

lint filter (bottom of washer basket)

(P. 12)

4

Operating Your Washer To obtain the best washing results, you must operate your washer properly. This section gives you this important information. Page references are included for more information. Starting your washer

Add measured

detergent to the washer. Then place a sorted load of clothes in the washer. l Sort and load clothes as described on pages 16 and 17. l If desired, you may also add color safe bleach or extra detergent for the Super Wash cycle.

2. (Optional

STEP) If desired, add measured liquid chlorine bleach to the liquid bleach dispenser. See page 13. l Use only liquid chlorine bleach in the bleach dispenser.

3. (Optional

STEP) If desired, on models with a liquid fabric softener dispenser, pour measured liquid fabric softener into the dispenser. See page 14. l If your model does NOT have a liquid fabric softener dispenser, see Step 11 and page 14.

Close the washer

lid. Fabric schtener dispenser (on some models) continued on next page 5

Small

A

1 Load Size

Turn the Load Size Selector

to the setting that corresponds with the size of your wash load and the type of fabric being washed. l The Load Size Selector is a rotary knob. Depending on your model, your washer has three, four, or five load size settings: -Small

Or

-Small OR -Extra -Medium -Medium Small -Large -Large -Small -Extra -Medium Large

Large

-Extra Large l To change the load size setting after the washer has started to fill, turn the Selector to the desired new setting.

I

Load Ske

I

Or

Load Size 6

Select a wash-rinse

temperature with the Water Temperature Selector. Match the water temperatures with the type of fabric and soils being washed. l See page 18 for water temperature guidelines. l Depending on your model, your washer has one of the Water Temperature Selectors shown:

Rotary knob with three temperature

selections;

Rotary knob with four temperature

selections;

CLEAN TOUCHTM Selector

with four temperature selections. (The washer shown on page 4 has a CLEAN TOUCH panel.) l For all Selectors, the top temperature is the wash water, and the bottom temperature is the rinse water. NOTE: On CLEAN TOUCH models, a colored indicator shows the setting you select.

7. (Optional

STEP) If desired, on models with the Extra Rinse option, set the CLEAN TOUCH Extra Rinse Selector to On to add an additional rinse and spin to the end of the wash cycle. l Use the Extra Rinse option when adding extra detergent for the Super Wash cycle, or any other cycle, depending on your model. old Wash RIllsa Temperature Rotary Knob

Or

1 TemEture Rotary Knob

Or

rll Temperature

Clean Touch

Selector

I

Options

Clean Touch

Selector continued on next page 7

8. (Optional

STEP) If desired, on models with the end-of-cycle signal option, set the CLEAN TOUCHTM Cycle Signal to On if you want the washer to alert you when the wash cycle is complete. l The signal is helpful when you are washing items that should be removed from the washer as soon as the cycle ends.

Push In the Cycle Control

Knob and turn it clockwise to the wash cycle you want. See pages 9 and 10.

Pull out the Cycle Control

Knob to start the washer.

11. (Optional

STEP) If deslred, on models with no liquid fabric softener dispenser, add measured liquid fabric softener to the rinse water. See page 14.

I

ws* w-1 Options

Clean Touch

Selector r Stopping/restarting your washer l To stop the washer at any time, push in the Cycle Control Knob. l To restart the washer, close the lid (if necessary) and pull out the Cycle Control Knob. 8

Selecting a cycle and time This section illustrates and describes the l Some washer models have an Extra Rinse wash cycles you can select with the Cycle option in most wash cycles. Control Knob. Use this information to help l Cycle descriptions are included below and you make the best cycle selections for your on the following pages for 6-cycle, 7-cycle, wash loads. Each cycle is designed for and 8-cycle models. different types of fabrics and soil levels. l Refer to page 11 to learn more about the l The washer pauses briefly throughout sounds you may hear during a wash cycle. each cycle. These pauses are normal for washer operation. l Refer to page 12 to help you understand what happens during a wash cycle. Super Wash Cycle The Super Wash cycle (18 minutes) features an extended wash time for washing heavily soiled loads that need maximum soil removal. For improved cleaning, use two times the amount of detergent recommended for a wash cycle. Normal Cycle The Normal cycle features the Gentle Wash system, and high agitation and spin speeds to shorten drying time. Use this cycle for cleaning cotton and linen fabrics. Select

9 (Regular)

or 12 (HEAVY) minutes of wash time, depending on whether your load is moderately or heavily soiled. For lightly soiled cotton and linen fabrics, use 6 minutes of wash time. (On 8-cycle models, this is labeled SOFTWASH.) On All Models 6 and 7-Cycle Models &Cycle Model 9

Permanent Press Cycle The Permanent Press cycle features the Gentle Wash system, a cool-down rinse, and low spin speeds to reduce wrinkling. Use this cycle for cleaning permanent press and some synthetic fabrics. Select 6 (LIGHT) or 9 (REGULAR) minutes of wash time, depending on whether your wash load is lightly or moderately soiled. NOTE: On 6-cycle models, the Permanent Press cycle has 9 minutes of wash time. Delicates Cycle The Delicates cycle features a reduced agitation speed for gentle soil removal. Low spin speeds reduce wrinkling. Use 6 minutes of wash time for cleaning lightly to moder- ately soiled delicate items and washable knits. Hand Washables Cycle The Hand Washables cycle features brief, low-speed agitation (2 seconds), and short soaks (28 seconds) to gently clean special- care items. Low spin speeds reduce wrin- kling. Use 6 minutes of wash time to clean lightly soiled hand washables. Wash small loads. If items appear to be floating (due to trapped air), stop the washer by pushing in the Cycle Control Knob. Push items down into the washer. Restart the washer. Refer to “Hand Washables” on page 19 for more information. 6 and 7-Cycle Models 6 and 7-Cycle Models 6 and 7-Cycle Models 6-Cycle Model

I

&Cycle Model &Cycle Model 10

Using rinse and spin NOTE: On some models, an Extra Rinse option is available in most cycles. (See paw 7.1 When using extra detergent for heavily soiled clothes, or washing special-care items, you may find an extra rinse and spin is needed.

To add an additional

rinse, push in the Cycle Control Knob and turn clockwise to RINSE, as illustrated.

Pull out the Cycle Control Knob. The

washer fills to selected load size, agitates, drains, and spins. Using drain and spin A drain and spin may help shorten drying times for some heavy fabrics or special-care items by removing excess water.

Push in the Cycle Control Knob and turn

clockwise to SPIN, as illustrated.

Pull out the Cycle Control Knob. The

washer drains, then spins. Understanding normal washer sounds Your new washer may make sounds that During drain your old one didn’t. Because the sounds are unfamiliar, you may be concerned about The rate that water is drained from your them. Don’t be; most of them are normal. washer depends on your installation. If water The following describes some of the is drained quickly from the washer, you may sounds you may hear and what causes hear air being pulled through the pump. This them. happens during the end of draining. During washing After drain and before spin When you select a small load size setting for When the cycle changes from draining to a small wash load, your washer has a lower spinning, you may hear gears engaging. water level. With this lower water level, you may hear a clicking sound from the upper portion of the agitator. 11

Understanding what happens in each cycle When the Cycle Control Knob is set to a number and pulled out, the washer fills (to the selected load size) before agitation and timing start. The washer begins agitating immediately after filling; agitation occurs with the washer lid up or down. During agitation, the XTRA ROLL ACTIONTM agitator creates a continu- ous rollover action that provides a thorough cleaning of the wash load. After agitation starts, the Cycle Control Knob turns clockwise until it points to an OFF area and the cycle ends.

Notes:

l The washer pauses briefly throughout each cycle. These pauses are normal for washer operation. l A Gentle Wash system helps protect your fabrics by reducing wash agitation speed during the last few minutes of wash agitation in the Normal and Permanent Press cycles.

Wash

F”1

4 Fill Wash selected time

I4

-:- Drain* No agitation *The Permanent Press cycle partially drains, fills, agitates briefly, and drains. w 4 Spin

Rinse

Fill Rinse t.....l -+- Drain-No agitation w Spin-Spray rinse l&J Spin w ofi

Magic

Clean”

lint filter The lint filter at the bottom of the washer basket cleans itself. During agitation, wash and rinse water passes over the filter, separating the lint from the water. The lint is then spun away from the filter and out of the system during the spin part of the cycle. If your washer drains into a tub, remove any lint collected in the tub or strainer.

Magic Clean

Basket lint filter interior 12

Adding liquid chlorine bleach Use your washer’s liquid chlorine bleach dispenser to add bleach to the wash load. Always measure liquid chlorine bleach. Do not guess. Never use more than 1 cup (250 mL) for a full load. Use less with lower water level settings. Follow manufacturer’s directions for safe use. Use a cup with a pouring spout to avoid spilling.

Load the washer.

Pour measured chlorine bleach carefully

into the dispenser. Do not let bleach splash, drip, or run down into washer basket. Undiluted bleach will damage any fabric it touches.

Start the washer. Bleach will be diluted

automatically during wash part of cycle. NOTE: Do not use this dispenser to add powdered chlorine or color safe bleach to your wash load. The dispenser is for liquid chlorine bleach use only. 13

Adding liquid fabric softener Models with fabric softener dispenser installed

Add detergent and load clothes into the

basket.

Pour liquid fabric softener into the dis-

penser using the amount recommended on the package. Avoid dripping or spilling any fabric softener on the load.

Dilute fabric softener with warm water.

Fill dispenser with warm water until liquid reaches the cross bar in the opening.

Start the washer. Diluted fabric softener

will be added to the load during the final rinse. NOTE: Do not stop the washer before the rinse part of the cycle begins. Staining can occur.

Flush dispenser periodically

with warm water, as illustrated. l To remove the dispenser, grasp the top of the dispenser with both hands. Squeeze and push upward with thumbs to remove. l Clean dispenser by holding under water faucet. Replace after cleaning. NOTE: Do not wash clothes with this dispenser removed. Do not add detergent or bleach to dispenser. The dispenser is for liquid fabric softener use only. Models with no fabric softener dispenser installed l Always dilute fabric softeners with l/2 cup (125 mL) to 1 cup (250 mL) warm water. Undiluted fabric softener can stain fabrics. l Add diluted fabric softener only in the final rinse. l Fabric softeners should not be mixed with other laundry products because greasy stains may form. If stains form, remove by wetting the stain and rubbing with liquid detergent or a bar of soap. Rewash the stained item. l Too much fabric softener can make some items (diapers and towels) nonabsorbent. If this happens, use less fabric softener, or do not use it every time. 14

Caring for Your Washer Proper care of your washer can extend its life. This section explains how to care for your washer properly and safely. Cleaning your washer Exterior Interior Wipe up detergent, bleach, and other spills liiiid with a soft, damp cloth or sponge as they occur. Occa- sionally wipe the outside of the ’ . washer to keep it looking like new. Clean interior with 1 cup (250 mL) of chlo- rine bleach mixed with 2 cups (500 mL) of detergent. Run washer through a complete cycle using hot water. Repeat process if necessary. Do not put sharp or metal objects in your washer. They can damage the finish. Check all pockets for pins, clips, money, bolts, nuts, etc. Do not lay these objects on your washer after emptying pockets. NOTE: Remove hard water deposits using only cleaners labeled as washer safe. Winter storage or moving care Install and store your washer where it will not freeze. Because some water may stay in the hoses, freezing can damage your washer. If storing or moving your washer during freezing weather, winterize it. To winterize washer: To use washer again:

Shut off both water faucets.

Flush water pipes and hoses.

Disconnect

and drain water inlet hoses.

Reconnect water inlet hoses.

Put 1 quart (1 L) of R.V.-type antifreeze in

Turn on both water faucets.

the basket.

Reconnect power supply cord.

Run washer on a drain and spin setting

(see page 11) for about 30 seconds to

Run the washer through a complete cycle

mix the antifreeze and water. with 1 cup (250 mL) of detergent to clean out antifreeze.

Unplug the power supply cord.

Non-use or vacation care Operate your washer only when you are at home. If you will be on vacation or not using your washer for an extended period of time, you should: l Unplug the power supply cord or turn off l Turn off the water supply to the washer. This helps avoid accidental flooding (due to a water pressure surge) while you are away. electrical power to the washer. 15

Laundry Tips This section reviews proper laundering techniques and gives you additional washing information. Preparing clothes for washing l Close zippers, snaps, and hooks to avoid l Tie strings and sashes so they will not snagging other items. Remove tangle. pins, buckles, and other hard l Mend tears, loose hems, and seams. objects to avoid scratching the washer interior. Remove non- l Treat spots and stains. (See “Removing washable trim and ornaments. Stains” on pages 21-23.) l Empty pockets and turn them inside out. l Stained or wet garments should be l Turn down cuffs, brush away lint and dirt. washed promptly for best results. l Turn synthetic knits inside out to avoid pilling. Sorting l Separate heavily soiled items from lightly soiled ones, even if they would normally be washed together. Separate lint givers (towels, chenille) from lint takers l Separate dark colors from light colors, colorfast items from noncolorfast items. l Sort by fabric and construction (sturdy cottons, knits, delicate items). (corduroy, synthetics, perma- nent press). When possible, turn lint givers inside out. Loading l Drop items into washer loosely. Fill to the

Il2

top of the basket (top row of holes). Do not wrap items around the agitator. Items should move easily through wash water for best cleaning and wrinkle-free results. Items should sink and reappear later. l Load washer properly and select correct load size setting. Overloading or packing the machine, and selecting a setting too small for the wash load can: -cause poor cleaning.

increase wrinkling.

create excessive

lint. -wear out items faster (because of pilling) l Load by the amount of space items take up, not by their weight. l Mix large and small items in each load. l!!Ea Load evenly to maintain ; washer balance. An off- balance load can make the --’ -- washer vibrate during spin. l Use a large load size setting to reduce wrinkling with permanent press clothes and some synthetic knits. These items should have more room to move in the water than heavy items (towels, jeans). l Reduce wash time when using a small load size setting. Loads with only a few small items need less wash time. 16

Loading suggestions For these suggested full-sized loads, set the Load Size Selector to the highest load size setting.

Super Capacity

Washers

Heavy Work Clothes 3 pair pants 3 shirts 4 pair jeans 1 coverall 1 overall Knits 3 slacks 3 blouses 6 shirts 4 tops 4 dresses Permanent Press Mixed Load Towels 2 double or 3 double sheets 10 bath towels 1 king size sheet(s) 4 pillowcases 10 hand towels 1 tablecloth 8 T-shirts 14 wash cloths 1 dress 6 pair shorts 1 bath mat 1 blouse 2 shirts 2 slacks 2 blouses Delicates 3 shirts 8 handkerchiefs 3 camisoles 2 pillowcases 1 quilted robe 4 slips 4 panties 2 bras 2 nighties 1 baby’s dress Saving energy l Use warm or cold wash water for most loads. Use hot water only when washing heavy, greasy soils or whites. l Use cold rinses. l Wash full loads. l Use lower water levels when washing small loads. l Avoid rewashing. Use enough detergent and pretreat stains or heavy soils. Use the cycles and wash times recommended for the fabric and soil. l Use your washer during off-peak hours - usually early morning and late evening. (Ask your power company.) 17

Water guidelines Selecting water temperatures

Wash Water

Temperature*

Suggested

Fabrics

Comments

Hot

l Work clothes l Best cleaning for heavily soiled items

130°F (54°C)

l Sturdy whites/colorfast l Removes oils, perspiration, greasy or above pastels soils, and stains l Diapers l Prevents graying or yellowing

Warm

l DarkInoncolorfast colors l Best for moderately soiled to lightly 90-l 10°F l Permanent press items soiled items

(32-44°C)

l Nylon, polyester, acrylics, l Safe for most fabric finishes silks, woolens l Less fading and dye bleeding l Knits/delicate fabrics l Reduces wrinkling

Cold

l Extra-sensitive colors l Best for very lightly soiled items

70-90°F

l Noncolorfast items l Saves hot water

, (21-32”(Z)

l Hand washables l Best rinse water temperature ’ The washer features cold rinses for all wash temperatures. In addition, on some models, warm rinses are available with warm washes. Warm rinse water provides better water extraction than cold rinse water and shortens drying times. However, warm rinse water may increase wrinkling when line drying. In cold climates, warm rinse water also provides a more comfortable temperature for handling the wash load. Checking hot water temperature Your hot water should be 130°F (54°C) or above. If you do not know your hot water temperature, you can check it easily. You may need to raise the temperature of your water heater. To check your hot water:

Fill a pan with the hottest water available

from the faucet that fills your washer. NOTE: If you do not have a faucet at your washer site, collect the water from the faucet closest to your washer.

Place a candy thermometer

or cooking thermometer in the water to check the temperature. NOTE: In wash water temperatures colder than 70°F (21 “C), detergents do not dissolve well. Also, soils may be difficult to remove, and some fabrics may retain wear wrinkles and may have increased pilling. Water hardness Many poor washing results can be traced to the hardness of the wash water. To check your water hardness: l City water - ask the city water company. l Well water - ask the local water authority. Ask for the mineral content in grains/gallon or parts/million. If your water is more than 8 grains/gallon or more than 137 parts/ million, you should consider: l Installing a water softener. l Using more detergent. l Using a packaged water conditioner. l Not using soap. 18

Washing special-care items Most garments and household textiles have care labels with laundering instructions. Always follow care label directions when they are available. Below are general washing instruc- tions for some special washables.

Item

Blankets (electric or woolen) Curtains, drapes, slipcovers

Care Instructions

Pretreat spots and stains. Select water temperature, cycle, and time according to the type of blanket being washed. Two rinses may be necessary. Check care label to see if manufacturer recommends machine washing. Wash small loads. Crowding may cause wrinkling. Replace slipcovers while still slightly damp. They will dry to fit tightly. NOTE: Sun-damaged curtains and draperies will tear whether hand or machine washed. Diapers When using chlorine bleach for soaking, add extra detergent to the load. Avoid overuse of fabric softeners - absorbency will be reduced. Elastic, spandex Flame-retardant clothing Hand washables Elastic picks up oil from the body. Oil can damage elastic. Wash often to reduce the damage. Use warm water and sufficient detergent to remove oils. Do not use chlorine bleach. Items will be clearly labeled as flame-retardant. Follow manufacturer’s instructions to retain flame-retardant qualities. Garments are labeled “Hand Wash” because: l The fiber or construction may be sensitive to agitation. l The fabric contains sensitive dyes that may bleed. Properly sort and then use your Hand Washables cycle for gentle washing. Follow care label directions for drying. Items that may shrink should be dried flat. Block these items by gently stretching to original measurements. Woolens tend to shrink more the first time they are washed. continued on next page 19

Item

Care Instructions

Knits Knits are comfortable to wear because they stretch. However, this means that knits are more likely to be stretched and damaged when washed (especially bulky knits). Knits made of synthetic fabrics such as polyester, nylon, and acrylic tend to keep their original shape more than knits made of cotton or ramie. Pillows, stuffed Washing feather pillows is not recommended unless they will be toys dried in a dryer. Plastic, rubber Treat as delicate items. Wash in warm water. Wash small items in items a mesh bag. Quilts, bedspreads Do not wash cotton-filled comforters unless they are quilted or stitched. Tucked cotton batting tends to slip and become lumpy. An extra rinse may be necessary. Scatter rugs Shake or vacuum rugs to remove loose dirt. Wash more than one rug at a time. If washing only one rug, add bath towels to balance the load. Snowsuits, Jackets Wash only one or two items at a time. You may need to stop the washer occasionally to press air from the items being washed. An extra rinse may be necessary. 20

Removing Stains Stained, heavily soiled, or greasy items may need to be prewashed or soaked for best results. Soaking helps remove protein-type stains like blood, milk, or grass. Prewashing helps loosen soil before washing. Stain removal rules l Use warm water for soaking or prewashing stained laundry. Hot water can set stains. l Most stains are easier to remove when they are fresh. Old or set stains may not come out. Follow package directions for pretreatment products. l Before treating any stain, find out what kind of stain it is, how old the stain is, what kind of fabric it is, and if the fabric is colorfast. (Check the care label.) l Washing and drying can set some stains. l Start with cold or warm water. Hot water can set some stains. l When bleach is recommended, use a bleach that is safe for the fabric. l Test stain removers on an inside seam or hidden corner of the item to see if the color is removed. l Put the stained area face down on a paper towel or white cloth. Apply the stain remover to the back of the stain. This forces the stain off the fabric instead of through it. l Meat tenderizer or enzyme presoaks help break down some protein stains so they are easier to remove. Stain removal guide

Stain

Alcoholic beverage

To Remove

These stains turn brown with age, so treat immediately. Sponge or soak fresh stains with cold water. Wash. If stain remains, soak 15 minutes in a solution of lukewarm water, liquid detergent, and a few drops of white vinegar. Rinse. Wash. Blood Rinse immediately or soak in cold water with enzyme presoak for 30 minutes or longer. Rinse. Rub detergent into any remaining stains. Rinse. If stain remains, put a few drops of 3% hydrogen peroxide on stain for 3-5 minutes. Rinse thoroughly. Wash. Chewing gum Chocolate or coffee Use ice to make gum hard. Scrape off what you can. Sponge with a nonflammable fabric cleaner. Let dry. Wash. Sponge immediately with a nonflammable fabric cleaner or apply a prewash soil and stain remover. Rinse. Wash. If stain remains, apply a liquid deter- gent to stain or soak in warm water with an enzyme presoak. Rewash. Crayon and Scrape off excess with a dull knife. Place fabric between two blotters or candle wax facial tissue. Press with warm iron. Remove color stain with nonflammable fabric cleaner. Hand wash until stain is gone. If full load is crayon stained, take to cleaners or coin-operated dry cleaning machine. Cream, milk, or ice cream Sponge with a nonflammable fabric cleaner, or a prewash soil and stain remover. Rinse. Wash. Repeat if necessary. If stain remains, apply a few drops of liquid detergent and a few drops of ammonia. Blot dry and rinse. If stain remains, soak in an enzyme presoak. Wash. continued on next page 21

Stain

To Remove

Deodorants Light stain: Treat with liquid detergent or your regular laundry detergent. and anti- Wash in hottest water safe for fabric. perspirants Heavy stain: Place face down on towel and treat with a paste of ammo- nia and color safe bleach. Let stand for 30 minutes. Wash in hottest water safe for fabric. Fat, grease, Items soiled with vegetable or cooking oil should not be washed or dried. or oil See vegetable/cooking oil Warning on page 3. For other types of greasy stains, use one of the methods below: l Use pretreatment stain remover. Follow label directions. Wash in hottest water safe for fabric. l Use talcum powder to absorb as much grease as possible. Sponge with a nonflammable fabric cleaner. Rinse. Wash. l Treat with liquid detergent or rub a detergent paste on the stain. Wash using hottest water safe for fabric. Fruit stains Fresh stains: Soak immediately in cool water. Wash. If stain remains, cover area with a paste made of color safe bleach, a few drops of hot water, and a few drops of ammonia. Wait 15 to 30 minutes. Wash. Old stains: Sponge with white vinegar. Rinse. Repeat procedure for fresh stains. Grass or Soak in warm or cold water with an enzyme presoak for at least 30 green minutes, or sponge with denatured alcohol. Wash in water temperature vegetables and bleach safe for the fabric. For colored fabrics, check colorfastness before applying alcohol. For acetate, sponge with a nonflammable fabric cleaner. If stain remains, bleach with 3% hydrogen peroxide. Rinse. Rewash. Ink or ballpoint pen Ink Spray stain with an aerosol hair spray or rubbing alcohol. Sponge stain continuously until all bleeding stops. Let dry. Repeat if necessary. Wash. If stain remains, bleach if safe for fabric. (India and other indelible inks are almost impossible to remove completely.) Iron or rust Colored or noncolorfast items: Apply lemon juice and salt. Place in the sun to dry. Rinse thoroughly. Repeat if necessary. White or colorfast Items: Try a rust remover. Test first on inside seam or hem. Some rust removers are not washer safe. Follow package directions. Ketchup or Sponge immediately with a nonflammable fabric cleaner or apply a tomato prewash soil and stain remover. Rinse. Wash. If stain remains, apply a products liquid detergent to stain or soak in warm water with an enzyme presoak. Rewash. Lipstlck Apply nonflammable fabric cleaner or prewash soil and stain remover. Blot with absorbent material. Repeat if necessary. Rinse. If stain still remains, rub with liquid detergent. Wash. 22

Stain

Meat juice,

Wi

To Remove

Scrape off excess with a dull knife. Soak in cold or warm water with enzyme presoak at least 30 minutes, or treat stains with a nonflammable fabric cleaner. Wash. Mildew Wash in hottest water safe for fabric. If stain remains, soak in warm water and a color safe bleach for 15 to 30 minutes. Rewash. (Old mildew stains are almost impossible to remove. Mildew fungus destroys or weakens fabrics.) An alternative to bleach is to treat with salt and lemon juice and dry in direct sunlight. Rinse and rewash. Mildew may form if wet or damp laundry remains in your washer for extended periods of time. To prevent mildew, promptly dry laundry after washing. Mustard Treat immediately. Scrape off excess mustard. Sponge with a nonflam- mable fabric cleaner or a prewash soil and stain remover. Rinse. Work liquid detergent and a few drops of vinegar into stain. Rinse. If stain remains, apply 3% hydrogen peroxide. Rinse and wash. Paint Hand wash paint-stained items. Water base: Treat stains while still wet. (These paints cannot be removed after they have dried.) Rinse in warm water to flush out paint. Sponge with a nonflammable fabric cleaner. Rinse. Wash. Oil base: Scrape off fresh paint. Sponge with a nonflammable fabric cleaner or treat stain with recommended thinner. While stain is still wet with solvent, rub liquid detergent into it. Wash with hottest water safe for fabric. Perspiration Remove stains before ironing. Perspiration stains may weaken fabric. Wash or sponge stain thoroughly with detergent and warm water. If perspiration has changed the color of the fabric, use one of the following treatments: Fresh stains: Apply ammonia to stain. Rinse. Launder to remove ammonia odor. Old stains: Apply white vinegar to stain. Rinse. Launder to remove vinegar odor. Scorch Severe scorch cannot be removed. Wet stain with 3% hydrogen peroxide. Cover with a dry cloth and press with an iron as hot as is safe for fabric. Rinse well. Wash.

Or

Wet with lemon juice and spread in the sun to dry. Wash. Soft drinks Sponge immediately with cold water and alcohol. Heat and detergent may set stain. 23

Troubleshooting Most laundering problems are easily solved if you understand the cause. Check the following list for common laundry problems and the next page for common washer problems. If you need further assistance, see page 26. Common laundrv problems

Problem

Brown, yellow stains Dye transfer

-

Cause

l Chlorine staining l Iron in water heater or pipes; iron and manganese in water l Improper sorting l Load not immediately removed from washer after end of cycle Gray whites, dingy colors l Improper sorting l Water temperature too low l Not enough detergent l Using soap in very hard water (use detergent in hard water) Greasy looking spots Lint l Fabric softener poured directly on clothes l Not enough detergent, or dispenser not used l Improper sorting l Paper or tissue in pockets l Pilling being mistaken for lint l Not enough detergent Load too wet after spin Shrlnking l Cold rinses l Cycle stopped before spinning is complete l Fabric type (some knits stretch during manufacturing

laundering

returns fabric to original size) l Care label directions not followed Snags, rips, and holes l Items damaged before washing l Misuse of chlorine bleach (do not pour directly on clothes); dispenser not used l Sharp items not removed from pockets; fasteners not fastened Stiff, rough fabrics l Using soap in very hard water (use detergent in hard water) l Not enough detergent l Line drying Twisting/ Tangllng Wrlnkllng l Overloading l Clothes wrapped around agitator l Overloading (leave more room for permanent press and knits) l Load not immediately removed from washer after cycle l Warm rinse water l Cycle selection incorrect Yellow areas l Water temperature too low (from body oils) l Not enough detergent 24

Common washer problems Before calling for service, check these: Is the lid closed? Is the Cycle Control Knob set and pulled out? q Is the power cord firmly plugged into a live outlet with proper voltage? Have you blown a household fuse or tripped a circuit breaker? Are both the hot and cold water faucets turned on? Are the water hoses kinked or clogged? Is the drain hose lower than the water level in the washer? It must be higher. %

I

I$

s t h e washer making noises (see page 1 l), or vibrating? 111)) Is the wash load properly distributed around the agitator? NOTE: Washer stops briefly during a wash cycle. These pauses are normal. If none of these items was causing your problem, see “Requesting Assistance or Service” on page 26. 25

Reauestina Assistance or Service- -- - --~~~

-

Before calling for assistance or service, please check “Troubleshooting” on pages 24-25. It may save you the cost of a service call. If you still need help, follow the instructions below.

If you

need assistance* . . . Call the Whirlpool Consumer Assistance El Center telephone number. w Dial toll-free from anywhere in the U.S.A.:

If you

need

Fsp

1-800-253-l 301 and talk with one of our trained consultants. The consultant can instruct you in how to obtain satisfactory operation from your appliance or, if service is necessary, recommend a qualified service company in your area. replacement parts . . . FSP is a registered trademark of Whirlpool Corporation for quality parts. Look for this symbol of quality whenever you need a replacement part for your WHIRLPOOL@ appliance. FSP replacement parts will fit right and work right, because they are made to the same exacting specifications used to build every new WHIRLPOOL appliance. To locate FSP replacement parts in your area, refer to Step 2 or call the Whirlpool Consumer Assistance Center number in Step 1. If you prefer, write to: Mr. William Clark Consumer Assistance Representative Whirlpool Corporation

If you are not satisfied

2000 North M-63 with how the problem was solved . . . Benton Harbor, Ml 49022-2692 Please include a daytime phone number in your correspondence.

If you

need service* . . . Whirlpool has a nationwide network of El authorized Whirlpool service

Servke

companies. Whirlpool service technicians are trained to fulfill the product warranty and provide after-warranty service, anywhere in the United States. To locate the authorized Whirlpool service company in your area, call our Consumer Assistance Center telephone number (see Step 1) or look in your telephone directory Yellow Pages under: l Contact the Major Appliance Consumer Action Program (MACAP). MACAP is a group of independent consumer experts that voices consumer views at the highest levels of the major appliance industry. l Contact MACAP only when the dealer, authorized servicer, and Whirlpool have failed to resolve your problem. Major Appliance Consumer Action Program 20 North Wacker Drive Chicago, IL 60606 l MACAP will in turn inform us of your action. Gearcase assembly covered by your

*Appliance-Household

Major,

Service

(L Repair

See: Whirlpool

Appliances or Authorized Whirlpool Service (ExampIer XYZ Service Co.) l WASHING

Machines

Il

Dryers,

Service

A Repair

See- Whirlpool

Appliances or Atihorized Whirlpool Service (Example: XYZ Service Co.) l When asking for help or service: Please provide a detailed description of the problem, your appliance’s complete model and serial numbers, and the purchase date. (See page 2.) This information will help us respond properly to your request. 26

Whirlpool@

Automatic Washer Warranty

Length Of Warranty

Whirlpool

Will Pay For

Full One-Year

FSP replacement parts and repair labor to correct defects in

Warranty

materials or workmanship. Service must be provided by an From Date of Purchase authorized Whirlpool service company.

Limited Five-Year

FSP replacement parts for any part of gearcase assembly if

Warranty

defective in materials or workmanship. The gearcase assembly From Date of Purchase is shown in the “Requesting Assistance or Service” section of this book. FSP replacement parts for any top and lid rust.

Limited Ten-Year

FSP replacement of outer tub should it crack, or fail to contain

Warranty

water, due to defective materials or workmanship. From Date of Purchase

Whirlpool

Will Not Pay For

A. Service calls to:

Correct the installation of your washer.

Instruct you how to use your washer.

Replace house fuses or correct house wiring or plumbing.

B. Repairs when your washer is used in other than normal, single-family household use. C. Pickup and delivery. Your washer is designed to be repaired in the home. D. Damage to your washer caused by accident, misuse, fire, flood, acts of God, or use of products not approved by Whirlpool. E. Any labor costs during the limited warranties. F. Repairs to parts or systems caused by unauthorized modifications made to the appliance. e-94

Whirlpool

Corporation

Shall Not Be Liable For Incidental

Or Conse-

Quential

Damages.

Some states do not allow the exclusion or limitation of incidental or consequential damages, so this exclusion or limitation may not apply to you. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. Outside the United States, a different warranty may apply. For details, please contact your authorized Whirlpool distributor or military exchange. If you need service, first see the “Requesting Assistance or Service” section of this book. After checking “Requesting Assistance or Service,” additional help can be found by calling our Consumer Assistance Center telephone number, 1-800-253-1301, from anywhere in the U.S.A. PART NO. 3383584 D-Line 0 1995 Whirlpool Corporation G3 Registered TrademaMM Trademark of Whirlpool.

U.S.A

al95 Printed in U.S.A.
