What type of detergent must I use in the WFC7500VW?

You must use only HE (High Efficiency) detergent, which will be marked 'HE' or 'High Efficiency' on the package. Using regular non-HE detergent will create too much sudsing and will likely result in washer errors, longer cycle times, and reduced rinsing performance. It may also result in component failures and noticeable mold or mildew.

What does error code A10 mean?

Error code A10 indicates a Drain Problem. You should unplug the washer and check whether the drain hose is kinked, frozen, or clogged, and whether the drain hose is more than 55 inches (1.4 m) above the floor.

How do I run the Clean Washer cycle to maintain my washer?

Make sure the washer drum is empty, then add one AFFRESH washer cleaner tablet to the drum, or add 1/2 cup (120 mL) of liquid chlorine bleach to the bleach compartment in the dispenser drawer. Close the door and dispenser drawer, select the CLEAN WASHER cycle, and press START, allowing the cycle to complete without interruption. The manual recommends running this cycle once a month to keep the inside of the washer fresh and clean.

How do I unlock the washer door if it won't open?

Press and hold CANCEL/DRAIN for 3 seconds to manually unlock the door; it will take approximately 1 minute for the door to unlock. If water remains in the washer, select DRAIN/SPIN to remove it first, as the door will unlock at the end of the drain cycle. If an error code is displayed, switch the knob or press and hold START to exit the failure mode, then wait for the door to unlock.

How do I prepare my washer if I'm going on vacation or storing it in freezing weather?

If leaving for vacation, unplug the washer, turn off the water supply, and leave the door slightly open for ventilation. To winterize the washer in freezing weather, put 1 quart (1 L) of R.V.-type antifreeze in the drum, run a Drain/Spin cycle, unplug the washer, shut off both water faucets, and disconnect and drain the water inlet hoses.

What are the water pressure and temperature requirements for the washer?

The washer requires hot and cold water faucets located within 4 ft (1.2 m) of the fill valves, with water pressure of 20–100 psi (137.9–689.6 kPa). Your water heater should be set to deliver 120°F (49°C) water to the washer. The manual also notes that you should not operate the washer in temperatures below 32°F (0°C), as remaining water in the washer can cause damage in low temperatures.

What type of detergent must I use in the WFC7500VW washing machine?

You must use only HE (High Efficiency) detergent, which will be marked 'HE' or 'High Efficiency' on the package. Using regular non-HE detergent will create too much sudsing and will likely result in washer errors, longer cycle times, and reduced rinsing performance. It may also result in component failures and noticeable mold or mildew. (Page 12)

What does error code A10 mean on my washer?

Error code A10 indicates a Drain Problem. You should unplug the washer and check whether the drain hose is kinked, frozen, or clogged, and verify that the drain hose is not more than 55 inches (1.4 m) above the floor. (Page 21)

How do I run the Clean Washer cycle to maintain my machine?

To run the Clean Washer cycle, ensure the washer drum is empty and add either one AFFRESH washer cleaner tablet directly to the drum or 1/2 cup (120 mL) of liquid chlorine bleach to the bleach compartment — do not add detergent. Close the door and dispenser drawer, select the CLEAN WASHER cycle, and press START, allowing the full cycle to complete without interruption. This cycle should be run once a month to keep the inside of your washer fresh and clean. (Page 19)

How do I remove the shipping bolts before first use?

There are 4 bolts in the rear panel of the washer that must be removed before use. Using a 12 mm wrench, loosen each bolt, move it to the center of the hole, and completely pull it out along with the plastic spacer. Once all 4 bolts are removed, discard them and close the bolt holes with the 4 transport bolt hole plugs supplied. (Page 8)

How do I manually unlock the door if it won't open?

Press and hold CANCEL/DRAIN for 3 seconds to unlock the door manually. It will take approximately 1 minute for the door to unlock. Note that if the water level is too high, the washer will drain automatically before the door unlocks. (Page 14)

How do I prepare my washer for vacation or long periods of non-use?

If you will be away for an extended period, unplug the washer or disconnect power and turn off the water supply to the washer to help avoid flooding due to a water pressure surge. You should also leave the door slightly open to provide ventilation. (Page 20)

How often should I replace the water inlet hoses?

Replace the water inlet hoses after 5 years of use to reduce the risk of hose failure. You should also periodically inspect and replace hoses if bulges, kinks, cuts, wear, or leaks are found. It is recommended that you record the hose installation or replacement dates on the hoses for future reference. (Page 9)

What should I do if the washer is noisy, vibrating, or walking across the floor?

First, check that the washer is level and that all four feet are properly installed with the nuts tightened against the washer cabinet and in firm contact with the floor. Also verify that the 4 shipping bolts in the back of the machine have been removed, as leaving them in can cause excessive vibration. If noise persists, placing a piece of 3/4 inch (19.1 mm) plywood underneath the washer may help reduce noise and vibration. (Page 21)

What are the electrical requirements for installing the WFC7500VW?

The washer requires a 120 volt, 60 Hz, AC only, 15 or 20 amp fused electrical supply, and a time-delay fuse or circuit breaker is recommended. It must be plugged into a grounded 3-prong outlet located within 5.4 ft (1.65 m) of where the power cord attaches to the back of the washer. You must not use an extension cord or an adapter, and the grounding prong must never be removed. (Page 7)

How often should I replace the inlet water hoses?

Replace inlet hoses after 5 years of use to reduce the risk of hose failure. Periodically inspect hoses for bulges, kinks, cuts, wear, or leaks throughout their lifespan. Record the installation or replacement date on the hoses for future reference.

What type of detergent should I use in this washing machine?

Use only High Efficiency (HE) detergents marked with 'HE' or 'High Efficiency' on the package. Regular non-HE detergent will create too much sudsing and can result in washer errors, longer cycle times, reduced rinsing, and potential component failures. HE detergents are formulated to produce the right amount of suds for optimal performance.

How do I properly level the washing machine after installation?

Place a level on the top edge of the washer side-to-side and front-to-back. If not level, prop the front with a wood block and adjust the feet, then prop the back and adjust feet as needed. After leveling, use a 13 mm wrench to tighten the nuts on all four feet firmly against the washer cabinet. The washer should not move when pushed on its top edges.

What does error code 'A09' mean and how do I fix it?

Error code 'A09' indicates a Water Inlet Problem with no water or insufficient water supply. Check that both water faucets are completely turned on, inlet hose screens are not clogged, hoses are not kinked or frozen, and verify water pressure is adequate. If the problem persists after these checks, unplug the washer and call for service.

How do I use the dispenser drawer to add laundry products?

Pull out the dispenser drawer and add liquid or powdered HE detergent to the main wash compartment, liquid chlorine bleach (no more than ½ cup) to the bleach compartment, and liquid fabric softener (no more than ½ cup) to the fabric softener compartment. Push the drawer in slowly to avoid spills. Products are automatically diluted and dispensed at optimal times during the cycle.

What should I do if my washer door won't unlock after the cycle?

First, check that all water has drained from the washer by selecting the DRAIN/SPIN cycle. If an error code is displayed, switch the knob or press and hold START to exit the error mode. If the water temperature is hotter than 104°F (40°C), wait for it to cool. The door will automatically unlock once these conditions are met; it takes approximately 1 minute to unlock.

What is the Clean Washer cycle and when should I use it?

The Clean Washer cycle is designed to keep the inside of the washer fresh and clean and should be used once a month. Use it with either one AFFRESH™ washer cleaner tablet or ½ cup of liquid chlorine bleach with an empty drum. Do not add any detergent or clothes during this cycle, and allow it to complete without interruption.

Why is my washing machine making unusual noises?

New washers produce various sounds that are normal during operation, including sounds when the door locks/unlocks and during washing, rinsing, or spinning. You may also hear water spraying and momentary pauses between wash actions. Metal items like zippers or buckles may touch the drum. If the washer is properly leveled and all four shipping bolts were removed, these sounds are part of normal operation.

What should I do before using the washer for the first time?

Before washing clothes for the first time, run the Normal cycle without any clothes to ensure the interior is clean. Use only HE detergent and add ½ the manufacturer's recommended amount for a medium-size load. This initial cleaning cycle prepares the washer for use.

How do I winterize my washing machine if I'm storing it during freezing weather?

Put 1 quart of R.V.-type antifreeze in the drum and run the Drain/Spin cycle. Then unplug the washer, shut off both water faucets, and disconnect the water inlet hoses from the faucets and drain them. To use it again, flush water pipes, reconnect the hoses, turn on faucets, plug in the washer, and run a Normal cycle with ½ the recommended amount of HE detergent to remove the antifreeze.

Whirlpool 7500VW Washing Machine — Manual, FAQ & Troubleshooting

Name: Whirlpool 7500VW Washing Machine
Brand: Whirlpool

Page 1

Front-Loading

Automatic Washer

Use & Care Guide For questions about features, operation/performance, parts, accessories or service call: 1-800-253-1301 In Canada, call: 1-800-807-6777 or visit our website at www.whirlpool.com or www.whirlpool.ca

Laveuse

Automatique À

Chargement Frontal

Guide d’utilisation et d’entretien Au Canada, pour assistance, installation ou service, composez le : 1-800-807-6777 ou visitez notre site Internet à www.whirlpool.ca Table of Contents/Table des matières .................. 2

W10175588A

® Designed to use only HE High Efficiency Detergent Conçue pour l’utilisation d’un détergent haute efficacité (HE) seulement Para obtener acceso al Manual de uso y cuidado en español, o para obtener información adicional acerca de su producto, visite: www.whirlpool.com. Tenga listo su número de modelo completo. Podrá encontrar el número de modelo y de serie en la etiqueta ubicada debajo de la tapa de la lavadora.

Page 2

2

Installation Requirements................................................4

Tools and Parts ............................................................................4 Options.........................................................................................4 Location Requirements................................................................4 Drain System................................................................................6 Electrical Requirements ...............................................................7

Installation Instructions..................................................8

Remove Transport System ..........................................................8 Connect the Inlet Hoses...............................................................8 Route the Drain Hose...................................................................9 Secure the Drain Hose.................................................................9 Level the Washer........................................................................10 Complete Installation .................................................................10 FEATURES AND BENEFITS ........................................................11 WASHER USE...............................................................................12 Starting Your Washer.................................................................12 Using the Proper Detergent .......................................................12 Using the Dispenser...................................................................13 Restarting...................................................................................14 Changing Cycles and Options...................................................14 Status Lights ..............................................................................14 Cycles.........................................................................................14 Normal Sounds ..........................................................................15 Options and Modifiers................................................................15 Laundry Guide............................................................................16 LAUNDRY TIPS ............................................................................17 Loading.......................................................................................17 Stain Removal Guide .................................................................18 WASHER CARE ............................................................................19 Cleaning Your Washer ...............................................................19 Water Inlet Hoses.......................................................................20 Vacation, Storage, and Moving Care.........................................20 TROUBLESHOOTING ..................................................................21 Washer and Components..........................................................21 Washer Operation ......................................................................22 Clothes Care...............................................................................23 ASSISTANCE OR SERVICE.........................................................25 In the U.S.A. ...............................................................................25 In Canada...................................................................................25 Accessories................................................................................25 WARRANTY ..................................................................................26

Table Des Matières

SÉCURITÉ DE LA LAVEUSE........................................................27

Exigences D'Installation...................................................28

Outillage et pièces......................................................................28 Options .......................................................................................28 Exigences d'emplacement.........................................................29 Système de vidange...................................................................30 Spécifications électriques ..........................................................31

Instructions D'Installation.............................................32

Élimination des accessoires de transport..................................32 Raccordement des tuyaux d'alimentation.................................32 Acheminement du tuyau de vidange .........................................33 Immobilisation du tuyau de vidange..........................................34 Réglage de l'aplomb de la laveuse............................................34 Achever l'installation ..................................................................34

Caractéristiques Et Avantages .....................................35

Utilisation De La Laveuse...................................................36

Mise en marche de la laveuse....................................................36 Utilisation du détergent approprié .............................................36 Utilisation du distributeur ...........................................................37 Remise en marche......................................................................38 Modification des programmes et options..................................38 Témoins lumineux ......................................................................38 Programmes...............................................................................38 Sons normaux ............................................................................39 Options et modificateurs............................................................40 Guide de lessivage.....................................................................41 CONSEILS DE LESSIVAGE..........................................................42 Chargement ...............................................................................42 Guide pour l'élimination des taches...........................................43

Entretien De La Laveuse .....................................................44

Nettoyage de la laveuse.............................................................44 Tuyaux d'arrivée d'eau...............................................................45 Précautions à prendre avant les vacances, un entreposage ou un déménagement......................................45 DÉPANNAGE.................................................................................46 La laveuse et ses composants...................................................46 Fonctionnement de la laveuse ...................................................47 Soin des vêtements....................................................................49 ASSISTANCE OU SERVICE.........................................................50 Aux États-Unis............................................................................50 Au Canada..................................................................................50 Accessoires ................................................................................50 GARANTIE.....................................................................................51

Page 3

3

Washer Safety

You can be killed or seriously injured if you don't immediately

You can be killed or seriously injured if you don't follow All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can happen if the instructions are not followed. Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or hurt you and others. All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.” These words mean: follow instructions. instructions.

Danger

Warning

Important Safety Instructions

Save These Instructions

■ Read all instructions before using the washer. ■ Do not wash articles that have been previously cleaned in, washed in, soaked in, or spotted with gasoline, dry-cleaning solvents, other flammable, or explosive substances as they give off vapors that could ignite or explode. ■ Do not add gasoline, dry-cleaning solvents, or other flammable, or explosive substances to the wash water. These substances give off vapors that could ignite or explode. ■ Under certain conditions, hydrogen gas may be produced in a hot water system that has not been used for 2 weeks or more. HYDROGEN GAS IS EXPLOSIVE. If the hot water system has not been used for such a period, before using the washing machine, turn on all hot water faucets and let the water flow from each for several minutes. This will release any accumulated hydrogen gas. As the gas is flammable, do not smoke or use an open flame during this time. ■ Do not allow children to play on or in the washer. Close supervision of children is necessary when the washer is used near children. ■ Before the washer is removed from service or discarded, remove the door or lid.

■ Do not reach into the washer if the drum, tub or agitator is moving. ■ Do not install or store the washer where it will be exposed to the weather. ■ Do not tamper with controls. ■ Do not repair or replace any part of the washer or attempt any servicing unless specifically recommended in this manual or in published user-repair instructions that you understand and have the skills to carry out. ■ See “Electrical Requirements” for grounding instructions. WARNING: To reduce the risk of fire, electric shock, or injury to persons when using the washer, follow basic precautions, including the following:

Page 4

4

Installation Requirements

Tools and Parts Gather the required tools and parts before starting installation. The parts supplied are in the washer drum. Tools needed for connecting the water inlet hoses ■ Pliers (that open to 1⁹⁄₁₆" [39.5 mm]) ■ Flashlight (optional) Tools needed for installation ■ Open end wrenches 13 mm and 12 mm ■ Level ■ Wood block ■ Ruler or measuring tape Parts supplied Alternate Parts Your installation may require additional parts. If you are interested in purchasing one of the items listed here, call the toll-free number on the cover or in the “Assistance or Service” section. Options Pedestal You have the option of purchasing a pedestal for this washer. You may select an 11.8" (30.0 cm) pedestal. The pedestal will add to the total height of the washer. Optional pedestal Stack Kit Are you planning to stack your washer and dryer? To do so you will need to purchase a Stack Kit. To order, call the dealer from whom you purchased your washer or refer to the “Assistance or Service” section. Ask for Part Number W10178021. Location Requirements Selecting the proper location for your washer improves performance and minimizes noise and possible washer “walk.” Your washer can be installed under a custom counter, or in a basement, laundry room, closet, or recessed area. See “Drain System.” Companion appliance location requirements should also be considered. Proper installation is your responsibility. You will need ■ A water heater set to deliver 120°F (49°C) water to the washer. ■ A grounded electrical outlet located within 5.4 ft (1.65 m) of where the power cord is attached to the back of the washer. See “Electrical Requirements.” ■ Hot and cold water faucets located within 4 ft (1.2 m) of the hot and cold water fill valves, and water pressure of 20-100 psi (137.9-689.6 kPa). ■ A level floor with a maximum slope of 1" (2.5 cm) under entire washer. Installing the washer on soft floor surfaces, such as carpets or surfaces with foam backing, is not recommended. ■ A sturdy and solid floor to support the washer with a total weight (water and load) of 400 lbs (180 kg). Do not operate your washer in temperatures below 32°F (0°C). Some water can remain in the washer and can cause damage in low temperatures. A. U-shaped hose form B. Water inlet hoses (2) C. Inlet hose washers (4) D. Beaded tie strap If You Have You Will Need to Buy Laundry tub or standpipe taller than 55" (1.4 m) Sump pump system (if not already available) Overhead sewer Standard 20 gal. (76 L), 30" (76.2 cm) tall drain tub or utility sink and sump pump (available from local plumbing suppliers) Floor drain Siphon break, Part Number 285834; additional drain hose Part Number 8318155; and connector kit, Part Number 285835 Drain hose too short 4 ft (1.2 m) drain hose extension kit, Part Number 285863 Water faucets beyond reach of fill hoses 2 longer water fill hoses: 6 ft (1.8 m) Part Number 76314 10 ft (3.0 m) Part Number 350008

A

B

C

D

Pedestal Height Approximate Height with Washer Color Model Number 11.8" (30.0 cm) 44.7" (113.5 cm) White

Lab0050Pq

Page 5

Page 6

Page 7

Page 8

Page 9

Page 10

Page 11

11

Features And Benefits

Your new front-loading high efficiency washer, was designed to conserve resources and lower your water and energy bills. The washer is designed to determine and then provide the amount of water needed for the best performance. The time of operation may be greater for this new system than for a conventional washer. Electronic Controls Flexible electronic controls are easy to use whether you are a beginner or an expert. Auto Water Level Adjusting to the size of the load, this feature allows the washer to use the minimal amount of water needed to clean and rinse the clothes. With a low water level, you can obtain the same results with smaller amounts of laundry products. Because only the required amount of water is used, the washer saves energy, too. Suspension System To reduce washer “walk” and “off-balance” conditions, your new washer combines: ■ 2 Springs to isolate vibration ■ 2 Shock absorbers at the washer base to minimize movement Stainless Steel Drum The stainless steel drum eliminates corrosion and enables higher spin speeds for more water extraction, reducing drying time. Adaptive Variable Speed Motor The motor adapts to the load size and to the cycle selected to give the optimum cleaning, rinsing, and spinning conditions. The motor can handle slow speeds needed for delicate items and is powerful enough to drive an average clothes load up to high- speed spin. Spin Speeds This washer automatically selects the spin speed based on the cycle selected. Dynamic Balance A precision balancing system allows the washer to reach high- speed spins. The washer spins faster so that clothes coming out of the washer will have less moisture than with traditional top load machines. In addition, if the Dynamic Balance system detects off-balance loads during spinning, it redistributes the clothes so that they are evenly balanced. Smart Dispensers The three compartments in the dispenser allow loading of all laundry products before the washer is started. The products will be dispensed into the wash at the optimal time for high- performance cleaning. The bleach release system is included in the detergent advantage system. The detergent is added at the beginning of the cycle, and the bleach is added after the enzymes have had a chance to do their cleaning. The fabric softener is dispensed in the rinse cycle or in the EXTRA RINSE, if selected. The Detergent Advantage System Dispenser tray is easily removed for cleaning. Use only HE High Efficiency detergent.

Page 12

12

Washer Use

Starting Your Washer WARNING: To reduce the risk of fire, electric shock, or injury to persons, read the IMPORTANT SAFETY INSTRUCTIONS before operating this appliance. The following is a guide to using your washer. Please refer to specific sections of this manual for more detailed information. Do not store laundry products on the top surface of this washer. Vibration is normal during operation. Using the Proper Detergent Use only High Efficiency detergents. The package for this type of detergent will be marked “HE” or “High Efficiency.” This wash system, along with less water, will create too much sudsing with a regular non-HE detergent. Using regular detergent will likely result in washer errors, longer cycle times, and reduced rinsing performance. It may also result in component failures and noticeable mold or mildew. HE detergents are made to produce the right amount of suds for the best performance. Follow the manufacturer's instructions to determine the amount of detergent to use. First Wash Cycle Without Laundry Before washing clothes for the first time, if not completed during the final installation step, choose the Normal cycle and run it without clothes. Use only HE High Efficiency detergent. Use ¹⁄₂ the manufacturer’s recommended amount for a medium-size load. This initial cycle serves to ensure the interior is clean before washing clothes. For All Wash Cycles

To load washer

Open the washer door by pulling on the handle. Sort laundry according to color and type of fabric. Place a load of sorted clothes in the washer. Do not overload washer. Overloading can cause poor cleaning. ■ The washer can be fully loaded, but not tightly packed. Washer door should close easily. ■ Mix large and small items. Avoid washing a single item. Load evenly. ■ Wash small items such as infant socks in mesh garment bags. It is recommended that more than one garment bag be used and that each garment bag be filled with equal amounts of material. ■ When unloading garments, occasionally check under the seal/bellow at the front of the tub for small items.

Close the washer door by pushing it firmly until the lock

clicks. The washer door will remain locked during the wash cycle. NOTE: There is a routine at the beginning of each cycle to avoid unintended use of the washer. This routine will take approximately 1 minute to complete before the selected wash cycle begins.

Open the dispenser drawer and add laundry products to the

detergent, bleach, or fabric softener compartments. Close drawer slowly to avoid spills. See “Using the Dispenser.”

Turn on the washer by turning the cycle selector and

selecting one of the cycles. The indicator light for the selected cycle will illuminate. When selecting a Wash Cycle, the preset Modifiers, Options and Water Temp for the selected cycle will illuminate. The preset settings provide the recommended fabric care for the selected cycle. See “Cycles.”

Select the desired OPTIONS. Not all Options are available

with all cycles. See “Options.” Use only HE High Efficiency detergent. Fire Hazard Never place items in the washer that are dampened with gasoline or other flammable fluids. No washer can completely remove oil. Do not dry anything that has ever had any type of oil on it (including cooking oils). Doing so can result in death, explosion, or fire.

Warning

Page 13

13

To begin the wash cycle immediately

Select and hold START (for approximately 3 seconds). ■ If you do not select START within 5 minutes of choosing a cycle, the washer display automatically shuts off. ■ When the wash cycle is complete, the CYCLE COMPLETE status light illuminates, the door unlocks and the wash load can be removed from the washer. The washer goes into standby mode automatically after the door is opened or 1 hour after the cycle is complete and all displays will go off. ■ To power down the washer manually after the wash cycle is complete, switch knob to Off position.

To begin the wash cycle later

Select DELAY WASH until the desired delay time (in hours) is displayed. Select START. The countdown to the wash cycle will show in the display window. IMPORTANT: When delaying a cycle, use only powdered detergents in the main wash compartment since liquid detergents may seep out of the compartment during Delay before the wash cycle begins. Using the Dispenser Your new washer has a dispenser drawer with three separate compartments for your laundry products—one is for detergent, one is for liquid chlorine bleach, and one is for liquid fabric softener. Laundry products are diluted and dispensed automatically at the proper time during the wash cycle, making it unnecessary for you to return to the washer during the cycle to add them. It is normal for small amounts of water to remain in the dispensers when the wash cycle is complete. Do not put laundry products directly into the wash tub. Always use the proper dispensers when adding laundry products. Choosing the Right Detergent Use only High Efficiency detergents. The package for this type of detergent will be marked “HE” or “High Efficiency.” This wash system, along with less water, will create too much sudsing with a regular non-HE detergent. Using regular detergent will likely result in washer errors, longer cycle times, and reduced rinsing performance. It may also result in component failures and noticeable mold or mildew. HE detergents are made to produce the right amount of suds for the best performance. Follow the manufacturer's instructions to determine the amount of detergent to use. To fill dispenser compartments

Pull out the dispenser drawer.

Add the desired laundry products to the proper compartment.

Push in the dispenser drawer slowly and completely (to avoid

a spill). Main Wash detergent compartment (Letter B in Dispenser Illustration) Add liquid or powdered HE detergent to this compartment for your main wash cycle. ■ Powdered color-safe bleach may be added to the Main Wash compartment along with the powdered detergent. ■ Follow the manufacturer’s instructions to determine the amount of detergent to use. NOTE: Overfilling could cause an oversudsing condition. Chlorine bleach compartment (Letter C in Dispenser Illustration) Add NO MORE THAN ¹⁄₂ cup (120 mL) liquid chlorine bleach to this compartment during normal use. The bleach will be automatically diluted and dispensed at the best time during the first rinse after the wash cycle. This compartment cannot dilute powdered bleach. ■ Use only liquid chlorine bleach in this dispenser. Do not use this dispenser to add powdered chlorine or any form of color- safe bleach to your load. ■ Always measure liquid chlorine bleach. Use a measuring cup with a pour spout; do not guess. Follow the manufacturer’s directions for proper use. ■ Do not fill beyond the “MAX” level during normal use. NOTE: Overfilling could cause garment damage. Fabric softener compartment (Letter D in Dispenser Illustration) Add NO MORE THAN ¹⁄₂ cup (120 mL) liquid fabric softener to this compartment. Fabric softener will be automatically dispensed in the final rinse or in the EXTRA RINSE, if selected. ■ Do not fill beyond the “MAX” level. Use only HE High Efficiency detergent. Dispenser A. Dispenser release lever B. Main Wash detergent compartment C. Liquid chlorine bleach compartment D. Fabric softener compartment

A

B

C

D

Page 14

Page 15

15 Normal Use this cycle to wash loads of normally soiled cottons and linens. This cycle has high-speed spin. Quick Wash Use this cycle to wash small loads of 2-3 lightly soiled garments that are needed in a hurry. This cycle combines a shortened wash time and high-speed spin to shorten drying time. Large wash loads will result in the machine increasing the wash time. Delicate Use this cycle to wash sheer fabrics and lingerie. This cycle has low-speed spin for gentle fabric care. ■ Use mesh garment bags to wash undergarments such as underwire bras, items with strings, and small items such as socks. Clean Washer Use the Clean Washer cycle once a month to keep the inside of your washer fresh and clean. This cycle uses a higher water level. Use with AFFRESH™ washer cleaner tablet or liquid chlorine bleach to thoroughly clean the inside of your washing machine. This cycle should not be interrupted. See “Cleaning Your Washer.” IMPORTANT: Do not place garments or other items in the washer during the Clean Washer cycle. Use this cycle with an empty wash drum. Drain/Spin Use this cycle to drain your washer or to drain and spin your wash load. The spin speed is preset to HIGH. Rinse/Spin Use this cycle to get a rinse and spin only. This cycle has high- speed spin. Rinse & Spin is useful for: ■ Loads that need rinsing only. ■ Adding fabric softener to a load using the fabric softener dispenser. Heavy Duty Use this cycle to wash loads of sturdy, colorfast fabrics and Heavy soiled garments. This cycle combines a longer wash time and high-speed spin to shorten drying times. Casual Use this cycle to wash loads of permanent press blends and synthetic fabrics. This cycle has a load cooling process to reduce wrinkling. Normal Sounds As with any new product, you will hear sounds that you are not accustomed to. You may hear various sounds when the door is locked or unlocked, and during the washing, rinsing, or spinning process. Between changes in wash actions, there will be momentary pauses. You will hear water spraying and splashing during the wash and rinse cycles. These new sounds and pauses are part of normal washer operation. See “Troubleshooting.” Options and Modifiers You can customize your wash by adding options to your cycle selections. Not all Options are available with all cycles. ■ See the “Laundry Guide” section for an overview of possible options for each Wash Cycle selection. ■ If an option is available with a selected cycle, the light for that option will illuminate when selected. ■ If an option is unavailable with a selected cycle, there will be a blinking light. The light for that option will not illuminate when selected. Delay Wash Use this to begin the wash cycle later. ■ Select DELAY WASH until the desired time (in hours) shows in the Estimated Time Remaining display. ■ Select START. The countdown to the wash cycle will show in the display window. Prewash Prewash is an 18-minute soak phase that is added before the main wash. During prewash, there is only a small amount of tumbling. Extra Rinse An extra rinse can be used to aid in the removal of detergent or bleach residue from garments. This option provides an additional rinse with the same water temperature as in the normal rinse. You may select or deselect by pressing EXTRA RINSE. Wrinkle Release Use this option to increase the quantity of incoming water and decrease the spin speed and duration in the rinse period. The last spin phase will have a lower spin speed and last a shorter time.

Page 16

Page 17

17

Laundry Tips

Preparing clothes for washing Follow these recommendations to help you prolong the life of your garments. ■ Use only High Efficiency detergents. The package for this type of detergent will be marked “HE” or “High Efficiency.” This wash system, along with less water, will create too much sudsing with a regular non-HE detergent. Using regular detergent will likely result in washer errors, longer cycle times and reduced rinsing performance. It may also result in component failures and noticeable mold or mildew. HE detergents are made to produce the right amount of suds for the best performance. Follow the manufacturer's instructions to determine the amount of detergent to use. ■ Close zippers, snaps, and hooks to avoid snagging other items. Remove pins, buckles, and other hard objects to avoid scratching the washer interior. Remove non-washable trim and ornaments. ■ Empty pockets and turn them inside out. ■ Turn down cuffs; brush away lint and dirt. ■ Turn wool and synthetic knits inside out to avoid pilling. ■ Tie strings and sashes so they will not tangle. ■ Mend tears, loose hems, and seams. ■ Treat spots and stains. ■ Stained or wet garments should be washed promptly for best results. ■ Mix large and small items, avoid washing single items, and load evenly. ■ Wash small items, such as infant socks, in a mesh garment bag. To create a balanced load it is recommended that more than one garment bag be used, and that each garment bag be filled with equal amounts of material. NOTE: If you are washing only small items, it is recommended that more than one mesh garment bag be used, and that each garment bag be filled with equal amounts of material. Sorting ■ Separate heavily soiled items from lightly soiled ones, even if they would normally be washed together. Separate lint-givers (towels, chenille) from lint-takers (corduroy, synthetics, permanent press). When possible, turn lint-givers inside out. ■ Separate dark colors from light colors, colorfast items from noncolorfast items. ■ Sort by fabric and construction (sturdy cottons, knits, delicate items). Unloading ■ Remove clothes from washer after the cycle is completed. Metal objects such as zippers, snaps, and buckles may rust if left in the washer basket for a long time. ■ When unloading garments, occasionally check under the gray colored seal at the front of the tub for small items. Loading Use only HE High Efficiency detergent. Loading suggestions (maximum size loads) Heavy Work Clothes 3 jeans 2 work pants 3 work shirts Towels 8 bath towels 8 hand towels 10 washcloths Permanent Press 1 double sheet 1 dress 1 blouse 2 slacks 3 shirts 6 handkerchiefs Mixed Load 1 double sheet or twin 4 pillowcases 2 shirts 2 blouses 6 T-shirts 6 shorts 6 handkerchiefs Knits 1 pant 2 blouses 4 shirts 4 tops 2 dresses Delicates 1 camisoles 4 slips 6 undergarments 1 set of sleepwear QUICK WASH cycle (2-3 garments) 2 dress shirts 1 pair dress pants

Page 18

Page 19

Page 20

Page 21

21

Troubleshooting

First try the solutions suggested here to possibly avoid the cost of a service call... Washer and Components Error codes An error code may be shown in the Estimated Time Remaining display. Check the list below for potential problem and troubleshooting checks. ■ “A09” on display (Water Inlet Problem—no water or insufficient water supply) If this error occurs, the system will pause. Unplug washer or disconnect power. Check the following: Are water faucets completely turned on? Are screens at inlet hose connection to washer clogged? Are water inlet hoses kinked? Are water inlet hoses frozen? Plug in washer or reconnect power. Press and hold START to continue the cycle or press and hold CANCEL/DRAIN to cancel the cycle. If the problem remains, call for service. ■ “A10” on display (Drain Problem) Unplug washer or disconnect power. Check the following: Is the drain hose kinked? Is the drain hose frozen? Is the drain hose clogged? Is the drain hose more than 55" (1.4 m) above the floor? ■ “F” Variables [F01 - F30] (Electrical Problem) Switch knob or press and hold START to cancel the cycle. Select DRAIN/SPIN if there is excessive water in the washer. Re-select cycle and press START. If the problem remains, call for service. Noisy, vibrating, off-balance ■ Is the washer level? The washer must be level. The four feet should be properly installed, and the nuts should be tightened against the washer cabinet. All four feet of the washer must be in firm contact with the floor. If the washer is on a pedestal, the washer must be secured to the pedestal and all four pedestal feet must be in firm contact with the floor. ■ Washer making a different noise? As with any new product, you will hear sounds that you are not accustomed to. You may hear various sounds when the door is locked or unlocked, and during the washing, rinsing, or spinning process. Between changes in wash actions, there will be momentary pauses. You will hear water spraying and splashing during the wash and rinse cycles. These new sounds and pauses are part of normal washer operation. ■ Is washer installed on a sturdy and solid floor? Refer to the “Installation Instructions” for flooring requirements. Noise and vibration may be reduced by placing a piece of ¾" (19.1 mm) plywood underneath your washer. The plywood may extend underneath both washer and dryer to keep them at equal heights. ■ Is the washer gurgling or humming? As water is drained from the washer, you may hear air being pulled through the pump. This happens during the end of draining. It is normal. ■ Are you washing items with metal snaps, buckles or zippers? You may hear metal items touching the washer drum. This is normal. ■ Were the 4 shipping bolts in the back of the machine removed? See “Remove Transport System.” Leaking ■ Is HE detergent being used? The non-High Efficiency detergents can cause oversudsing, which can leak from the rear of the washer. ■ Are the fill hoses tight? ■ Are the fill hose gaskets properly seated? Check both ends of each hose. See “Connect the Inlet Hoses.” ■ Is the drain hose properly installed? The drain hose should be secured to the drainpipe or laundry tub. See “Secure the Drain Hose.” ■ Is the sink or drain clogged? Sink and drainpipe must be able to carry away 17 gal. (64 L) of water per minute. If the sink or drain is clogged or slow, water can back up out of drainpipe or sink. Check household plumbing (laundry tubs, faucets, drainpipe, water pipes) for leaks. Electrical Shock Hazard Plug into a grounded 3 prong outlet. Do not remove ground prong. Do not use an adapter. Do not use an extension cord. Failure to follow these instructions can result in death, fire, or electrical shock.

Warning

Page 22

22 Dispenser operation ■ Did you follow the manufacturer’s directions when adding detergent and fabric softener to the dispensers? Measure detergent and fabric softener. Slowly pour into the dispensers. Wipe up all spills. Dilute fabric softener in the fabric softener dispenser. ■ Did you put powdered or liquid color-safe bleach into the liquid chlorine bleach dispenser (on some models)? Add powdered or liquid color-safe bleach to the Main Wash detergent compartment. Do not use the chlorine bleach dispenser for color-safe bleach. ■ Is the fabric softener dispenser clogged? Clean the fabric softener dispenser. See “Washer Care” for details. ■ Are the laundry products in the correct dispenser compartment? Add the correct amounts of detergent, fabric softener or liquid chlorine bleach to the correct compartments. Add powdered or liquid color-safe bleach to the Main Wash compartment. ■ Is there water in the dispenser at the end of the cycle? A small amount of water will remain in the dispenser compartment. This is normal. Washer odor ■ See “Cleaning Your Washer.” ■ Are you using AFFRESH™ washer cleaner on a regular basis? AFFRESH™ washer cleaner removes and avoids odor- causing residue in all High Efficiency washers. For washers where odor is present, use 3 tablets instead of 1 tablet. After the CLEAN WASHER cycle is complete, wipe away residue if necessary. ■ Are you using HE detergent? Use of non-HE detergent can cause a film residue which can result in odor. ■ Did you leave the door open after use? This washer has a tight seal to avoid water leaks. To avoid odors leave the door open to allow the washer to dry between uses. Door won't unlock ■ Did all of the water drain out of the washer during the spin? Select DRAIN/SPIN to remove any water remaining in the washer. The washer door will unlock at the end of the drain. It will take 1 minute for the door to unlock. ■ Is the error code displayed? Failure mode will lock the door. Switch knob or press and hold START to exit, then wait for the door to unlock. ■ Is the water temperature hotter than 104°F (40°C)? Wait for the water temperature to drop. Washer Operation Washer won't run, fill, rinse or tumble; washer stops ■ Is the power cord plugged into a grounded 3 prong outlet? Plug power cord into a grounded 3 prong outlet. ■ Are you using an extension cord? Do not use an extension cord. ■ Has a household fuse blown, or has a circuit breaker tripped? Replace the fuse, or reset the circuit breaker. If the problem continues, call an electrician. ■ Are both the hot and cold water faucets turned on? Turn on the water. ■ Is the water inlet hose kinked? Straighten the hoses. ■ Are the water inlet valve screens clogged? Turn off the water and remove inlet hoses from the washer. Remove any accumulated film or particles. Reinstall hoses, turn on water and check for leaks. ■ Is the washer in a normal pause in the cycle? The washer pauses for about 2 minutes during certain cycles. Allow the cycle to continue. Some cycles feature periods of tumbling and soak. ■ Is the washer overloaded? Wash smaller loads. ■ Is the washer door firmly shut? The door must be closed during operation. ■ Are the shipping bolts removed? All four shipping bolts must be removed for proper operation of the washer. ■ Has a cycle been selected, but START has not been selected and held for 3 seconds? Press and hold START, for 3 seconds. Electrical Shock Hazard Plug into a grounded 3 prong outlet. Do not remove ground prong. Do not use an adapter. Do not use an extension cord. Failure to follow these instructions can result in death, fire, or electrical shock.

Warning

Page 23

23 Washer continues to fill or drain, drain cycle seems stuck ■ Is the top of drain hose lower than 30" (76 cm) on washer? The top of the drain hose must be at least 30" (76 cm) above the floor. See “Drain System.” ■ Does the drain hose fit too tightly in the standpipe, or is it taped to the standpipe? The drain hose should be loose yet fit securely. Do not seal the drain hose with tape. The hose needs an air gap. See “Secure the Drain Hose.” Washer won’t drain or spin, water remains in washer ■ Is the drain hose clogged, or the end of the drain hose more than 55" (1.4 m) above the floor? ■ Is your voltage low? Check electrical source or call electrician. ■ Excessive suds? When excessive suds are detected, a special oversuds routine automatically starts. Cycle will complete once extra suds are removed. This will occur more frequently when a non-HE detergent is used. ■ Is the load balanced? A single or bulky item may cause imbalance. Add more items or redistribute the load. Not enough water/Not enough suds ■ Low water? This washer uses very little water to provide good cleaning results. You will see little or no water splashing in this washer. This is normal. ■ Are you using HE detergent? HE detergent is a low sudsing detergent. This is normal and will not affect cleaning performance. Wash/Rinse temperature ■ Are the hot and cold water inlet hoses reversed? See “Connect the Inlet Hoses.” ■ Are you washing many loads? As your frequency of loads washed increases, the water temperature may decrease for hot and warm temperatures. This is normal. Cycle time changes/Cycle too long ■ Estimated cycle time? The cycle times vary automatically based on your water pressure, water temperature, detergent, and clothes load. The cycle time will be extended if oversudsing occurs or the load is unbalanced. The oversuds routine removes extra suds and assures proper rinsing of your garments. The options you select will also affect the cycle times that are shown in the Preset Cycle Settings table. ■ Excessive suds? When excessive suds are detected, a special oversuds routine automatically starts. This routine will add time to the original cycle. ■ Did the load cause imbalance? When too much imbalance occurs, an imbalance routine will start to redistribute the load. During the imbalance routine the time displayed may pause until this activity is complete, then resume with the remainder of the cycle. ■ Are you washing a single item or bulky load? Spin time is added if an unbalanced load is detected. The washer will attempt to redistribute the load with additional tumbling. ■ Did you wash a large load on the Quick Wash cycle? The Quick Wash cycle is designed for smaller load sizes (2-3 items) of lightly soiled garments. If larger loads are washed in this cycle, wash time will be increased. ■ Did you wash a large load in a gentle or Delicate cycle? When using the Quick Wash or Delicate cycles, you should use small loads. This ensures a gentle wash for your garments without increasing cycle times. Clothes Care Load too wet ■ Did you use the right cycle for the load being washed? Select a cycle with a higher spin speed. ■ Did you wash a single item or bulky items or have you overloaded the washer? A single item, bulky items, or overloading may cause imbalance. Add items or try to evenly distribute your wet laundry in the drum, and start a Drain/Spin cycle. If the laundry is still wet, take half of the load out of the washer and try again. ■ Did you use HE detergent? Suds during rinse and spin cycles can reduce spin speed. Use HE detergent. Residue, lint, stains on load; gray whites, dingy colors ■ Did you add detergent to the dispenser? For best results, add detergent to the detergent compartment. Do not add detergent to the washer drum. ■ Did you sort properly? Sort lint givers (towels, chenille) from lint takers (corduroy, synthetics). Transfer of dye can occur when mixing whites and colors in a load. Sort dark clothes from whites and lights. ■ Did you overload the washer? Do not overload the washer. The washer can be fully loaded, but not tightly packed. The wash load must be balanced. Lint can be trapped in the load if overloaded. ■ Check the following: Was paper or tissue left in pockets?

Page 24

Page 25

25

Assistance Or Service

Before calling for assistance or service, please check “Troubleshooting.” It may save you the cost of a service call. If you still need help, follow the instructions below. When calling, please know the purchase date and the complete model and serial number of your appliance. This information will help us to better respond to your request. If you need replacement parts If you need to order replacement parts, we recommend that you only use FSP® factory specified parts. These parts will fit right and work right because they are made with the same precision used to build every new WHIRLPOOL® appliance. To locate FSP® replacement parts in your area: In the U.S.A., call the Customer eXperience Center at 1-800-253-1301, or your nearest designated service center. In Canada, call 1-800-807-6777, or your nearest designated service center. In the U.S.A. Call the Whirlpool Customer eXperience Center toll free: 1-800-253-1301. Our consultants provide assistance with: ■ Features and specifications on our full line of appliances ■ Installation information ■ Use and maintenance procedures ■ Accessory and repair parts sales ■ Specialized customer assistance (Spanish speaking, hearing impaired, limited vision, etc.) ■ Referrals to local dealers, repair parts distributors, and service companies Whirlpool designated service technicians are trained to fulfill the product warranty and provide after-warranty service anywhere in the United States. To locate the Whirlpool designated service company in your area, you can also look in your telephone directory Yellow Pages. For further assistance If you need further assistance, you can write to Whirlpool Corporation with any questions or concerns at: Whirlpool Brand Home Appliances Customer eXperience Center 553 Benson Road Benton Harbor, MI 49022-2692 Please include a daytime phone number in your correspondence. In Canada Call the Whirlpool Canada LP Customer Interaction Centre toll free: 1-800-807-6777. Our consultants provide assistance with: ■ Use and maintenance procedures ■ Accessory and repair parts sales ■ Features and specifications on our full line of appliances ■ Referrals to local dealers, repair parts distributors, and service companies. Whirlpool Canada LP designated service technicians are trained to fulfill the product warranty and provide after-warranty service anywhere in Canada. For further assistance If you need further assistance, you can write to Whirlpool Canada LP with any questions or concerns at: Customer Interaction Centre Whirlpool Canada LP 1901 Minnesota Court Mississauga, Ontario L5N 3A7 Please include a daytime phone number in your correspondence. Accessories Enhance your washer with these premium accessories. For more high-quality items or to order, call 1-800-901-2042, or visit us at www.whirlpool.com/accessories. In Canada, call 1-800-807-6777 or visit us at www.whirlpoolparts.ca. Part Number Accessory

8212638Rp

6 ft (1.8 m) nylon braided space-saving fill hose, 90° elbow, hypro-blue steel couplings. Safer than stainless steel. (2-pack)

8212487Rp

5 ft (1.5 m) nylon braided fill hose. Safer than stainless steel. (2-pack) 8212526 Washer drip tray, fits under all 31682 All purpose appliance cleaner

1903Wh

Laundry supply storage cart

W10135699

AFFRESH™ Washer Cleaner

W10178021

Stack kit

Page 26

Page 27

27

Sécurité De La Laveuse

Risque possible de décès ou de blessure grave si vous ne suivez pas immédiatement les instructions. Risque possible de décès ou de blessure grave si vous ne suivez pas les instructions. Tous les messages de sécurité vous diront quel est le danger potentiel et vous disent comment réduire le risque de blessure et ce qui peut se produire en cas de non-respect des instructions. Votre sécurité et celle des autres est très importante. Nous donnons de nombreux messages de sécurité importants dans ce manuel et sur votre appareil ménager. Assurez-vous de toujours lire tous les messages de sécurité et de vous y conformer.
